Front Runner SSDR003 Quick Start Manual

Fit Drawer SYSTEM
Fit the four Mounting
( )
A
Brackets, two left and two
right. There are two different
height options available
when mounting the
Brackets. Choose the option
best suited to your vehicle.
REV_A01
-
MERCEDES BENZ GELÄNDEWAGEN
DRAWER SYSTEM
( )
b
Place the Drawer System into the vehicle locating it as
far back as possible without it interfering with Rear Door.
Center the Drawer System left to right.
Using the Mounting Brackets as
( )
C
guides, mark the position of the
four Mounting Holes (Outer hole
on each Mounting Bracket) onto
the vehicle's wheel arches.
Remove the Drawer System and
drill 9mm holes through the
wheel arches on your markings.
Refit the Drawer System.
1
INSTALL TIME: 30 mins
You will need:
9 mm Drill Bit and Drill Machine
13 mm Flat and Socket Wrench
7 mm Flat or Socket Wrench
8 mm Flat or Socket Wrench
3 mm Hex Key
4 mm Hex Key
Marking Pen
SSDR003
