Eden - Small Side Table
Assembly Instructions -
Dimensions
Width - 47.5cm
Depth - 38cm
Height - 51cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
414/1594
414/4962
MADE IN
BRITAIN
Issue 1 - 15/05/15
Advertisement
Related Manuals for Argos Eden 414/1594
Summary of Contents for Argos Eden 414/1594
- Page 1 Eden - Small Side Table Assembly Instructions - 414/1594 Please keep for future reference 414/4962 Dimensions Width - 47.5cm Depth - 38cm MADE IN Height - 51cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 Issue 1 - 15/05/15...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 10kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left End Right End (DF3748) (DF3749) (DF3750) (475 x 378mm) (475 x 378mm) (475 x 381mm) Base...
-
Page 4: Tools Required
If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. - Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the drawer front Screw 2 metal dowels into the drawer front Note: Tighten the metal dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the drawer base...
- Page 7 Assembly Instructions Step 8 Prepare the left end Place a runner the left end shown. Slide back the Finished top of runner and use the front edge 1st hole from the front to fit the 1st screw Slide the runner back the other way and fit the 2nd screw into...
- Page 8 Assembly Instructions Step 9 Prepare the right end Place a runner the right end shown. Slide back the top of runner and use the 1st hole from the front to fit the 1st screw Slide the runner back the other way and Finished fit the 2nd screw into...
- Page 9 Assembly Instructions Step 10 Prepare the base Push 4 hollow core locking nuts into the base , making sure that they are flush against the panel’s Finished surface. front edge Using a hammer, tap in the pin on the hollow core locking nut Step 11 Fit the base to the...
- Page 10 Assembly Instructions Step 13 Prepare the top Screw 4 small metal dowels into the top Finished front edge Step 14 Fit the top Push the top onto the assembly. The 4 small metal dowels fitted to the top must slide into the top of the 4 hollow core locking nuts fitted to the ends...
- Page 11 Assembly is complete If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 12 ALR3154...
