Event Settings
In the Event column, click Add to open the event setting page. In this page, you can arrange the
three elements -- Trigger, Schedule and Action to plot an event. A total of three event settings
can be configured.
Event name: Enter a descriptive name for the event setting.
Enable this event: Select this option to enable this event setting.
Priority: Select the relative importance of this event (High, Normal, and Low). Events with higher priority
setting will be executed first.
Detect next event after
motion is detected.
An event is an action initiated by user-defined trigger source; it is the causal arrangement of the
following three elements: Trigger, Event Schedule, and Action.
Trigger: Also referred as the cause or stimulus, defines when to trigger the Network Camera. The trigger
source can be configured to use the Network Camera's built-in motion detection mechanism or external
digital input devices.There are four choices of trigger sources:
■ Video motion detection
Select this option to allow the Network Camera to use the built-in motion detection mechanism as
a trigger source. To enable this function, you need to configure Motion detection first. For more
information, please refer to Motion detection on page 41 for details.
■ Periodically
Select this option to allow the Network Camera to trigger periodically for every other defined minute. At
most 999 minutes can be set.
■ Digital input
Select one of the Digital inputs to allow the Network Camera to use external digital input device as a
trigger source. Depending on your applications, there are choices of digital input devices on the market
48 - User's Manual
seconds: Enter the duration in seconds to pause motion detection after a
