SAN DIEGO - Nest Of Tables
Assembly Instructions
- Please keep for future reference
395/6199
Dimensions
Width - 66cm
Depth - 44cm
Height - 59cm
Important –
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
Customer Helpline: 03456 400 800
Issue 1 - 15/04/15

Advertisement

loading
Need help?

Need help?

Do you have a question about the SAN DIEGO 395/6199 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos SAN DIEGO 395/6199

  • Page 1 SAN DIEGO - Nest Of Tables Assembly Instructions - Please keep for future reference 395/6199 Dimensions Width - 66cm Depth - 44cm Height - 59cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400 800 Issue 1 - 15/04/15...
