Technical Specifications
Specifications
Models
IP7133
IP7134 (Wireless)
System
CPU: VVTK-1000 SoC
Flash: 4 MB
RAM: 32 MB
Embedded OS: Linux 2.4
Lens
Board lens type, f = 4.09 mm, F2.0, Fixed,
focus range: 70 cm to infinity
Angle of view
49.6 ° (horizontal)
38.2 ° (vertical)
Shutter Time
1/5 sec. to 1/15000 sec.
Image Sensor
OV 1/4" CMOS sensor in VGA resolution
Minimum Illumination
0.4 Lux / F2.0
Video
Compression: MJPEG & MPEG-4
Streaming:
Simultaneous dual-streaming
MPEG-4 streaming over UDP, TCP, or HTTP
MPEG-4 multicast streaming
MJPEG streaming over HTTP
Supports 3GPP mobile surveillance
Frame rates:
MPEG-4: Up to 30/25 fps at 640x480
MJPEG: Up to 30/25 fps at 640x480
Image Settings
Adjustable image size, quality, and bit rate
Time stamp and text caption overlay
Flip & mirror
Configurable brightness, contrast, saturation,
sharpness, and white balance
AGC, AWB, AEC (Automatic Exposure Control)
Supports privacy masks
Audio
Compression:
GSM-AMR speech encoding,
bit rate: 4.75 kbps to 12.2 kbps
MPEG-4 AAC audio encoding,
bit rate: 16 kbps to 128 kbps
Interface:
Built-in microphone
Supports audio mute
VIVOTEK - A Leading Provider of Multimedia Communication Solutions
Networking Networking
10/100 Mbps Ethernet, RJ-45 10/100 Mbps Ethernet, RJ-45
Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/ Protocols: IPv4, TCP/IP, HTTP, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, and PPPoE DDNS, and PPPoE
Built-in 802.11b/g WLAN (IP7134) Built-in 802.11b/g WLAN (IP7134)
Alarm and Event Management Alarm and Event Management
Triple-window video for motion detection Triple-window video for motion detection
One D/I and one D/O for external sensor and alarm One D/I and one D/O for external sensor and alarm
Event notification using HTTP, SMTP, or FTP Event notification using HTTP, SMTP, or FTP
Local recording of MP4 file Local recording of MP4 file
Security Security
Muilti-level user access with password protection Muilti-level user access with password protection
IP address filtering IP address filtering
Wireless: WEP, WPA-PSK, WPA2 (IP7134) Wireless: WEP, WPA-PSK, WPA2 (IP7134)
Users Users
Camera live viewing for up to 10 clients Camera live viewing for up to 10 clients
Dimension Dimension
26.9 mm (D) x 86.7 mm (W) x 87.6 mm (H) 26.9 mm (D) x 86.7 mm (W) x 87.6 mm (H)
Weight Weight
Net: 106 g (IP7133) Net: 106 g (IP7133)
Net: 122 g (IP7134) Net: 122 g (IP7134)
LED Indicator LED Indicator
System power and status indicator System power and status indicator
System activity and network link indicator System activity and network link indicator
Privacy button on Privacy button on
Power Power
5V DC 5V DC
Power Consumption: Max 5 W (IP7133) Power Consumption: Max 5 W (IP7133)
Approvals Approvals
CE, LVD, FCC, VCCI CE, LVD, FCC, VCCI
Operating Environments Operating Environments
Temperature: 0 ° ~ 40 ° C Temperature: 0 ° ~ 40 ° C
Humidity: 20 % ~ 80 % RH Humidity: 20 % ~ 80 % RH
Viewing System Requirements Viewing System Requirements
OS: Microsoft Windows 2000/XP/Vista OS: Microsoft Windows 2000/XP/Vista
Browser: Internet Explorer 6.x or above Browser: Internet Explorer 6.x or above
Cellphone: 3GPP player Cellphone: 3GPP player
Real Player: 10.5 or above Real Player: 10.5 or above
Quick Time: 6.5 or above Quick Time: 6.5 or above
Installation, Management, and Maintenance Installation, Management, and Maintenance
Installation Wizard 2 Installation Wizard 2
16-CH recording software 16-CH recording software
Supports firmware upgrade Supports firmware upgrade
Applications Applications
SDK available for application development and SDK available for application development and
system integration system integration
Max 6.6 W (IP7134) Max 6.6 W (IP7134)
User's Manual - 85
