Fig. 1
CAUTION: De-energize unit prior to servicing. For continued protection against risk of electric shock and fire hazard
replace fuse with the same type and rating. Do not expose to rain or moisture.
Earth
Ground
220VAC
power mains
Wire Strap
(from
Enclosure
to Door)
Battery 1
- 3 -
AC Delay
15
+ +
BAT --- DC ---
Battery connection
(non power-limited)
ON
Battery 2
5VDC
12VDC
Outputs to
devices are
power-limited
24VDC
AL4003V
