Giga LAN
Rear Panel I/O
Internal I/O
Connectors
& Headers
- Capability for "full rate" BluRay DVD/HD DVD
support.
- Meets Microsoft WLP3.10 and future WLP audio
requirements
• Dual* Gigabit LAN, Realtek RTL8111E PCIe GigaLAN
controller
• Supports Realtek Teaming Technology
*The X79R-AX Deluxe only has one Giga LAN.
• 1 x PS/2 keyboard/mouse combo port
• 1 x CLR_CMOS button (Only X79R-AX has this button)
• 2 x eSATA 6Gb/s ports (Only X79R-AX has these ports)
• 6 x USB 2.0 ports
• 4 x USB 3.0 ports
• 2 x RJ45 LAN connectors (Only X79R-AX has two con-
nectors)
• 1 x Bluetooth Dongle (Only X79R-AX has this dongle)
• 1 x Wireless LAN Dongle (Only X79R-AX has this
dongle)
• 1 x Audio port with 6 audio jacks (Center/ Subwoofer
Speaker Out/ Rear Speaker Out / Side Speaker Out / Line
in, microphone in, line out, and optical SPDIF out)
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin ATX Power Supply connector
• 4 x Serial ATA 3Gb/s connectors
• 8 x Serial ATA 6Gb/s connectors (X79R-AX Deluxe only
has 6 x Serial ATA 6Gb/s connectors)
• 2 x USB 2.0 headers support additional 4 USB 2.0 ports
• 1 x USB 3.0 headers supports additional 2 USB 3.0 ports
• 1 x CLR_CMOS jumper
• 1 x power button (Only X79R-AX has this button)
• 1 x reset button (Only X79R-AX has this button)
• 1 x Front panel switch/LED header
• 1 x SPDIF out header
• 1 x Front panel audio header
• 1 x buzzer
• 1 x POST Debug LED (Only X79R-AX has this LED)
• 1 x COM header
• 1 x ME UNLOCK header
• C P U _ FA N 1 / C P U _ FA N 2 / S Y S _ FA N 1 / P W R _ FA N 1 /
PWR_FAN2 connectors
Introducing the Motherboard
