Exerpeutic Triple SureLock Inversion Table Owner's Manual page 14

ASSEMBLY
Tools:
13,17mm Wrench
6mm Allen Wrench
2PCS
1PC
Step 3
Note: The parts are labeled with R and L decals to indicate the left and right sides. The left and
right side are labeled as if you are on the inversion table.
3A. Installing the Front Support Post
Align the Front Support Post (4) and two Metal Plates (5) with both the Left & Right Front
Posts (3) & (2). Attach with four Hex Bolts (47), four Flat Washers (59), and four Nylon Nuts
(61). DO NOT fully tighten the hardware until instructed to do so in STEP 4.
DO NOT fully tighten Socket Hex Bolts (47) at this time.
3B. NOW fully tighten the four Socket Hex Bolts (46) using the 6mm Allen Wrench provided.
3C. Attach two Rubber Pads (43) onto the Front Support Post (4).
3D. install a Foot Caps (41) onto each end of the Foot Bars (1).
Hardware:
(47) Hex Bolt (59) Flat Washers
(61) Nylon Nut
4 PCS
4 PCS
4 PCS
12
