Summary of Contents for 3Com Router 3030
- Page 1 Part No. 10014363 Published August 2004 Router 6000 and 3000 DSL Family Release Notes Software V 2.01 Router 6040 (3C13840) Router 6080 (3C13880) Router 3030 (3C13630) Router 3031 (3C13631) Router 3032 (3C13632) Router 3033 (3C13633) Router 3034 (3C13634) Router 3035 (3C13635)
-
Page 3: Important Note
2.01. You can obtain the latest version of router software from the 3Com support web site. IMPORTANT: For 3Com Router 3000 DSL Family running V2.00 router software. If you upgrade your router software via tftp, it will always fail on the first attempt with the following output: <3Com>tftp <server ip address>... -
Page 4: System Access
Incorrect packet received It is necessary to wait 3 minutes and then repeat the command. IMPORTANT: For 3Com 6000 Router Family running V2.00 router software. If you upgrade your router software via tftp and set the destination filename to secure.bin then tftp will always fail on the first attempt with the following output: <3Com>tftp <server ip address>... -
Page 5: System Management
Router 3000 DSL Family resets after reboot. Configure NTP protocol or check system clock and set clock manually. Cannot undo snmp trap target created using SNMP. 3Com Network Director automatically configures the router to send SNMP traps by default. The entry cannot be deleted using the CLI. -
Page 6: Routing Protocol
NAT traversal is not compatible with Cisco routers Only one security association is used for all traffic flows. IPsec SAs originated from 3Com routers will be ACL based. To obtain flow-based functionality, create multiple ACLs with one rule each. -
Page 7: Documentation Errors
The Router 6000 Family uses the frame relay terminology Cir Allow and Cir, instead of Cir and MinCir respectively. Please refer to the following documents: '3Com Router Command Reference Manual' page 1033. '3Com Router Configuration Guide' page 1019 Text Correction: Use CIR Allow when configuring the maximum Committed Information Rate for the DTE when no network congestion exists. -
Page 8: Chapter 1: 3C Om Router 6000/3000 Dsl Family Release Notes Softwarev 2.01
1: 3C 6000/3000 DSL F HAPTER OUTER The SNMP Trap enable default is incorrectly documented. All traps are enabled when the snmp-agent command is executed Firewall ASPF UDP detection does not support the following UDP based applications: TFTP, SSH, DHCP. Named access list is documented but not supported.
