Physical description

Front panel
Built-in Microphone
Connectors
Power cord socket
Indented reset button
General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input / output devices. The pin definitions are described below.
4 - User's Manual
Lens
Status LED
RESET
Privacy button
P
Ethernet 10/100
RJ45 socket
ETHERNET
IO
1 2 3 4
General I/O
terminal block
1: Power
2: Digital output
3: Digital input
4: Ground
