Darcy - Bookcase with 2 doors
Assembly Instructions - Please keep for future reference
428/5890
Dimensions
Width - 90 cm
Depth - 42 cm
Height - 120.1 cm
Important
- Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400 800
Issue 1 - 03/06/2015
1
Advertisement
Related Manuals for Argos Darcy 428/5890
Summary of Contents for Argos Darcy 428/5890
- Page 1 Darcy - Bookcase with 2 doors Assembly Instructions - Please keep for future reference 428/5890 Dimensions Width - 90 cm Depth - 42 cm Height - 120.1 cm Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6400 800 Issue 1 - 03/06/2015...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assemb ly • Check you have all the • Assemble on a soft level • Dispose of all packaging components and tools listed on surface to avoid damaging the carefully and responsibly.
- Page 3 If you have damaged or missing components Component - Panels call the Customer Helpline: 0845 6400 800 Please check you have all the panels listed below Bottom (90 x 42cm) (90 x 42cm) Left side Right side (111 x 41.8cm) (111 x 41.8cm) Vertical Vertical...
- Page 4 Components - Fittings Please check you have all the fittings listed below Wooden dowel x 40 Hinge plate x 4 Door hinge x 4 (8x35) Locking nut x 22 ( 15x13) 4x13mm Screw x 8 Cap x 22 Hexagon bolt x 6 Metal dowel x 22 Cap x 6 (7x50)
- Page 5 Assembly Instructions Step 1 Step 1 a: Inserting dowels and locking nuts Insert locking nuts into the left side panel Insert wooden dowels into the left side panel Screw metal dowels Attach flap stay using screws WARNING! Please wear goggles or protective eyewear whilst hammering...
- Page 6 Assembly Instructions Step 1 Step 2 a: Inserting dowels and locking nuts Insert locking nuts into the right side panel Insert wooden dowels into the right side panel Screw metal dowels Attach flap stay using screws WARNING! Please wear goggles or protective eyewear whilst hammering...
- Page 7 Assembly Instructions Step 1 Step 2 Step 1 Step 3 a: Inserting dowels and locking nuts Insert locking nuts into the vertical partition middle Repeat step with the vertical partition bottom Insert wooden dowels into the vertical partition Finished middle front edge Finished Repeat step with vertical...
- Page 8 Assembly Instructions Step 1 Step 2 Step 1 Step 4 a: Inserting dowels and locking nuts Insert locking nuts into the vertical top partition Insert wooden dowels into the vertical partition WARNING! Please wear goggles or protective eyewear whilst hammering dowels in place.
- Page 9 Assembly Instructions Step 5 a: Fitting dowels and cams Insert locking nuts into the horizontal top partition Insert wooden dowels into the horizontal partition Screw metal dowels into the horizontal top partition Insert shelf support Rotate horizontal top partition. Screw metal dowels WARNING! Please wear goggles or...
- Page 10 Assembly Instructions Step 7 a: Inserting dowels and locking nuts Insert locking nuts into the horizontal bottom partition Insert wooden dowels into the horizontal bottom partition Screw metal dowels into the horizontal bottom partition Insert shelf support Rotate horizontal bottom partition.
- Page 11 Assembly Instructions Step 9 Attaching partitions Attach vertical top partition to the horizontal top partittion Finished Attach vertical partition middle front edge to the to the horizontal partition top Use the allen key turn locking nuts clockwise to lock Cover with caps Attach vertical bottom partition to the to the horizontal partition bottom...
- Page 12 Assembly Instructions Step 10 Attaching panels Attach right side panel to the horizontal partitions & Attach left side panel to the horizontal partitions & Use the allen key turn locking nuts clockwise to lock Cover with caps Finished front edge Step 11 Attaching plinth Attach feet...
- Page 13 Assembly Instructions Step 12 Attaching plinth Fit long plinth & short plinth to the bottom Step 13 Mounting bracket Place mounting bracket onto the assembly as shown. Mark holes with a punch and fix the bracket with screws...
- Page 14 Assembly Instructions Step 14 Attaching top Attach top to the sides & vertical top partition Use the allen key turn locking nuts clockwise to lock Cover with caps Step 15 Inserting rear panel Slide rear top , rear middle & rear bottom panels into the grooves of sides...
- Page 15 Assembly Instructions Step 16 Attaching bottom panel Attach bottom panel to the sides & vertical partition using hexagon bolt & allen key Cover bolts with caps...
- Page 16 Assembly Instructions Step 17 Fixing rear panels Fix rear panel to the back of bookcase using stabilizer Attach washers using screw IMPORTANT ! Cabinet MUST be “square” when rear panel is attached.
- Page 17 Assembly Instructions Step 18 Fixing to wall It is recommended that the bookcase is fixed to a wall. With help, move bookcase into position. Mark fixing hole on wall and remove bookcase. Fix wall bracket to the wall. Reposition bookcase. Mark a hole with a punch and fix bookcase to wall bracek...
-
Page 18: Hinge Adjustment
Assembly Instructions Step 17 Hanging flaps a: slot flap hinges onto ‘hinge plates’. b: Tighten screw shown to lock hinges in Hinge adjustment position. Adjust hinges so that gaps around the flap is even. Fix flap stay to the flap using screws Attach door handles using screws...
