Attach Drawers; Insert Bolts - Mocka Addi Three Drawer Assembly Instructions Manual

Addi Three Drawer
Assembly Instructions
9
A
D
A
D
3
Attach panel [1] to the unit with 4x dowels (A) and secure
with 4x locking nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
1
A
D
4
10
Drawers x3
O
O
14
P
12
A
P
x2
11
P
10
Insert 5x small bolts (O) into panels [10] and [11]. Secure panels
[12], [13] and [14] to panels [10] and [11] with 1x dowel (A) and
5x small locking nuts (P). Tighten with a screwdriver. Slide panel
[15] down along the grooves between panels [12] and [13] to form
the base of the drawer.
O O
O
x2
11
10
13
P
P
15
12
11
10
13
x2
