PowerBoss
®
The Power of Clean
User Manual
Rider Sweeper
Armadillo 6X
(Diesel, Gas, & LPG)
AM7D-III
(Diesel)
PowerBoss®, Minuteman International, Inc.
A Member of the Hako Group
PB# 4100043UM Rev. B 07/20
