SAN DIEGO - Bookcase
Assembly Instructions
- Please keep for future reference
414/9376
Dimensions
Width - 90cm
Depth - 35cm
Height - 180cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 03456 400 800
Issue 1 - 15/04/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos SAN DIEGO 414/9376
Summary of Contents for Argos SAN DIEGO 414/9376
- Page 1 SAN DIEGO - Bookcase Assembly Instructions - Please keep for future reference 414/9376 Dimensions Width - 90cm Depth - 35cm Height - 180cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 15/04/15...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly Check you have all the This product has been produced We do not components and tools listed on from natural timber; you may recommend the pages 2 and 3. notice some variation in the grain use of power and colour of different component...
- Page 3 Components - Panels Please check you have all the panels listed below underside 1 Right side panel (177.2 x 32cm) 7 Top panel (90 x 33.8cm) underside 8 Base panel x 2 2 Left side panel (177.2 x 32cm) (81 x 30cm) 9 Shelf x 2 (81 x 30cm) 3 Back panel x 2...
- Page 4 Components - Fittings If you have damaged or missing components, call the Customer Helpline: 03456 400 800 Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 Assembly Instructions Step 1 Fixing right front frame to the right side panel (Two people required for an easier assembly). Insert right side panel into right front frame through joints. Yes! Note: Before fixing blocks into Attention: correct position of panel. place it is important to ensure that the slot and groove of parts...
- Page 6 Assembly Instructions Step 3 Fitting Metal dowels. Screw metal dowels into right side panel and left side panel Insert metal Note: dowels as far as shown. Do not over tighten. Step 4 Insert dowels into the indicated parts.
- Page 7 Assembly Instructions Step 5 Assembling parts. Put parts together as shown in the diagram. Step 6 Assembling the cabinet. Note: The Insert assembled frame hole position. and front frames into holes on right side panel , as shown. Step 7 Fit cross rail to the right side panel...
- Page 8 Assembly Instructions Step 8 Attention: Inserting base panels and shelves. With help, fit base panels and shelves right side panel Attention! Round edges on base panels and shelves must be facing front. Insert locking nuts into base panels where shown. Use a screwdriver to turn locking nuts clockwise...
- Page 9 Assembly Instructions Step 10 Fix bottom front frame to the right and left front frames using screws as shown in the diagram. Step 11 Attach middle drawer runner to back column using screw Step 12 Fixing middle drawer runner. Fit middle drawer runner in vertical frame and back column...
- Page 10 Assembly Instructions Step 13 Fixing side drawer runner. Fit side drawer runners to the side panels, then fix them using screws as shown. With help, carefully turn the product with its front facing up. Step 14 Fixing top panel. With help, fit top panel to the cabinet then fix it using screws...
- Page 11 Assembly Instructions Step 15 Fix side plinths the side panels using screws Note: Make sure side plinths are aligned to the bottom and front edges of the side panels. Fix front plinth to the front frames using screws Note: Make sure front plinth is aligned to the bottom edge of the side...
- Page 12 Assembly Instructions Step 17 Fixing back panels. Important: Cabinet MUST ‘square’ when back panels are attached. Make sure back panels are in flush with the edge of the top panel prior to fixing. Attach back panel to the right side first using nails Position profile onto...
- Page 13 Assembly Instructions Step 18 Smaller drawer assembly. Attach drawer sides to the drawer front using screws Slide drawer bottom into slots on drawer sides and position drawer back in place. Holding the drawer back , press the drawer sides and fix them using screws Using bolts attach...
- Page 14 Assembly Instructions Step 20 Insert drawers into unit. With the back of the drawers past the front frames, use a hammer to tap dowels in flush to drawer sides. This is a safety catch to stop drawer falling out. Step 21 Note: Wall plugs not supplied.
-
Page 15: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
