Phoenix Contact RAD-ISM-900-DATA-BD Quick Start Manual

RAD-ISM-900-DATA-BD
RAD-ISM-900-RS232-BD
Quick Start Guide 1945B

Features

• DIN-rail mountable
• All-in-one Master, Slave and Store-and-Forward
Repeater/Slave
• GUI and DIP switch confi guration
• Remote diagnostics avaiable via second port on radios,
and terminal windows in the GUI
• Dry contact LINK output as well as voltage output for
quick and easy fi eld RSSI wiring
• 1 watt transmit power
• Class I, Div. 2 approved for hazardous area installation
(UL, CUL, and CSA approved)

Description

The RAD-ISM-900-RS232-BD is a radio transceiver that
allows two-way communications via RS-232. The RAD-
ISM-900-DATA-BD is a radio transceiver that allows
two-way communications via RS-232, RS-485 and RS-
422. Modbus RTU and Allen Bradley DF1 protocols are
supported with assured communications in both radios,
which are programmed using the RAD-LINK software. Up
to 254 remote locations can be accessed by one Master
transceiver. The RAD-ISM-900 transceivers can be used on
the license-free 902-928MHz band and proven Frequency
Hopping Spread Spectrum technology designed for use in
high frequency environments.

Applications

• SCADA systems
• PC/PLC/RTU interface
• Pump controls
• Tank level/pressure/temperature monitoring
• Water/Wastewater
• Petro-chem
PHOENIX CONTACT • P.O. Box 4100 • Harrisburg, PA 17111 • Phone: (717) 944-1300 • Fax: (717) 944-1625
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12967-Phoenix-Contact-2867131-Radio-900-MHz-Serial-Data-Radio.aspx
INSPIRING INNOVATIONS
Figure 1. RAD-ISM-900-DATA-BD
p/n 2867131
Figure 2. RAD-ISM-900-RS232-BD
p/n 2867555
1
September 2006
