Malibu - 5+2 Drawer Chest
Assembly Instructions -
In order to prevent overturning, this product must be
used with the wall attachment device provided
Dimensions
Width - 74.8cm
Depth - 39cm
Height - 108.6cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, please visit www.argos-support.co.uk
or email: Help@ClickSpares.co.uk (quoting your original order number)
Alternatively, call the Spares Helpline on: 0370 112 1928.
For any other queries please contact the Customer Helpline on: 0345 640 2020
Please keep for future reference
C R
WARNING!
More help is available throughout this
booklet by scanning in the QR codes
or typing in the links
C R
C R
C R
C R
C R
C R
558/8228
539/6173
544/1341
541/5566
542/1907
MADE IN
BRITAIN
Issue 5 - 06/10/16
Advertisement
Table of Contents
Related Manuals for Argos 558/8228
Summary of Contents for Argos 558/8228
- Page 1 Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928.
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 38kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 Components - Panels If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
- Page 4 Components - Fittings If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly.
- Page 5 Assembly Instructions Step 1 Use the Drawer Fittings Bag marked ‘drw kit’ for Steps 1 - 14 Prepare 5 pairs of Standard Drawer Box Assembly drawer sides https://www.youtube.com/watch?v=HclfJdkm-Lg Insert a large locking cam nut into the left drawer sides and the right drawer sides Note: The arrow on the locking cam nut must...
- Page 6 Assembly Instructions Step 3 Standard Drawer Box Assembly https://www.youtube.com/watch?v=HclfJdkm-Lg Fit the large drawer bases Slide a large drawer base down the grooves in the drawer sides and down into the groove in the large drawer front Step 4 Fit the large drawer backs Fit a large drawer back between the drawer...
- Page 7 Assembly Instructions Step 7 Prepare 2 pairs of drawer sides Insert a large locking cam nut into the left drawer sides and the right drawer sides Note: The arrow on the locking cam nut must point towards the hole in the end of the panel.
- Page 8 Assembly Instructions Step 9 Fit the small drawer bases Slide a small drawer base down the grooves in the drawer sides down into the groove in the small drawer front Step 10 Fit the small drawer backs Fit a small drawer back between the drawer sides Make sure that the small...
- Page 9 Assembly Instructions Fixing Bottom Mounted Runners Step 13 https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit runners to the 5 large drawers Runners must be pushed up against the drawer front Fit the DL runner the bottom edge of the left drawer side , as shown, making sure that it is pushed up against the back of the drawer front.
- Page 10 Assembly Instructions Step 15 Use the Main Fittings Bag for Steps 15 - end Fixing Bottom Mounted Runners Prepare the left side https://www.youtube.com/watch?v=Z6lGMy19h7Q Fit 6 CL runners to the left side screw The 1st screw uses the 1st hole in from the front of the runner.
- Page 11 Assembly Instructions Step 16 Prepare the right side screw Fit 6 CR runners to the right side The 1st screw uses the 1st hole in from the front of the runner. The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 12 Assembly Instructions Step 17 Note: The cross rail has no Prepare the cross rail holes drilled on either surface Tap 4 wooden dowels into the cross rail Finished front edge Step 18 Fit the cross rail onto the left side Finished front edge Push the cross rail...
-
Page 13: Table Of Contents
Assembly Instructions Step 20 Carcase Assembly https://www.youtube.com/watch?v=9C7tgv5xnbE Fit the plinth Push the plinth down onto the left side Turn the large locking cam nut clockwise to the “2 o’clock” position as far as it will go to secure the panels. Important: Make sure there is no gap between the fitted panels. -
Page 14: The "2 O'clock" Position As Far As It Will Go To Secure The Panels
Assembly Instructions Step 23 Fit the other back rail Push the back rail down onto the left side Turn the large locking cam nut clockwise to the “2 o’clock” position as far as it will go to secure the panels. Important: Make sure there is no gap between the fitted panels. -
Page 15: Insert 2 Large Locking
Assembly Instructions Step 25 Finished Prepare the divider screw front edge Fit a runner the divider The 1st screw uses the 1st hole in from the front of the runner. Finished front edge The 2nd and 3rd screws use the holes that line up with the other panel holes. -
Page 16: Secure The Panels
Assembly Instructions Step 26 Fit the divider to the Push the divider down onto the top Finished front edge Turn the 2 large locking cam nuts clockwise to the “2 o’clock” position as far as they will go to secure the panels. Important: Make sure there is no gap between the fitted panels. - Page 17 Assembly Instructions Step 28 Squaring up a Chest and tting the Back Panel www.youtube.com/watch?v=FeaI6541z7o Fit the back The measurement from top corner X to bottom corner X must be Square up the unit by equal to the measurement from top corner Y to bottom corner Y making sure that measurement x to x equals y to y.
- Page 18 Assembly Instructions Step 30 WARNING! Fit the overbalance In order to prevent overturning protector kit this product must be used with the Before fitting the wall attachment device provided overbalance protector kit, use a spirit level to check the top of the unit is level, front-to-back and side-to-side in the 3 positions shown.
- Page 19 Side panel Drawer If you need help or have damaged or missing parts, please visit www.argos-support.co.uk or email: Help@ClickSpares.co.uk (quoting your original order number) Alternatively, call the Spares Helpline on: 0370 112 1928. For any other queries please contact the Customer Helpline on: 0345 640 2020...
- Page 20 ALR3296...
