3.2
Service programs
3.2.1
How to call up service program
1.
Set slide switch 'SERVICE' (1) to 'ON'.
2.
Press 'LT' button (2) once.
Button 0 - least popular titles (flops)
Pressing button 0 once indicates the least
popular record. Pressing button 0 again
shows the record with second lowest number
of plays. Press button 0 again shows the
third lowest etc..
Press button 'R' (RESET) to terminate the
'flop' call.
Button 1 - Top Tunes
Shows the record which was played most frequently followed by the number of plays (Max. 99). If
one record was played more often than 99 times, the counter remains in this position. Pressing
button 1 again shows the second popular record, etc.
Press button 'R' RESET to terminate the 'Top Tune' call.
Button 2 - cash box contents
Shows the cash box contents in basic units; basic units being the value of the lowest coin, resp. coin
value of coin output 1 on the S&CC.
Example (lowest coin 25ct):
Press button 'R' RESET to terminate the 'cash box contents' call.
Button 3 - clear memory
Press and hold down button 3, then press button 'R' RESET. All counters are reset to zero.
Button 4 - display check and program number version
When you press button 4 the digital display automatically indicates the number 8 on all three digits.
Successivly 'Record Playing', 'Hit of the House', 'Error' and 'Credit' will light and the program version
number will appear, e.g. 7.01 or higher.
Button 5 - Playstimulator
The playstimulator is playing a random record automatically after a programmed time period. It is
programmable between 1 and 98 minutes. For programming please refer to
OMT VINYL – edition: 13.08.2007
display readout: 0 4 5 = 45 x 25ct = $ 11.25
1
Z
6
K
T.T.
F
7
5
6
6
+2
5
5
4
+3
3
4
4
GP
ON
+
3
3
2
Service
6
1
2
2
OFF
0
0
0
BS
B4
B3
GP
Korb
Location
ACHTUNG:
MEMORY-Stecker von OFF
auf ON umstecken, wenn
Top Tunes, Popularitätszähler
oder Kassenzähler arbeiten soll.
ATTENTION:
Move MEMORY Plug from OFF
to ON if Top tunes, Pop Meter or
Selection &
Cash Box Content Registration
is required.
A
TTENTION
:
Placer la prise MEMORY en
Credit Computer
position ON de la position OFF
si le Top Tunes, le compteur de
100 - 160 - 200
popularité et le contenu de la
caisse sont demandés.
M3 M6 M
C
chapter 3.4, on page
Service programs
2
1
2
6
6
4
5
5
5
4
4
T1
3
3
2
2
10
LT
1
1
M
20
0
0
+B
B2
B1
ON
Memory
0047971
OFF
7.
5
- Quick Links:
- Set up to Play
- Trouble Shooting Chart
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the One More Time Vinyl and is the answer not in the manual?
Questions and answers
gripper needs adjusting so that it can get under the record to pick it up
To adjust the gripper on a Wurlitzer One More Time Vinyl to pick up records, ensure the following:
1. The gripper arm is properly linked to the cam and gear shaft using the two-way spring clutch.
2. Check that the turntable chassis linkage is not maladjusted, which could push the turntable too far right and pinch the record.
3. Make sure the upper clamp is aligned correctly and not positioned deeper than the plane of the record.
4. Ensure the complete gear cycle takes at least 10 seconds to allow proper timing and avoid misplacement of records.
5. Confirm the arm catches up correctly after the clutch spring tension is released. If the arm flips too late, it can throw the record into the wrong compartment.
Proper mechanical alignment and cycle timing are critical for the gripper to pick up records reliably.
