Ultimate Storage Bed
Assembly Instructions
- Please keep for future reference
501-3298
Dimensions
Width - 143,5cm
Depth - 196cm
Height - 91,5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800
Issue 2 - 24/09/15
Advertisement
Related Manuals for Argos 501-3298
Summary of Contents for Argos 501-3298
- Page 1 Ultimate Storage Bed Assembly Instructions - Please keep for future reference 501-3298 Dimensions Width - 143,5cm Depth - 196cm Height - 91,5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly . Check you have all the . We do not This product contain Natural timber; you may recommend the components and tools listed on notice some variation in the grain use of power pages 2 and 3.
- Page 3 Components - Panels Please check you have all the panels listed below Large middle bar x 2 (77 x 6,5cm) Side bar x 8 (36,9 x 4,5cm) Left side panel x 2 (36,2 x 30,4cm) Drawer front x 4 (76,4 x 16,1cm) Middle left side panel x 2 Drawer right side x 4 (36,2 x 40cm)
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Step 1 Step 1 It takes 3 hours to build 19 6X the bed. 20 2X Insert wooden dowels 18 4X into the indicated parts. 23 4X 24 4X 21 8X Step 2 Insert small wooden dowels where shown Attach runners...
- Page 6 Assembly Instructions Step 4 Attach base ,shelf and 2 side bars to right side panel using bolts Step 4 Step 5 Attach base ,shelf and 2 side bars to left side panel using bolts Step 4 Step 5 Step 6 Attach the two parts from step 4 and 5 to the previously assembled...
- Page 7 Assembly Instructions Step 7 Step 7 Fix large middle bar using screws Step 7 Step 8 Step 8 Turn cabinet up side down and fix back panels using nails...
- Page 8 Assembly Instructions Step 7 Step 9 Step 9 a: Attach drawers sides to drawer front using screws b: Slide drawer base into groove. c: Attach back using screws Step 10 Slide drawer into cabinet. S ID Assemble is complete!
