Wireless LAN (IP7134 only)

SSID (Service Set Identifier): It is a name that identifies a wireless network. Access Points and wireless
clients attempting to connect to a specific WLAN (Wireless Local Area Network) must use the same
SSID. The default setting is default. Note: The maximum length of SSID is 32 single-byte characters and
SSID can't be any of ", <, > and space character.
Wireless mode: Clicking on the pull-down menu to select from the following options:
Infrastructure: Make the Network Camera connect to the WLAN via an Access Point. (The default setting)
Ad-Hoc: Make the Network Camera connect directly to a host equipped with a wireless adapter in a peer-
to-peer environment.
Channel: While in infrastructure mode, the channel is selected automatically to match the channel setting
for the selected Access Point. In Ad-Hoc mode, the channel must be manually set to the same channel
for each wireless adapter. The default channel setting depends on the installed region.
TX rate: This field is for selecting the maximum transmission rate on the network. The default setting
is "auto", that is the Network Camera will try to connect to the other wireless device with highest
transmitting rate.
Security: Select the data encrypt method. There are four types from low to high: none, WEP, WPA-PSK,
and WPA2-PSK.
1. None: No data encryption.
30 - User's Manual
