3Com 6000 Series Installation Manual page 11

6080 Rear Panel The following illustration details the components of the rear panel of the 3Com
Router 6080.
Figure 3 Rear Panel of the 3Com Router 6080
1. Holes for holding chassis
2. RPU Slot0
3. FIC Slot1
4. FIC Slot2
5. FIC Slot3
6. FIC Slot4
7. FIC Slot5
8. FIC Slot6
9. FIC Slot7
10. FIC Slot8
11. ESD-preventive wrist strap port
(1)
(3) (4)
1. Fan module
2. Grounding screw
3. ESD-preventive wrist strap port
4. PWR1 - first power supply
5. PWR2 - second power supply
Router Model and Structure
(2)
(5)
11
