Sophia 3 Drawer Bedside
Assembly Instructions -
Dimensions
Width - 40cm
Depth - 41.5cm
Height - 67cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800.
For further assistance please visit http://www.argos-support.co.uk/
Please keep for future reference
499/5348
501/5320
501/1496
Issue 1 - 12/05/16
Advertisement
Related Manuals for Argos Sophia 499/5348
Summary of Contents for Argos Sophia 499/5348
- Page 1 Depth - 41.5cm Height - 67cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts,call the Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/ Issue 1 - 12/05/16...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly · Do not stand or put weight on · Check you have all the · To reduce components and tools listed on the product, this could cause the likelihood of pages 2 and 3.
- Page 3 If you have damaged or missing componets, call the Components - Panels Customer Helpline:03456 400800. For further assistance please visit http://www.argos-support.co.uk/ Please check you have all the panels listed below Left Side × 1 Right Side × 1 Top × 1 (43.4 ×...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. Large locking nut × 12 Wooden dowel ×...
- Page 5 Assembly Instructions Step 1 Fitting dowels Insert Wooden dowels into Left side Right side Fix Runner Outside Right onto Left side by using Screws Fix Runner Outside Left onto Right side by using Screws ×12...
- Page 6 Assembly Instructions Step 2 Fitting locking pins Insert Large locking Pin into Top Note: Insert locking pin as shown. Do not over tighten. Fitting locking pins Fitting Large Locking pins to Base Fram...
- Page 7 Assembly Instructions Step 5 Attach the Sides to Base frame Attach Left Side Base Fram and fixing by Large Locking Nut Repeat this step to attach Right Side Base Frame Step 6 Insert back panel Slip the Back panel the groves on the Sides.
- Page 8 Assembly Instructions Step 7 Attaching Top Attach Top to the unit. Insert Large Locking Nuts where shown and use a screw driver to turn locking nuts clockwise to lock. Step 8 Drawer assembly Insert 4 Small locking into holes shown on back of Drawer front Note: Insert Locking pin as far as shown.
- Page 9 Assembly Instructions Step 9 Slip Drawer base into grooves. Fix Drawer back onto sides by using 4 Screws Fix Handle using Screw Fix Runners onto the underside of Drawer sides by using 6 Screws Repeat a - f to finish another 2 drawers.
- Page 10 Carefully put in drawers to the unit. If you need help or have damaged or missing parts,call the Customer Helpline: 03456 400800 Retailer:Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9,2NW For further assistance please visit http://www.argos-support.co.uk/...
- Page 11 If you need help or have damaged or missing parts,call the Customer Helpline: 03456 400800 Retailer:Argos Address: 489-499 Avebury Boulevard Saxon Gate West, Central Milton Keynes Bucks, MK9,2NW For further assistance please visit http://www.argos-support.co.uk/...
-
Page 12: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
