74 C 8: F
HAPTER LEXIBLE
1-port OC-3 ATM MM
FIC (3C13882)
1-port OC-3 ATM SM
FIC (3C13884)
1-port OC-3 ATM SML
FIC (3C13886)
Interface Attributes
Attribute 1-port OC-3 ATM MM
Optical fiber
SC
connector
Connector
1
number
Interface
SONET OC-3/SDH STM-1
standard
Interface
155Mbps
speed
Cable and the
max. Multi-mode optical fiber of
transmission 2km transmission distance
distance
Transmitter LD
Transmitting Min: -15dBm
optical power Max: -8dBm
Receiver Min: -28dBm
sensitivity Max: -8dBm
Central
1310nm
wavelength
ATM Traffic CBR (Constant Bit Rate), rt_VBR (Variable Bit Rate-
Supported
service
Rate-Non Real Time),
Panel and Interface LED
I C
NTERFACE ARDS
ATM interface cards (including 1-port OC-3 ATM MM SC, 1-port OC-3 ATM SM
SC 15km, and 1-port OC-3 ATM SM SC 30km) function in the system primarily to
provide ATM interfaces for the Router. They can:
Support two frame formats, namely, SDH STM-1 and SONET OC-3.
Allow scrambling in data transmission.
Support both line clock (used when working as DTE interface), and internal
clock (used when working as DCE interface)
Support the test measures of local cell loopback, local payload loopback and
remote loop.
Table 14 Interface attributes of the ATM cards
1-port OC-3 ATM SM
Single-mode optical fiber
of
distance
LED
Min: -19dBm
Max: -14dBm
Min: -30dBm
Max: -14dBm
UBR (Unspecified Bit Rate)
The following figure illustrates the 1-port OC-3 ATM MM panel.
Figure 16 1-port OC-3 ATM MM panel
Single-mode
15km transmission
transmission distance
LD
Min: -5dBm
Max: 0dBm
Min: -34dBm
Max: -10dBm
1-port OC-3 ATM SML
optical fiber
Real Time), (Variable Bit
nrt_VBR
of 30km
