  • Page 1 Radioline - Wireless transmission system for serial interfaces and I/O signals User manual UM EN RAD-...-IFS...
  • Page 2 RAD-2400-IFS 2901541 RAD-868-IFS 2904909 RAD-2400-IFS-JP 2702863 I/O extension modules: RAD-AI4-IFS 2901537 RAD-PT100-4-IFS 2904035 RAD-AO4-IFS 2901538 RAD-DI4-IFS 2901535 RAD-DI8-IFS 2901539 RAD-DOR4-IFS 2901536 RAD-DO8-IFS 2902811 RAD-DAIO6-IFS 2901533 PHOENIX CONTACT GmbH & Co. KG • Flachsmarktstraße 8 • 32825 Blomberg • Germany phoenixcontact.com...

  • Page 3: Table Of Contents

    Diagnostics on the wireless module ..............44 Diagnostics via PSI-CONF software ..............49 Starting up I/O extension modules............... 52 4.10 Startup time of the wireless station ..............54 Serial data mode ........................55 Frame-based data transmission ................57 3 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 4 Free space attenuation ..................139 8.11 Propagation of radio waves ................141 8.12 Fresnel zone...................... 144 8.13 Range........................ 146 8.14 Equivalent isotropically radiated power (EIRP) ..........147 8.15 System calculation in free space ............... 148 4 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 5 10 Technical data for the wireless modules ................159 Technical appendix.........................171 Typical combinations of antennas and adapter cables ........171 Control box for wireless systems ............... 184 Appendixes..........................185 List of figures ..................... 185 List of tables ...................... 189 Index........................191 5 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 6 RAD-...-IFS 6 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 7: For Your Safety

    The use of products described in this manual is oriented exclusively to electrically skilled persons or persons instructed by them. The users must be familiar with the relevant safety concepts of automation technology as well as applicable standards and other regulations. 7 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 8: Field Of Application Of The Product

    Operation of the wireless system is only permitted if accessories available from Phoenix Contact are used. The use of other accessory components could invalidate the op- erating license. You can find the approved accessories for this wireless system listed with the product at phoenixcontact.net/products.
  • Page 9 Modifications to hardware and firmware of the device are not permitted. Incorrect operation or modifications to the device can endanger your safety or damage the device. Do not repair the device yourself. If the device is defective, please contact Phoenix Contact. 9 / 198 105542_en_05...

  • Page 10: Installation Notes

    The device complies with the EMC regulations for industrial areas (EMC class A). When used in residential areas, the device may cause radio interference. • Only specified devices from Phoenix Contact may be connected to the 12-pos. S-PORT interface. •...

  • Page 11: Installation In Zone 2

    The antennas are intended for use in potentially explosive areas that require 1G equipment. Connection is via antenna barriers (Order No. 2702198) with separate approval as intrinsically safe equipment. • Observe the safety notes in the documentation for the respective antenna. 11 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 12: Notes For Individual I/O Extension Modules

    These devices are open-type devices that are to be installed in an enclosure suitable for the environment that is only accessible with the use of a tool. WARNING - Exposure to some chemicals may degrade the sealing properties of ma- terials used in relays within this device. 12 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 13: Fcc, Industry Canada, Ift Mexico (Rad-2400-Ifs Only)

    To reduce potential radio interference to other users, the antenna type and its gain should be so chosen that the equivalent isotropically radiated power (EIRP) is not more than that permitted for successful communication. This device contains: IC certificate: 4720B-RAD2400A 13 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 14 19 dBi. Use of this equipment with antennas not included in this list or having a higher gain than 19 dBi is prohibited. The required antenna impedance is 50 ohms. Certificate number: IFT RCPPHRA17-1112 – Antennas: see table “2.4 GHz antennas” 14 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 15: Brief Description

    – Installation in Ex Zone 2 (RAD-2400-IFS and RAD-868-IFS only) – Can be combined with RS-485 stations The RAD-RS485-IFS RS-485 front module is not described in this user manual. For additional information, visit phoenixcontact.com/product/2702184. 15 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 16: Firmware Versions

    Support for RAD-DI8-IFS and 1.40 1.00 RAD-DO8-IFS I/O extension modules Support for RAD-PT100-4-IFS 1.50 1.00 Support for ETSI EN 300328: V1.8.1 1.60 Support for RAD-RS485-IFS 1.70 1.70 RS-485 front module PLC / Modbus/RTU dual mode 1.80 1.80 16 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 17: I/O Extension Modules

    RAD-DI4-IFS 2901535 8 digital inputs or 2 pulse inputs RAD-DI8-IFS 2901539 4 digital relay outputs RAD-DOR4-IFS 2901536 8 digital transistor outputs RAD-DO8-IFS 2902811 Analog/ 1 analog input/output, 2 digital RAD-DAIO6-IFS 2901533 digital wide-range inputs/outputs 17 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 18: Application Examples

    RAD-...-IFS Application examples The Radioline system offers a wide range of application options. 18 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 19: Installation

    Status LED (RX/TX) for RS-232/485 serial interface LED bar graph for displaying the wireless signal strength ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 19 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 20: Basic Circuit Diagram

    2.4 GHz frequency band (e.g., WLAN, Bluetooth, microwave ovens). Otherwise, both the link quality and the data transmission speed will be re- duced. Figure 3-3 Radioline connection station with up to 32 I/O extension modules 20 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 21 Use a suitable screwdriver to release the locking mechanism on the snap-on foot of the device (see Figure 3-4, E). • Hold onto the device by the housing cover and carefully tilt it upwards. • Carefully lift the device off the DIN rail connector and the DIN rail. 21 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 22: Connecting The Cables

    ... 2.5 mm • Insert the wire with ferrule into the corresponding connection terminal block. • Use a screwdriver to tighten the screw in the opening above the connection terminal block. Tightening torque: 0.6 Nm. 22 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 23: Connecting The Power Supply

    Parallel supply via the screw terminal blocks and with a system power supply via the bus foot is not possible. – For redundant supply, you can connect a second MINI-SYS-PS 100-240AC/24DC/1.5 system power supply. 23 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 24: Serial Interfaces

    If several devices are connected to a single bus, the shield must be connected to each device (e.g., by means of clamps). – Connect the bus shield to a central PE point using short, low-impedance connections with a large surface area (e.g., by means of shield connection clamps). 24 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 25 Connect the single wires of the data cable to the COMBICON plug-in screw terminal block (Figure 3-1, item 10). • Make sure the signal assignment is correct. COMBICON D(B) + (4.2) D(B) D(A) - (4.1) D(A) RS-485 Figure 3-9 RS-485 interface pin assignment 25 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 26 If you are not sure whether the device to be connected is of DTE or DCE type, you can also measure the voltage. Measure the voltage between Tx and GND in the idle state: – Voltage of approximately -5 V: DTE device – Voltage of approximately 0 V: DCE device 26 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 27: Connecting The Antenna

    Please also observe the installation instructions for the antenna as well as Section “For your safety” on page 7. – For information on the transmission power, refer to “Transmission power” on page 39. S I+ S I- Figure 3-12 Connecting the antenna 27 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 28 RAD-...-IFS 28 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 29: Configuration And Startup

    In this case, remove the antennas, increase the distance between the devices and antennas or reduce the transmission power using the PSI-CONF software. 29 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 30 You can update the firmware using the PSI-CONF software. The device is reset to the de- fault settings after a firmware update. • In the device selection area, select “Wireless, RAD-2400-IFS” or “Wireless, RAD-868-IFS”. • Select “Update firmware”. 30 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 31: Operating Mode Of The Wireless Module

    You can therefore establish a wireless connection to other wireless modules without laborious programming (see “Setting the address of the wireless module using the thumb- wheel” on page 35 and “Setting the address of the extension modules via the thumbwheel” on page 53). 31 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 32 RX TX D(A) D(B) D(A) D(B) D(A) D(B) RS-485 RS-485 RS-485 Figure 4-2 I/O-to-I/O, wireless, and RS-485 The RAD-RS485-IFS RS-485 front module is not described in this user manual. For additional information, visit phoenixcontact.com/product/2702184. 32 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 33 Modbus memory map of the master wireless module. In addition, the diagnostic data from all wireless devices is stored here. You need to configure each wireless module using the PSI-CONF software (from page 38 onwards). 33 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 34 Radioline extension modules to the controller directly via the integrated RS-232 and RS-485 interface by means of wireless communication. You can also connect additional Modbus/RTU slaves in parallel. You need to configure each wireless module using the PSI-CONF software (from page 38 onwards). 34 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 35: Setting The Address Of The Wireless Module Using The Thumbwheel

    IDs from 1 ... 127 using the PSI-CONF software (see page 39). 868 MHz wireless modules: for additional information on the various RF bands in 868 MHz wireless systems, refer to “RF bands” on page 131. 35 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 36 Read-in has been completed when the DAT LED lights up once. The new pa- rameters are activated. • Remove the configuration stick from the wireless module. • Repeat this process for each individual wireless module in the network. 36 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 37: Copying The Device Settings Via A Memory Stick

    Insert the memory stick in the S-PORT of the wireless module. Parameter copying is started automatically. • Wait until the running light stops. The write process has been completed. • Remove the memory stick from the wireless module. 37 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 38: Configuration Via The Psi-Conf Software

    For additional information on the USB cable, please refer to the PACKB.RAD-CABLE- USB packing slip. The latest documentation can be downloaded via the product at phoenixcontact.net/product/2903447. • Install the software and the USB driver for the RAD-CABLE-USB cable. Follow the soft- ware wizard. 38 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 39 Observe the maximum permissible radiated transmission power at the antenna (EIRP, see Table 4-4 or Table 4-5). If necessary, reduce the device transmission power via the PSI-CONF software. The transmission power can be calculated as follows: Device transmission power + Antenna gain - Cable attenuation 39 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 40 Adherence to the Fresnel zone If you reduce the data transmission rate, obstacles such as walls or trees can be penetrated much better. Please note, however, that the delay time increases when the data rate is reduced. 40 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 41 Configuration and startup Figure 4-8 PSI-CONF software: “Wizard, Step 3” Figure 4-9 PSI-CONF software: setting the data transmission rate 41 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 42 PSI-CONF software. You can assign a device name or set the transmission power under “Device Settings”. All device parameters are listed on the “Overview” tab. Figure 4-10 PSI-CONF software: “Individual Settings, Overview” 42 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 43 Repeater chains are used to circumvent obstacles or to set up redundant wireless paths by means of several repeaters. The “Allowed Parents” tab is only available if the “Line/Mesh” network type has been selected. Figure 4-12 PSI-CONF software: “Individual Settings, Allowed Parents” 43 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 44: Diagnostics On The Wireless Module

    Double assignment of I/O MAP address (e.g., two input modules with the same I/O MAP address) – RAD ID changed – No Modbus communication Fast (2.8 Hz) Wireless connection interrupted Local bus error, e.g., input or output module not read 44 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 45 In this case, remove the antennas, increase the dis- tance between the devices and antennas or reduce transmission power using the PSI-CONF software (from page 38 onwards). 45 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 46 LINK LINK LINK LINK ~1.0 V LED bar graph - running light The running light from bottom to top indicates: – Firmware update or – Wireless module in write mode for the memory stick 46 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 47 For example, the RSSI voltage may be helpful when positioning and aligning the antenna. The recommended minimum signal strength is 1.5 V DC. This results in a power reserve of around 10 dB, which ensures communication even in unfavorable transmission conditions. 47 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 48 This is why only the yellow bar graph LED lights up for the master. You can read the RSSI values via the serial interface of the master wireless module using Modbus/RTU commands (see Section “RSSI signal and error code registers” on page 82). 48 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 49: Diagnostics Via Psi-Conf Software

    Missing input module – Missing output module – Double assignment of I/O MAP address – Error on IFS bus – Wireless connection interrupted – RAD ID changed – Configuration stick has not yet been inserted 49 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 50 The “I/O Status” tab displays the status and the current values of the connected I/O extension modules. Figure 4-17 PSI-CONF software: “Diagnostic, I/O Status” The “Serial Port” tab displays the parameters currently set for the RS-232/RS-485 interface. Figure 4-18 PSI-CONF software: “Diagnostic, Serial Port” 50 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 51 Select a storage location. Click on “Start Recording”. Diagnostic data is now written to a CSV file which can be opened with Excel, for example. Figure 4-20 PSI-CONF software: “Record diagnostic data, Network diagnose” 51 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 52: Starting Up I/O Extension Modules

    I/O MAP address. +24 V RSSI RSSI OFF ON DIP-1 RX TX D(A) D(B) +24 V RSSI RSSI OFF ON DIP-1 RX TX D(A) D(B) Figure 4-22 RAD-DAIO6-IFS assignment: analog/digital inputs and outputs 52 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 53 Interface system slave address, for use with other interface system master devices (IFS) The following conditions must be met: – Addresses 1 ... 99 (maximum) can be assigned for the extension modules in the entire wireless network. 53 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 54: Startup Time Of The Wireless Station

    Accordingly, a complete wireless station with 32 I/O extension modules may take several minutes to start up. Only after this time has elapsed is the wire- less station ready for operation. 54 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 55: Serial Data Mode

    When operating the network in serial data mode, it may not be possible to diagnose all devices. In this case, stop the serial application in order to perform full diagnostics. – Using the PSI-CONF software, you can assign different serial settings to the devices under “Individual Settings”. 55 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 56 Once you have performed all the steps in the wizard, you can save the project and transfer it to the wireless modules. Figure 5-2 PSI-CONF software: “Wizard, Step 3” Figure 5-3 PSI-CONF software: “Wizard, Step 4” 56 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 57: Frame-Based Data Transmission

    Otherwise the frame might be frag- mented. Frame 1 Frame 2 NOT OK Idle Idle Idle FrameEnd FrameEnd Figure 5-5 Frame-based data transmission: T parameter FrameEnd 57 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 58: Setting Telegram Pauses Based On The Example Of Modbus/Rtu

    Verified parameters for frame-based data transmission Manufacturer Product Protocol [bit] [bit] IdleMin FrameEnd PROFIBUS Modbus/RTU Phoenix Contact EMPro Modbus/RTU Phoenix Contact SOLAR- Modbus/RTU CHECK Delta RPI-M20A Modbus/RTU Not all of the I/O devices available on the market are verified. In this case, the parameters must be determined by tests based on the connected I/O device and on the protocol.

  • Page 59: Plc / Modbus/Rtu

    RESET RAD-ID RAD-ID 1.1 2.1 1.1 2.1 1.1 2.1 1.1 2.1 Modbus-Register RX TX RX TX D(A) D(B) D(A) D(B) Modbus/RTU- RAD-Repeater/Slave Master Modbus-Slave 1 RAD-Master Figure 6-1 Configuration example: PLC / Modbus/RTU mode 59 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 60 None, even, odd None Number of stop bits 1; 2 Number of data bits Modbus address 1 ... 247 You can monitor the Modbus connection between the controller and the wireless module via a watchdog. 60 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 61 D(A) D(A) D(B) +24V RSSI+ +24V +24V RSSI+ RX TX D(A) D(A) D(A) RX TX DIP-1 RX TX RX TX MESH Network Channel 3 MESH Network Channel 5 Figure 6-3 Monitoring of oil pumps 61 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 62: Plc / Modbus/Rtu Dual Mode

    C=0,1Wh/imp Modbus-Register Output RS485 13 15 17 RX TX RX TX D(A) D(B) D(A) D(B) Modbus/RTU- Master Modbus-Slave 1 Modbus-Slave 4 Modbus-Slave 5 RAD-Repeater/Slave RAD-Master Figure 6-4 Configuration example: PLC / Modbus/RTU dual mode 62 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 63 None, even, odd None Number of stop bits 1; 2 Number of data bits Modbus address 1 ... 247 You can monitor the Modbus connection between the controller and the wireless module via a watchdog. 63 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 64 I/O transmission. Dual mode allows for economic implementation with only one wireless system. +24V 0V +24V RSSI+ RSSI– RSSI+ RSSI– SI– RX TX RX TX Ethernet Modbus Digital OUT Figure 6-6 Access control with door opener 64 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 65: Watchdog

    If the watchdog is activated and Modbus communication interrupted, the red ERR LED will flash on all wireless modules in the network. Depending on the DIP switch settings, the out- put modules issue the corresponding hold or reset value. 65 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 66: Modbus Function Codes

    Function codes 03 and 16 You must enter 0031 (hex001F) as the start address in order to read or write registers 40032 ... 40039. Address range 4xxxx is already defined by the function code field. 66 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 67: Module Type And Error Code Registers For I/O Extension Modules

    Modbus registers. The read I/O data is only valid and up to date if a valid module type value is returned by the slave and the “timeliness of data” register value is 0. 67 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 68: Modbus Memory Map

    -100 dBm -95 dBm -90 dBm -85 dBm -80 dBm ≥2.0 V LED 1 -110 dBm -105 dBm -100 dBm -95 dBm -90 dBm ≥1.5 V LINK LED LINK LINK LINK LINK LINK ~1.0 V 68 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 69 30xx1 Reserved 30xx2 Analog input 1 (terminal point 2.x) 30xx3 Analog input 2 (terminal point 3.x) 30xx4 Analog input 3 (terminal point 4.x) 30xx5 Analog input 4 (terminal point 5.x) 30xx6 ... 30xx9 Reserved 69 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 70 30xx1 Reserved 30xx2 Pt100 input 1 (terminal point 2.x) 30xx3 Pt100 input 2 (terminal point 3.x) 30xx4 Pt100 input 3 (terminal point 4.x) 30xx5 Pt100 input 4 (terminal point 5.x) 30xx6 ... 30xx9 Reserved 70 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 71 40xx1 Reserved 40xx2 Analog output 1 (terminal point 2.x) 40xx3 Analog output 2 (terminal point 3.x) 40xx4 Analog output 3 (terminal point 4.x) 40xx5 Analog output 4 (terminal point 5.x) 40xx6 ... 40xx9 Reserved 71 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 72 Modbus table, but is no longer updated. If the module type in the register is invalid or not available, then the register value is 0. 30xx1 Digital inputs DI4 DI3 DI2 DI1 Terminal point 30xx2 ... 30xx9 Reserved 72 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 73 In this case, the IN process data is re- tained in the Modbus table, but is no longer updated. If the module type in the register is invalid or not available, then the register value is 0. 73 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 74 30xx6 ... 30xx9 Reserved 40xx1 Reset of counter states DI1/DI7 Bit 1 = 1: counter state DI7 reset to 0 Bit 0 = 1: counter state DI1 reset to 0 40xx2 ... 40xx9 Reserved 74 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 75 0. The value then remains 0 for the entire operating time of the device. If the module type in the register is invalid or not available, then the register value is 0. 40xx1 Digital outputs Terminal point 40xx2 ... 40xx9 Reserved 75 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 76 Short-circuit detection at the digital outputs Reserved Bit 1 = 1: short circuit detected at one output or several outputs 5 ... 8. Bit 0 = 1: short circuit detected at one output or several outputs 1 ... 4. 76 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 77 This is the case, for example, if the wireless connection fails. The IN process data is retained in the Modbus table, but is no longer updated. If the module type in the register is invalid or not available, then the register value is 0. 77 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 78 30xx1 Digital inputs DI2 DI1 Terminal point 30xx2 Analog input (terminal point 3.x) 30xx3 ... 30xx9 Reserved 40xx1 Digital outputs Terminal point 40xx2 Analog output (terminal point 4.x) Terminal point 40xx3 ... 40xx9 Reserved 78 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 79 X X X X X X X X X X X X X X X X Counter state DI7 (high word) 30 xx 5 X X X X X X X X X X X X X X X X 30xx6 ... 30xx9 reserved 79 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 80 X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X X 30xx6 ... 30xx9 reserved 40xx6 ... 40xx9 reserved 80 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 81 Example for reading temperature T1 (I/O MAP = 02): function code 04, start address 21 (hex15) ......30 99 0 40 99 0 81 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 82 Value 255 means that the RSSI value is invalid or the device cannot be reached. Example for reading the RSSI register of the station with RAD ID = 2: Function code 04, start address 5001 (hex1389) 82 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 83: Error Codes And Formats For Analog Input And Output Values

    4 mA 4 mA 7530 30000 20 mA 20 mA 10 V 7F00 32512 21.67 mA 21.67 mA 10.84 V 8001 Overrange >21.67 mA >21.67 mA 8002 Open circuit <3.2 mA 8080 Underrange <0 mA 83 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 84: Radioline Function Blocks

    The Radioline function blocks are suitable for PC Worx, STEP 7 and TIA Portal. Thanks to modern wireless technology, I/O signals from distributed sensors and actuators can easily be integrated in a Phoenix Contact or Siemens controller. Figure 6-8 Function blocks for Radioline...
  • Page 85 PLC / Modbus/RTU 6.8.1 I/O integration in Phoenix Contact controllers Figure 6-9 I/O integration in PC Worx Required components: – Radioline front module – Radioline I/O extension modules – Inline or Axioline controllers – Inline or Axioline RS-485 communication module –...
  • Page 86 Inline or Axioline bus coupler – Inline or Axioline RS-485 communication module – S7-3xx, S7-12xx, S7-15xx controllers – TIA Portal or STEP 7 – STEP 7 function blocks – STEP_7_RadiolineBasic – STEP_7_comserial – STEP_7_Modbus 86 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 87: Description Of I/O Extension Modules

    Analog input 3 for 2, 3, 4-wire measuring transducers 5.1/5.2/5.3 Analog input 4 for 2, 3, 4-wire measuring transducers ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 87 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 88 0 mA ... 20 mA Analog IN2 4 mA ... 20 mA 0 mA ... 20 mA Analog IN3 4 mA ... 20 mA 0 mA ... 20 mA Analog IN4 4 mA ... 20 mA 88 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 89 Configuration and addressing mode Cyclic data communication ERR LED The red ERR LED indicates the error status. No error Flashing Slow (1.4 Hz) I/O MAP address changed Fast (2.8 Hz) No bus communication Critical internal error 89 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 90 The process image of the I/O extension module consists of six data words. For additional information, please refer to Section “RAD-AI4-IFS process data” on page 69. I/O module Module type ID Register Address range Function code RAD-AI4-IFS 30xx0 ... 30xx5 fc 04 90 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 91: Rad-Pt100-4-Ifs - Extension Module With Four Temperature Inputs

    At a temperature of 250°C at the Pt100 input, a current of 20 mA or a voltage of 10 V is issued at the output. Table 7-3 Pt100 input Pt100 input Analog output -50°C 0 mA or 0 V +250°C 20 mA or 10 V 91 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 92 +I and -I must have the same value. This allows you to subtract the measured cable resistance from the measurement result and to get the Pt100 platinum resistance value. IO-MAP ϑ U– I– µC Figure 7-6 3-wire connection technology 92 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 93 A = 0.25 mm  A = 0.5 mm  A = 1.0 mm  A = 1.5 mm (Measuring error valid for: copper cable χ = 57 m/Ωmm = 25°C, and Pt100 sensor) 93 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 94 Since there are two cable resistances in the measuring system, the value must be doubled. Using the average temperature coefficient α = 0.385 Ω/K for Pt100, the absolute measuring error in Kelvin can be determined for platinum sensors according to DIN. 94 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 95 Pt100 input 3 for 2 and 3-wire sensors 5.1/5.2/5.3 Pt100 input 4 for 2 and 3-wire sensors ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 95 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 96 For 2-wire connection technology, an insertion bridge is required between terminal blocks x.2 and x.3. In this case, the measuring accuracy is reduced (see “Measuring errors when using 2-wire connection technology” on page 93). 96 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 97 Configuration and addressing mode Cyclic data communication ERR LED The red ERR LED indicates the error status. No error Flashing Slow (1.4 Hz) I/O MAP address changed Fast (2.8 Hz) No bus communication Critical internal error 97 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 98: Rad-Ao4-Ifs - Analog Extension Module With Four Outputs

    The RAD-AO4-IFS analog I/O extension module can output up to four input signals with 0/4 mA ... 20 mA. All outputs are electrically isolated from one another, from the supply volt- age, and from the electronics. Use either the current or voltage output at every analog channel. 98 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 99 ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 7.3.2 Basic circuit diagram IO-MAP 0/4...20 mA 0...10V DC µC Figure 7-15 Basic circuit diagram for the RAD-AO4-IFS 99 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 100 Figure 7-16 DIP switches of the RAD-AO4-IFS Table 7-5 DIP switches of the RAD-AO4-IFS DIP switch Input Output signal RESET Analog OUT1 HOLD RESET Analog OUT2 HOLD RESET Analog OUT3 HOLD RESET Analog OUT4 HOLD 100 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 101 Wireless module in I/O data mode – Missing input module – No bus communication Wireless module in PLC / Modbus/RTU mode – No Modbus communication (safe state of outputs, depending on DIP switch setting) Critical internal error 101 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 102: Rad-Di4-Ifs - Digital Extension Module With Four Inputs

    0 V ... 50 V AC/DC at the low voltage input – 0 V ... 250 V AC/DC at the high voltage input All inputs are electrically isolated from one another, from the supply voltage, and from the electronics. 102 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 103: Figure 7-18 Rad-Di4-Ifs Structure

    ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 7.4.2 Basic circuit diagram IO-MAP 10...50V AC/DC µC 50...250V AC/DC Figure 7-19 Basic circuit diagram for the RAD-DI4-IFS 103 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 104: Figure 7-20 Diagnostic Leds Of The Rad-Di4-Ifs

    No error Flashing Slow (1.4 Hz) I/O MAP address changed Fast (2.8 Hz) No bus communication Critical internal error DI1 ... DI4 The yellow DI1 ... DI4 LEDs indicate the state of the digital inputs. 104 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 105 The process image of the I/O extension module consists of two data words. For additional information, please refer to Section “RAD-DI4-IFS process data” on page 72. I/O module Module type ID Register Address range Function code RAD-DI4-IFS 30xx0 ... 30xx1 fc 04 105 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 106: Rad-Di8-Ifs - Digital Extension Module With Eight Inputs

    Digital inputs 7 + 8, DI7: pulse input 2 Status LEDs for digital inputs DI1 ... DI8 CNT status LED, green (pulse counter mode) ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 106 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 107: Figure 7-22 Basic Circuit Diagram For The Rad-Di8-Ifs

    The pulse counter function is only available in PLC / Modbus/RTU mode and in dual mode. Set the operating mode using the PSI-CONF software (from page 35). Figure 7-23 DIP switches of the RAD-DI8-IFS 107 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 108 By setting the inputs • Set the corresponding input for at least 0.5 seconds: – Set input DI3 in order to reset counter state DI1. – Set input DI5 in order to reset counter state DI7. 108 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 109: Figure 7-24 Diagnostic Leds Of The Rad-Di8-Ifs

    The red ERR LED indicates the error status. No error Flashing Slow (1.4 Hz) I/O MAP address changed or mode switched using DIP switch 1, but not yet applied Fast (2.8 Hz) No bus communication Critical internal error 109 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 110 Function code 30xx0 ... 30xx1 fc 04 Static mode Static inputs 30xx0 ... 30xx5 fc 04 Pulse counter Pulse inputs RAD-DI8-IFS mode 40xx0 ... 40xx1 fc 03, 16 Pulse counter Reset of mode counter states 110 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 111: Rad-Dor4-Ifs - Digital Extension Module With Four Outputs

    6.1/6.2/6.3 Relay output 4 with floating changeover contact Status LEDs for relay outputs DO1 ... DO4 ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 111 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 112: Figure 7-26 Basic Circuit Diagram For The Rad-Dor4-Ifs

    Any changes to the DIP switch set- tings will be applied immediately. – RESET = output value is set to 0 – HOLD = hold the last output value OFF ON DIP-1 Figure 7-27 DIP switches of the RAD-DOR4-IFS 112 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 113: Figure 7-28: Diagnostic Leds Of The Rad-Dor4-Ifs

    The green PWR LED indicates the status of the supply voltage. No supply voltage Supply voltage OK DAT LED The green DAT LED indicates the status of bus communication. No communication Flashing Configuration and addressing mode Cyclic data communication 113 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 114 The process image of the I/O extension module consists of two data words. For additional information on the process data, please refer to Section “RAD-DOR4-IFS process data” on page 75. I/O module Module type ID Register Address range Function code RAD-DOR4-IFS 10 40xx0 ... 40xx1 fc 03, 16 114 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 115: Rad-Do8-Ifs - Digital Extension Module With Eight Outputs

    Terminal block 1.1 (12 V DC ... 30.5 V DC) – Terminal blocks 1.2/1.3 (GND) • Outputs DO5 ... DO8 are supplied via: – Terminal block 6.1 (12 V DC ... 30.5 V DC) – Terminal blocks 6.2/6.3 (GND) 115 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 116: Figure 7-29 Rad-Do8-Ifs Structure

    6.1/6.2/6.3 Supply voltage for outputs 5 ... 8 Status LEDs of transistor outputs DO1 ... DO8 ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 116 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 117: Figure 7-30 Basic Circuit Diagram For The Rad-Do8-Ifs

    Any changes to the DIP switch set- tings will be applied immediately. – RESET = output value is set to 0 – HOLD = hold the last output value Figure 7-31 DIP switches of the RAD-DO8-IFS 117 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 118: Figure 7-32 Diagnostics Leds Of The Rad-Do8-Ifs

    The green PWR LED indicates the status of the supply voltage. No supply voltage Supply voltage OK DAT LED The green DAT LED indicates the status of bus communication. No communication Flashing Configuration and addressing mode Cyclic data communication 118 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 119 Setting the I/O MAP address for the RAD-DO8-IFS Thumbwheel Description 01 ... 99 I/O MAP address Delivery state **, 1* ... 9* Setting not permitted *1 ... *9 Interface system slave address, for use with other interface system (IFS) master devices 119 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 120: Rad-Daio6-Ifs - Analog/Digital Extension Module With Six Channels

    The analog output is designed as an active output. You can select a current signal of 0/4 mA ... 20 mA or a voltage signal of 0 V ... 10 V. Use either the current or voltage output at the analog output. 120 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 121: Figure 7-33 Rad-Daio6-Ifs Structure

    Status LEDs of digital outputs DO1 ... DO2 Status LEDs of digital inputs DI1 ... DI2 ERR status LED, red (communication error) DAT status LED, green (bus communication) PWR status LED, green (supply voltage) 121 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 122: Figure 7-34 Basic Circuit Diagram For The Rad-Daio6-Ifs

    RESET = output value is set to 0 – HOLD = hold the last output value Digital outputs – RESET = relay drops out – HOLD = hold the last valid state Figure 7-35 DIP switches of the RAD-DAIO6-IFS 122 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 123: Figure 7-36 Diagnostics Leds Of The Rad-Daio6-Ifs

    The green PWR LED indicates the status of the supply voltage. No supply voltage Supply voltage OK DAT LED The green DAT LED indicates the status of bus communication. No communication Flashing Configuration and addressing mode Cyclic data communication 123 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 124 Section “RAD-DAIO6-IFS process data” on page 77. I/O module Module type ID Register Address range Function code 30xx0 ... 30xx2 fc 04 (inputs) RAD-DAIO6-IFS 60 40xx0 ... 40xx2 fc 03, 16 (outputs) 124 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 125: Planning Wireless Systems

    Distance and set data rate of the wireless interface The lower the data rate via the wireless interface, the higher the delay time. – Data encryption If data encryption is activated, the delay time increases. 125 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 126 I/O data mode: the telegram length depends on the number of I/O extension modules. Serial data mode: the telegram length depends on the protocol used and the terminal devices that are connected to the serial interface. 126 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 127: Pulse Transmission

    The Modbus register can be read and written by any PLC via Modbus/RTU. Trusted Wireless 2.0 Phoenix Contact has developed Trusted Wireless 2.0 technology specifically for industrial applications. Trusted Wireless 2.0 operates in the license-free 2.4 GHz or 868 MHz fre- quency bands.
  • Page 128 The higher the energy per bit, the greater the achievable range. The energy per bit results from the ratio between transmission power and data rate: energy per bit = transmission power / data rate 128 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 129: Figure 8-1 Penetration Of Obstacles At Different Frequencies

    The maximum transmission time is 10% of one hour (6 minutes). Usually, the duty cycle is not reached during operation, since only low volumes of data are transmitted. 129 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 130: Figure 8-2: Point-To-Point Connection, Star Network, Self-Healing Mesh Network

    This reduces the message traffic volume and speeds up data exchange. Parent-Child-Zone 1 Parent-Child-Zone 2.1 Parent-Child-Zone 2.2 M = Master R = Repeater S = Slave Parent-Child-Zone 3.1 Figure 8-3 Distributed network management with parent-child zones 130 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 131: Rf Bands

    19.2 kbps 9.6 kbps 120 kbps 1 RF band (fixed frequency) 2 RF bands 14 RF bands (fixed frequency) (frequency hopping spread spectrum method) Figure 8-5 RF bands in the 868 MHz wireless system 131 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 132: Planning Wireless Paths

    However, small obstacles in the Fresnel zone will not necessarily disturb com- munication. In general, obstacles in the way on long wireless paths have a greater influence than those on short ones. 132 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 133: Selecting Antenna Cables And Antennas

    In reflective environments the signal can be received via an indirect route. Directional antenna – Large distances – Point-to-point connections – Stationary or linear mobile applications – Multiple point-to-point paths, decoupling due to directivity and different polarization levels (see Figure 8-7) 133 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 134: Installing Antennas

    The partner antennas must therefore also be polarized vertically. Vertical polarization means that the elements are aligned vertically to the horizon. Crossing polarization between the stations results in signal loss (see Table 8-4). Figure 8-6 Antenna polarization 134 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 135: Figure 8-7: Decoupling Of Wireless Paths Due To Directivity And Different Polarization Levels

    If you operate several wireless paths directly next to one another in parallel, you can alternately align directional antennas horizontally and vertically. The signals of the various wireless paths will therefore be decoupled. Figure 8-7 Decoupling of wireless paths due to directivity and different polarization levels 135 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 136: Figure 8-8 Outdoor Installation Of Antennas

    DIP-1 DIP-1 RX TX D(A) D(B) IN AC 100-240V Figure 8-8 Outdoor installation of antennas Omnidirectional antenna Antenna cables Antenna mast Antenna surge protection Control cabinet Power supply, wireless module, and I/O extension modules 136 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 137: Level And Attenuation Of Wireless Modules And Accessories

    Antenna cable - EF393 RAD-CAB-EF393-3M N(m) 2867649 -1.8 dB -1 dB RAD-CAB-EF393-5M N(m) 2867652 -2.9 dB -1.6 dB RAD-CAB-EF393-10M N(m) 2867665 -5.6 dB -2.9 dB 10 m RAD-CAB-EF393-15M N(m) 2885634 -8.3 dB -4.3 dB 15 m 137 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 138 2 dBi 2.4 GHz directional antenna ANT-DIR-2459-01 N(f) 2701186 9 dBi RAD-ISM-2400-ANT-PAR-19-0 N(f) 2867885 19 dBi 868 MHz directional antenna ANT-DIR-868-01 N(f) 2702137 3.5 dBi RAD-ISM-900-ANT-YAGI-6.5-N N(f) 2867814 8.5 dBi RAD-ISM-900-ANT-YAGI-10-N N(f) 5606614 12 dBi 138 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 139: Free Space Attenuation

    1000 m -100 dB -91.2 dB 2000 m -97.2 dB 3000 m -100.7 dB 4000 m -103.2 dB 5000 m -105.1 dB 6000 m -106.7 dB 7000 m -108.1 dB 8000 m -109.2 dB 139 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 140 = transmission frequency in MHz d = distance between the antennas in km The free space attenuation is later included in the system calculation (see Section “Equiva- lent isotropically radiated power (EIRP)” on page 147). 140 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 141: Propagation Of Radio Waves

    In certain applications, the reflection may have a positive effect, e.g., if there is no line of sight. Reflections mainly occur in buildings. Figure 8-11 Reflection on a metal surface 141 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 142: Figure 8-12 Reduction Of Radio Waves When Penetrating A Wall

    Forest, 1 m, see 8.16 “Practical 9 ... 14 4 ... 8 examples” Heat-absorbing glass with metal 40 ... 50 30 ... 40 coating Figure 8-12 Reduction of radio waves when penetrating a wall 142 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 143: Figure 8-13 Angle Of The Transmitter And Receiver

    It can only receive reflections or diffracted waves. +24 V 0 V RSSI+ RSSI- RX TX D(A) D(B) +24 V 0 V RSSI+ RSSI- RX TX D(A) D(B) Figure 8-14 Radio dead spot 143 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 144: Fresnel Zone

    They contribute to a good wireless connection even if the Fresnel zone is not free from obstacles. The following figure shows the Fresnel zone between two antennas. The required mounting height for the antennas depends on the radius of the Fresnel zone. 144 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 145: Figure 8-16 Fresnel Zone

    Radius of the Fresnel zone for 2.4 GHz and d = 3000 m: r = 9.68 m Result: the radius of the Fresnel zone is 9.68 m at a wavelength of 0.125 m (2.4 GHz) and a distance of 3000 m between the antennas. 145 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 146: Range

    Outside buildings, with a free line of sight 120 kbps 4 km 60 kbps 5 km Omnidirectional antenna, 4 dBi 19.2 kbps 8 km 9.6 kbps 9 km 1.2 kbps 11 km 146 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 147: Equivalent Isotropically Radiated Power (Eirp)

    Maximum of 19 dBm in Europe, depending on the set transmission rate – For 868 MHz: – Maximum of 27 dBm • If the maximum EIRP is exceeded, adapt the cable, adapter or transmission power, if necessary. 147 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 148: System Calculation In Free Space

    System reserve = |-96 dB| - |-67.7 dB| = 28.3 dB 28.3 dB > 10 dB Conclusion: The loss of -67.7 dB is significantly lower than the receiver sensitivity of -96 dB. The desired wireless connection is therefore possible in mathematical terms. 148 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 149: Practical Examples

    5 cm to 20 cm. In our test, the 2.4 GHz wireless signal was transmitted through a 25 m forest. The attenuation was around 40 dB. At 868 MHz, the attenuation is around 22 dB. Figure 8-19 Forest with an attenuation of around 40 dB 149 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 150 RAD-...-IFS 150 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 151: Detecting And Removing Errors

    On a slave or repeater, it is only possible to read the RSSI voltage of the connected wireless module. For more information on the RSSI voltage, please refer to Table 4-7 and Table 4-8. 151 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 152 The data of the I/O extension modules is read again. connector and the bus. ERR flashing Writing to the memory stick did • Repeat the process in order to correctly write to the memory stick. DAT flashing not work. 152 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 153 1 m in the horizontal direction or 0.6 m in the vertical direction). • Make sure that the power supply is sufficiently high. • Make sure that there is no connection between the core and the shield of the cable in the connected antenna system. 153 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 154 Example: the yellow thumb- • If necessary, set the correct RAD ID and press the SET button. wheel setting has accidentally been modified and the modifica- tion has not yet been confirmed via the SET button. 154 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 155 • Check the serial interface settings (baud rate, parity, data bits, and stop bits) for the wireless modules and serial terminal devices (from page 38 onwards). 155 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 156 • Reset the wireless module to the default settings (I/O data mode, see page 30), if necessary. Critical internal error • Please contact Phoenix Contact technical support. ERR on Example: technical defect I/O MAP address changed • Check the I/O MAP address setting on the white thumbwheel of the I/O extension module.

  • Page 157: Loopback Test During Serial Data Transmission

    Connect the PC to the master wireless module. Start HyperTerminal via “Start, All Pro- grams, Accessories, Communication, HyperTerminal”. The COM port settings on the PC must correspond to the interface settings on the master wireless module. 157 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 158: Figure 9-1 Loopback Test On An Rs-232 Interface

    If the characters only appear once, check the HyperTerminal settings for hidden outgoing characters. The following options must be enabled under “File, Proper- ties, Settings, ASCII Setup”: “Echo typed characters locally” and “Append line feeds to incoming line ends” Figure 9-2 Settings in HyperTerminal 158 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 159: 10 Technical Data For The Wireless Modules

    (30.5 V DC / 200 mA) I/O extension module, 2 digital inputs and outputs RAD-DAIO6-IFS 2901533 (0 ... 250 V AC/DC) and 1 analog input (0/4 ... 20 mA) and output (0/4 ... 20 mA, 0 ... 10 V) 159 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 160 Omnidirectional antenna, 2.4 GHz, gain: 6 dBi, polariza- RAD-ISM-2400-ANT-OMNI-6- 2885919 tion: linear, opening angle: h/v 360°/30°, degree of protec- tion: IP67, seawater-resistant, connection: N (female), including mounting bracket and mast clips, ATEX and IECEx approval 160 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 161 Directional antenna 868 MHz/900 MHz, gain: 12 dBi, RAD-ISM-900-ANT-YAGI-10- 5606614 polarization: linear, opening angle: h/v 56°/46°, degree of protection: IP65, connection: N (female), including mounting bracket and mast clips 161 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 162 2 x N (female), ATEX and IECEx approval Antenna splitter, frequency range: 0.3 GHz ... 6 GHz, RAD-SPL-2-N/N 2702293 degree of protection: IP65, connection: 3 x N (female), corresponding connecting cable for antenna connection (Order No. 2700677) 162 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 163 Control box for robust setup of wireless systems for indus- FL RUGGED BOX 2701204 trial applications, IP65, 25 x 18 x 13 cm, polycarbonate material, gray, drilled, including DIN rail, plugs, and screw connections, without devices 163 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 164 ≤99 (I/O extension modules per wireless network, serial inter- face deactivated) Serial data mode 0 (no I/O extension modules can be used) PLC / Modbus/RTU mode ≤99 (access to I/O extension modules via Modbus/RTU proto- col) 164 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 165 COMBICON plug-in screw terminal block Connection technology 2-wire Data rate 0.3 kbps ... 187.5 kbps Transmission length ≤1200 m Termination resistor (can be switched on via DIP 390 Ω / 150 Ω / 390 Ω switches) 165 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 166 -40°F ... 185°F Permissible humidity (operation) 20% ... 85% Permissible humidity (storage/transport) 20% ... 85% Altitude 2000 m Vibration (operation) According to IEC 60068-2-6: 5g, 10 Hz ... 150 Hz Shock 16g, 11 ms 166 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 167 IFT Mexico IFT RCPPHRA17- 1112 UL, USA/Canada UL 508 Listed, Class I, Div. 2, Groups A, B, C, D T4A Class I, Zone 2, IIC T4 Noxious gas test ISA-S71.04-1985 G3 Harsh Group A 167 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 168 EN 60950 safety Health - limitation of exposure of the population to electro- EN 62311 magnetic fields Radio - effective use of the frequency spectrum and avoid- EN 300328 EN 300220 ance of radio interference 168 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 169 Otherwise, please observe the following restrictions. Individual operating conditions available on request! RAD-DAIO6-IFS (2901533): Do not use the analog loop power output (PWR1). Only use the analog voltage output (U1). Do not use more than two of the four possible digital inputs and outputs. 169 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 170 Maximum switching current: 1 A per channel RAD-AI4-IFS (2901537): Make sure that no more than 40 mA in total is drawn from loop power outputs ... PWR RAD-AO4-IFS (2901538): Only use the analog voltage output (0 V ... 10 V). 170 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 171: A Technical Appendix

    Omnidirectional antenna, 2 dBi Item Product Description Connection Order No. RAD-ISM-2400-ANT-OMNI-2-1- Omnidirectional antenna, 2.4 GHz, 2 dBi gain, RSMA (male) 2701362 RSMA 1.5 m cable length, linear vertical polarization, h/v 360°/75° opening angle, IP65 protection 171 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 172: Figure A-2: Omnidirectional Antenna With Protection Against Vandalism, 3 Dbi

    RAD-ISM-2400-ANT-VAN-3-0- Omnidirectional antenna with protection RSMA (male) 2701358 RSMA against vandalism, 2.4 GHz, 3 dBi gain, IP55 protection, 1.5 m cable length, h/v 360°/85° opening angle Appropriate mounting material is available for wall mounting. 172 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 173: Figure A-3: Omnidirectional Antenna, 2.5 Dbi

    2.5/5 dBi gain, linear vertical polarization, opening angle: h/v 360°/30° for 2.4 GHz, h/v 360°/16° for 5 GHz, IP68 N (female)  RAD-PIG-EF316-N-RSMA Adapter cable, 50 cm pigtail, 50 Ω impedance 2701402 RSMA (male) 173 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 174: Figure A-4: Omnidirectional Antenna, 6 Dbi, Without Surge Protection

    Alternative: RAD-PIG-RSMA/N-1 Antenna cable, 1 m length 2903264 RAD-PIG-RSMA/N-2 Antenna cable, 2 m length N (male)  2903265 RSMA (male) RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266 RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140 174 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 175: Figure A-5: Omnidirectional Antenna, 6 Dbi, With Surge Protection

    Alternative: RAD-PIG-RSMA/N-1 Antenna cable, 1 m length 2903264 RAD-PIG-RSMA/N-2 Antenna cable, 2 m length N (male)  2903265 RSMA (male) RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266 RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140 175 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 176: Figure A-6: Directional Antenna, 9 Dbi, With Outdoor Surge Protection

    Alternative: RAD-PIG-RSMA/N-1 Antenna cable, 1 m length 2903264 RAD-PIG-RSMA/N-2 Antenna cable, 2 m length N (male)  2903265 RSMA (male) RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266 RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140 176 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 177: Figure A-7: Parabolic Antenna, 19 Dbi, With Outdoor Surge Protection

    Alternative: RAD-PIG-RSMA/N-1 Antenna cable, 1 m length 2903264 RAD-PIG-RSMA/N-2 Antenna cable, 2 m length N (male)  2903265 RSMA (male) RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266 RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140 177 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 178: Figure A-8: Omnidirectional Antenna, 4 Dbi, With Surge Protection

    Antenna cable, 10 m length 2867665 N (male) RAD-CAB-EF393-15M Antenna cable, 15 m length 2885634 N (female)  CN-LAMBDA/4-2.2-BB Attachment plug with LAMBDA/4 technology 2800024 as surge protection for coaxial signal interfaces N (female (opt.) 178 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 179: Figure A-9: Directional Antenna, With Surge Protection

    25 mm ... 85 mm diameter, stainless steel, ATEX and IECEx approval Alternative: RAD-ISM-900-ANT-YAGI-6.5-N Yagi antenna, IP65, 8.5 dBi gain, 0.6 m cable 2867814 length N (female) RAD-ISM-900-ANT-YAGI-10-N Yagi antenna, IP65, 12 dBi gain, 0.6 m RG-213 5606614 cable 179 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 180 Alternative: RAD-PIG-RSMA/N-1 Antenna cable, 1 m length 2903264 N (male)  RAD-PIG-RSMA/N-2 Antenna cable, 2 m length 2903265 RSMA (male) RAD-PIG-RSMA/N-3 Antenna cable, 3 m length 2903266 RAD-PIG-RSMA/N-5 Antenna cable, 5 m length 2702140 180 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 181: Figure A-10: Directional Antennas, 8 Dbi, With 2-Way Outdoor Antenna Splitter

    IP67, including mounting bracket and mast clips for 25 mm ... 85 mm diameter, stainless steel, ATEX and IECEx approval Or other directional antennas from Phoenix Contact FL LCX PIG-EF142-N-N Antenna cable, 50 cm length, 50 Ω impedance N (male) 2700677 ...

  • Page 182: Figure A-11: Antenna Installation In Zone 2

    OUT DC 24V 1.5A +24 V 24V 0V 0V RSSI RSSI OFF ON OFF ON OFF ON DIP-1 DIP-1 DIP-1 RX TX D(A) D(B) IN AC 100-240V Figure A-11 Antenna installation in Zone 2 182 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 183 ATEX and IECEx approval ANT-OMNI-868-01 Omnidirectional antenna, 868 MHz, gain: 2702136 4 dBi, polarization: linear, opening angle: h/v 360°/30°, degree of protection: IP67, seawa- ter-resistant, including mounting bracket and mast clips, ATEX and IECEx approval 183 / 198 105542_en_05 PHOENIX CONTACT...

  • Page 184: A 2 Control Box For Wireless Systems

    Mounting example with a 35 mm power supply and five 17.5 mm devices and terminal blocks Power supply MINI-SYS-PS-100-240AC/24DC/1.5 1500 mA Load Wireless module 65 mA RAD-DAIO6-IFS 95 mA RAD-DI4-IFS 11 mA RAD-DOR4-IFS 55 mA RAD-DI8-IFS 18 mA RAD-DO8-IFS 22 mA RAD-AI4-IFS 120 mA RAD-AO4-IFS 115 mA 184 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 185: Appendixes

    PSI-CONF software: “Diagnostic, Serial Port” ........50 Figure 4-19: PSI-CONF software: “Diagnostic, Network settings” ......51 Figure 4-20: PSI-CONF software: “Record diagnostic data, Network diagnose” ..51 Figure 4-21: Assignment of digital inputs and digital outputs ........52 185 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 186 Figure 7-14: RAD-AO4-IFS structure ..............99 Figure 7-15: Basic circuit diagram for the RAD-AO4-IFS ........99 Figure 7-16: DIP switches of the RAD-AO4-IFS ............ 100 Figure 7-17: Diagnostic LEDs of the RAD-AO4-IFS ..........101 186 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 187 Figure 8-15: Wireless path with strong wind ............144 Figure 8-16: Fresnel zone ..................145 Figure 8-17: Free space attenuation ..............148 Figure 8-18: Bush with an attenuation of approximately 15 dB ......149 187 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 188 Directional antenna, with surge protection ........179 Figure A-10: Directional antennas, 8 dBi, with 2-way outdoor antenna splitter ..181 Figure A-11: Antenna installation in Zone 2 ............182 Figure A-12: Control box with wireless system ............184 188 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 189: B 2 List Of Tables

    Table 6-19: Representation of RAD-AO4-IFS analog values ........83 Table 6-20: Representation of RAD-DAIO6-IFS analog values ......83 Table 6-21: Representation of RAD-PT100-4-IFS Pt100 values......84 Table 7-1: DIP switches of the RAD-AI4-IFS............88 189 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 190 Ranges for different antennas at 2.4 GHz.......... 146 Table 8-10: Ranges for different antennas at 868 MHz......... 146 Table 9-1: Detecting and removing errors: wireless module ....... 152 Table 9-2: Detecting and removing errors: I/O extension module ....... 156 190 / 198 PHOENIX CONTACT 105542_en_05...

  • Page 191: B 3 Index

    Point-to-point connection ........48 Default settings ............29 Blacklisting..............128 Delay time ..............125 Brief description ............15 Diagnostics On the wireless module ......... 44 Via PSI-CONF software......... 49 Cable ..............133, 171 Checking the location..........132 191 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 192 I/O extension module RAD-DI8-IFS ............107 See Extension module RAD-DO8-IFS ............. 117 I/O integration RAD-DOR4-IFS........... 112 Phoenix Contact controller ........85 Wireless module............ 25 Siemens controller ..........86 Directional antenna ........... 133 I/O-MAP address ............53 Dispersion ..............141 RAD-DAIO6-IFS ............ 52 Distributed network management ......
  • Page 193 Pt100 value ..............84 RS-485 station ............32 Pulse counter mode ..........107 RSMA antenna socket ..........27 Pulse transmission ............ 127 RSSI signal register ............ 84 RSSI test socket ............47 RSSI voltage ............46, 151 193 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 194 Thumbwheel, white ............. 53 Thumbwheel, yellow ........... 35 TIA Portal ..............84 Troubleshooting ............151 UL notes..............12 USB cable ..............38 Watchdog..............61 Weather influences ........... 144 Well-pad monitoring system........61 Wind................144 194 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 195 Index 195 / 198 105542_en_05 PHOENIX CONTACT...
  • Page 196 RAD-...-IFS 196 / 198 PHOENIX CONTACT 105542_en_05...
  • Page 197 The receipt of technical documentation (in particular user documentation) does not constitute any further duty on the part of Phoenix Contact to furnish information on modifications to products and/or technical documentation. You are responsible to verify the suitability and intended use of the products in your specific application, in particular with regard to observing the applicable standards and regulations.
  • Page 198 Should you have any suggestions or recommendations for improvement of the contents and layout of our manuals, please send your comments to: tecdoc@phoenixcontact.com 198 / 198 PHOENIX CONTACT GmbH & Co. KG • Flachsmarktstraße 8 • 32825 Blomberg • Germany phoenixcontact.com...

This manual is also suitable for:

Rad-2400-ifsRad-868-ifsRad-2400-ifs-jpRad-ai4-ifsRad-pt100-4-ifsRad-ao4-ifs ... Show all

Table of Contents
