IHB EN 2004-1
531675
Ground source heat pump
NIBE F1245
INSTALLATION MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1245 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nibe F1245 Series

Summary of Contents for Nibe F1245 Series

  • Page 1 IHB EN 2004-1 INSTALLATION MANUAL 531675 Ground source heat pump NIBE F1245...
  • Page 2 Quick guide Navigation Ok button (confirm/select) Back button (back/undo/exit) Control knob (move/increase/reduce) A detailed explanation of the button functions can be found on page How to scroll through menus and make different settings is described on page Set the indoor climate INDOOR CLIMATE HOT WATER HEAT PUMP...

  • Page 3: Table Of Contents

    Technical specifications Heating medium side Energy labelling Cold and hot water Docking alternatives Item register 5 Electrical connections Contact information General Connections Settings Optional connections Connecting accessories 6 Commissioning and adjusting Preparations Filling and venting NIBE F1245 Table of Contents...

  • Page 4: Important Information

    Rights to make any design or technical modifications are reserved. The CE mark is obligatory for most products sold in the EU, regardless of where they are made. ©NIBE 2020. IPX1B Classification of enclosure of electro-technical equipment. Water may drip from the safety valve’s overflow pipe.

  • Page 5: Serial Number

    This unit contains a fluorinated greenhouse gas that is covered by the Kyoto agreement. The equipment contains R407C, a fluorinated green- house gas with a GWP value (Global Warming Potential) of 1,774. Do not release R407C into the atmosphere. NIBE F1245 Chapter 1 | Important information...

  • Page 6: Inspection Of The Installation

    Shut off valves Circulation pump setting Electricity (page Connections Main voltage Phase voltage Fuses heat pump Fuses property Outside sensor Room sensor Current sensor Safety breaker Earth circuit-breaker Setting of emergency mode thermo- stat Chapter 1 | Important information NIBE F1245...

  • Page 7: Delivery And Handling

    • Because water comes from F1245, the area where the heating pump is located must be equipped with floor drainage. 0 - 50 mm NIBE F1245 Chapter 2 | Delivery and handling...

  • Page 8: Supplied Components

    Twist the cover slightly outward. The kit of supplied items is placed in packaging on top Move the hatch outwards and backwards. of the heat pump. Assembly takes place in the reverse order. Chapter 2 | Delivery and handling NIBE F1245...

  • Page 9: Removing Parts Of The Insulation

    Grip the handle and pull the insulation carefully to- wards you as illustrated. Grip the handle and pull straight out as illustrated. NIBE F1245 Chapter 2 | Delivery and handling...

  • Page 10: The Heat Pump Design

    3 The heat pump design VIEW FROM ABOVE General QM22 QN10 W130 F1245 AA4-XJ4 VIEW FROM BEHIND AA4-XJ3 QM34 QM31 QM32 EP14-AA11 QM33 EP14 Chapter 3 | The heat pump design NIBE F1245...
  • Page 11 AA4-XJ4 Service outlet (No function) AA11 Motor module Immersion heater El. anode* Switch W130 Network cable for NIBE Uplink * Only heat pump with enamelled vessel. MISCELLANEOUS EP14 Cooling section Rating plate Type plate, cooling section Cable gland, incoming electricity...

  • Page 12: Distribution Boxes

    Immersion heater card Base card Input circuit board Extra relay circuit board Electrical anode board Miniature circuit-breaker FQ10 Temperature limiter/Emergency mode thermostat Only for F1145PC and F1245PC Only heat pump with enamelled vessel. Chapter 3 | The heat pump design NIBE F1245...
  • Page 13 MOTOR MODULE (AA11) 3X400 V 6-10 kW AA10 3x400V 12 kW FC10 AA10 ELECTRICAL COMPONENTS AA10 Soft-start card Miniature circuit-breaker FC10 Motor cut-out NIBE F1245 Chapter 3 | The heat pump design...

  • Page 14: Cooling Section (Ep14)

    BT14 BT12 BT17 BT10 BT15 XL21 AA100 EB10 XL20 BT11 12 kW GQ10 BT14 10 kW BT17 BT15 BT12 XL21 BT10 EB10 XL20 AA100 BT11 12 kW BT12 BT10 AA100 BT11 Chapter 3 | The heat pump design NIBE F1245...
  • Page 15 Temperature sensor, hot gas BT15 Temperature sensor, fluid pipe BT17 Temperature sensor, suction gas ELECTRICAL COMPONENTS AA100 Joint card EB10 Compressor heater COOLING COMPONENTS Evaporator Condenser GQ10 Compressor Drying filter Expansion valve NIBE F1245 Chapter 3 | The heat pump design...

  • Page 16: Pipe Connections General

    The overflow pipe must be at least the same size as the safety valve. The overflow pipe must be visible and its mouth must be open and not located close to electrical components. Chapter 4 | Pipe connections NIBE F1245...

  • Page 17: Dimensions And Pipe Connections

    Connection, hot water (XL6)/(XL7) Brine in/out ext Ø (mm) Connection, brine in (XL1)/(XL2) Heating medium (mm) Connection, brine out flow/return ext Ø (XL3)/(XL4) Cold/hot water Ø (mm) * Can be angled for side connection. NIBE F1245 Chapter 4 | Pipe connections...

  • Page 18: Brine Side

    F1245 and for example radiators, underfloor heating/cooling, fan convectors etc. • Install all required safety devices, shut-off valves (as close to the heat pump as possible), and supplied particle filter. Chapter 4 | Pipe connections NIBE F1245...

  • Page 19: Cold And Hot Water

    F1245. BUFFER VESSEL If the climate system volume is too small for the heat pump output, the radiator system can be supplemented with a buffer vessel, for example NIBE UKV. NIBE F1245 Chapter 4 | Pipe connections...
  • Page 20 TWO OR MORE CLIMATE SYSTEMS The installation can be supplemented with the exhaust In buildings with several climate systems that require air module NIBE FLM to provide ventilation recovery. different supply temperatures, the accessory ECS 40/ECS 41 can be connected. A shunt valve then •...

  • Page 21: Electrical Connections

    Cut the current with the circuit breaker before carrying out any servicing. Electrical installation and wiring must be carried out in accordance with the stipulations in force. NIBE F1245 Chapter 5 | Electrical connections...
  • Page 22 Removing the cover, base board Caution To remove the cover for the base board, the cover for the input circuit board must first be removed. Push the catch down. Angle out the cover and remove it. Chapter 5 | Electrical connections NIBE F1245...

  • Page 23: Connections

    Enclosed cable for incoming supply electricity is connected to terminal block X1 on the immersion heater board (AA1). All installations must be carried out in accordance with current norms and directives. AA1-X1 NIBE F1245 Chapter 5 | Electrical connections...
  • Page 24 The room sensor has a number of functions: Shows current room temperature in the display on F1245. Option of changing the room temperature in °C. Provides the option of fine-tuning the room temper- ature. Chapter 5 | Electrical connections NIBE F1245...

  • Page 25: Settings

    When the heat pump is set to emergency mode (SF1 The electric additional heat may be restricted depending is set to ) only the most necessary functions are activ- on the selected country. ated. NIBE F1245 Chapter 5 | Electrical connections...

  • Page 26: Optional Connections

    X4:13 (GND) on the input card (AA3). Use cable type LiYY, EKKX or similar. The example shows the connection of several F1245 . AA1-S2 The image shows the dip-switch (AA1-S2) in the factory setting, that is 6 kW. Chapter 5 | Electrical connections NIBE F1245...
  • Page 27 Connect the current sensors to a multi-core cable in an enclosure directly adjacent to the electrical distribution unit. The multi-core cable between the enclosure and F1245 must have a cable area of at least 0.5 mm². NIBE F1245 Chapter 5 | Electrical connections...
  • Page 28 Connect the cable to the input board (AA3) on terminal NIBE UPLINK block X4:1-4 where X4:1 is the common terminal block Connect the network connected cable (straight, Cat.5e for the three current sensors. UTP) with RJ45-contact (male) to RJ45 contact (female) Incoming electricity on the rear of the heat pump.
  • Page 29 Caution brine (NC). In systems with both underfloor heating and • pressure switch for climate system (NC). radiators, NIBE ECS 40/41 should be used for optimum operation. External activation of functions An external switch function can be connected to F1245 •...

  • Page 30: Connecting Accessories

    Instructions for connecting accessories are in the install- The common alarm is preselected at the factory. ation instructions provided for the respective accessory. See information at nibe.eu for the list of the accessories that can be used with F1245. Chapter 5 | Electrical connections NIBE F1245...
  • Page 31 AA3-X4 AA3-X4 are going to install. EB100 F1245 Accessories AA3-X4 AA9-X1 12V A B GND AA3-X4 F1245 Accessory card 1 AA5-X4 AA5-X4 -X10 Accessory card 2 AA5-X4 AA5-X4 -X10 NIBE F1245 Chapter 5 | Electrical connections...

  • Page 32: Commissioning And Adjusting Preparations

    If alternative 1 (level vessel) is used, open the valve under the level vessel (CM2). Venting Bleed the heat pump via a vent valve (QM22) and the rest of the climate system via their relevant vent valves. Chapter 6 | Commissioning and adjusting NIBE F1245...

  • Page 33: Start-Up And Inspection

    F1245, start it manually in menu 5.7. brackets refer to the menu number in the control sys- tem. If you want to read more about affected menus either consult the help menu or read the user manual. NIBE F1245 Chapter 6 | Commissioning and adjusting...
  • Page 34 When an accessory for passive cooling is used, the brine pump speed must be set in menu 5.1.9. Set the pump speed when the system has come into balance (ideally 5 minutes after compressor start). Chapter 6 | Commissioning and adjusting NIBE F1245...
  • Page 35 Pumpkapacitet, värmebärarsida för F1145/F1245 6kW. be replenished. Available pressure, kPa Tillgängligt tryck, kPa Electrical output, W Eleffekt, W P100% P80% 100% P60% P40% 0,05 0,10 0,15 0,20 0,25 0,30 0,35 0,40 0,45 Flöde l/s Flow l/s NIBE F1245 Chapter 6 | Commissioning and adjusting...

  • Page 36: Setting The Heating Curve

    Chapter 6 | Commissioning and adjusting NIBE F1245...
  • Page 37 If you need to adjust "min. flow line temp." and/or "max flow line temperature", you do this in other menus. Settings for "min. flow line temp.” in menu 1.9.3. Settings for "max flow line temperature” in menu 5.1.2. NIBE F1245 Chapter 6 | Commissioning and adjusting...

  • Page 38: Control - Introduction

    • confirm selections of sub menus/options/set values/page in the start guide. BACK BUTTON The back button is used to: • go back to the previous menu. • change a setting that has not been confirmed. Chapter 7 | Control - Introduction NIBE F1245...

  • Page 39: Menu System

    Display of temperature and other operating information and access to the alarm log. See information in the help menu or user manual. This menu is also set in the slave heat pump's limited menu system. NIBE F1245 Chapter 7 | Control - Introduction...
  • Page 40 This symbol indicates whether "holiday setting" is active in 4.7. This symbol indicates whether F1245 has contact with NIBE Uplink. This symbol indicates the actual speed of the fan if the speed has changed from the normal setting.
  • Page 41 To select another option: Mark the applicable option. One of the options is pre-selected (white). Press the OK button to confirm the selected option. The selected option has a green tick. NIBE F1245 Chapter 7 | Control - Introduction...
  • Page 42 (at the page number) has been marked. Press the OK button to skip between the steps in the start guide. If the start guide is left on this page it closes automatically in 60 min Chapter 7 | Control - Introduction NIBE F1245...

  • Page 43: Control - Menus

    Menu 3 - INFO 3 - INFO ** 3.1 - service info ** 3.2 - compressor info ** 3.3 - add. heat info ** 3.4 - alarm log ** 3.5 - indoor temp. log NIBE F1245 Chapter 8 | Control - Menus...
  • Page 44 * Accessories are needed. ** This menu is also set in the slave heat pump's limited menu system. Chapter 8 | Control - Menus NIBE F1245...

  • Page 45: Menu 4 - Heat Pump

    4 - HEAT PUMP 4.1 - plus functions 4.1.1 - pool * 4.1.2 - pool 2 * 4.1.3 - internet 4.1.3.1 - NIBE Uplink 4.1.3.8 - tcp/ip settings 4.1.3.9 - proxy settings 4.1.4 - sms * 4.1.5 - SG Ready 4.1.6 - smart price adap-...

  • Page 46: Menu 5 - Service

    ** This menu is also set in the slave heat pump's limited menu system. Go to the main menu and hold the Back button in for 7 seconds to access the Service menu. Chapter 8 | Control - Menus NIBE F1245...
  • Page 47 Climate systems 2 - 8 can- not be set to a higher max supply temperature than cli- mate system 1. Stainless NIBE F1245 Chapter 8 | Control - Menus...
  • Page 48 (ACCESSORY IS REQUIRED) normal and speed 1-4 Setting range: 0 – 100 % Set the speed for the five different selectable speeds for the fan here. Chapter 8 | Control - Menus NIBE F1245...
  • Page 49 For operation of brine pump with "fixed delta", select Setting range: 1 - 100 % "fixed delta" under "op. mode" and set the value between Default values: 30 % 2 and 10 °C. NIBE F1245 Chapter 8 | Control - Menus...
  • Page 50 (GP1) works towards is set here. dT at DOT is the difference in degrees between flow and return temperatures at dimensioned outdoor tem- perature. Chapter 8 | Control - Menus NIBE F1245...
  • Page 51 Controlled by relev- heating. The menu is only displayed if at least one slave ant heat pump. is connected to the master. Pool 1 NIBE F1245 Chapter 8 | Control - Menus...
  • Page 52 Here, you can set how many months should pass before the heat pump notifies that it is time to clean the filter in the exhaust air module. Chapter 8 | Control - Menus NIBE F1245...
  • Page 53 If the heat pump is connected to a climate system(s) for cooling, any condensation can take place in this/these. Check that "use in heating mode" has been selected for the climate system(s) that NIBE F1245 Chapter 8 | Control - Menus...
  • Page 54 This is to protect against excess temperatures in the solar tank. If the unit has an anti-freeze function, solar panel cooling and/or passive/active recharging you can activate them here. When the function has been activated, you can Chapter 8 | Control - Menus NIBE F1245...
  • Page 55 Default value: 1.0 mixing valve step delay Setting range: 10 – 300 s Default values: 30 s Make settings for the hot water comfort here. See the accessory installation instructions for function description. NIBE F1245 Chapter 8 | Control - Menus...
  • Page 56 1 – 4: Here, you select which exhaust air module(s) will be affected by which HTS unit(s). If two or more HTS units control an exhaust air module, the ventilation is adjusted base on the units’ average value. Chapter 8 | Control - Menus NIBE F1245...
  • Page 57 There must be a heating, cooling or hot water calculated cooling supply to prevent condensation on demand to start the compressor. pipes and components in the cooling system. See the Installer Manual for HTS 40 for function descrip- tion. NIBE F1245 Chapter 8 | Control - Menus...
  • Page 58 "start for addi- tion" in menus 4.9.2 to -80. When set under floor drying periods have stopped, reset the menus 4.2 and 4.9.2 as per previous settings. Chapter 8 | Control - Menus NIBE F1245...

  • Page 59: Service

    NOTE Servicing should only be carried out by persons with the necessary expertise. When replacing components on F1245 only replacement parts from NIBE may be used. EMERGENCY MODE NOTE The switch (SF1) must not be moved to "" or "...
  • Page 60 If, for example, the heating medium pump requires re- placing or the cooling module requires servicing, drain the heating medium side as follows: Close the shut-off valves to heating medium side (QM31) and (QM32). Chapter 9 | Service NIBE F1245...
  • Page 61 Remove the front cover Remove the cover for the cooling module. Loosen the venting screw (QM5) with a screwdriver. Hold a cloth around the screwdriver blade as a small amount of water may run out. NIBE F1245 Chapter 9 | Service...
  • Page 62 Switch off the heat pump and cut the power with the safety switch. Caution Remove the front cover according to the de- scription on page Disconnect the connectors (A) and (B) from the un- derside of the base card cabinet. Chapter 9 | Service NIBE F1245...
  • Page 63 When a USB memory is connected, a new menu (menu F1245 7) appears in the display. Menu 7.1 - update firmware update firmware7.1 QM34 QM32 start updating choose another file This allows you to update the software in F1245. NIBE F1245 Chapter 9 | Service...
  • Page 64 For the following functions to work the USB memory must contain files with software for F1245 from NIBE. The fact box at the top of the display shows information activated (always in English) of the most probable update that the interval update software has selected form the USB memory.
  • Page 65 USB memory. Via "recover settings" you reset all menu settings from the USB memory. Caution Reset of the menu settings from the USB memory cannot be undone. NIBE F1245 Chapter 9 | Service...

  • Page 66: Disturbances In Comfort

    “alarm” is visible in the display, the problem causing the alarm still remains. • Too low hot water setting. – Enter menu 2.2 and select a higher comfort mode. Chapter 10 | Disturbances in comfort NIBE F1245...
  • Page 67 1.9.1 "heating curve" needs adjusting down. This part of the troubleshooting chapter only applies if the NIBE FLM accessory is installed. • External switch for changing the room heating activ- • Not enough water in the water seal.
  • Page 68 • Choked water seal. – Check and adjust the condensation water hose. Chapter 10 | Disturbances in comfort NIBE F1245...

  • Page 69: Accessories

    This accessory is used to create a larger connection area EXHAUST AIR MODULE NIBE FLM under F1245. NIBE FLM is an exhaust air module designed to combine Part no. 067 152 recovery of mechanical exhaust air with ground source heating.
  • Page 70 Part no 067 064 different supply temperatures. SOLAR PACKAGE NIBE PV ECS 40 (Max 80 m²) ECS 41 (approx. 80-250 m²) Part no 067 287 Solar panel package, 3 - 24 kW, (10 - 80 panels), which is used to produce your own electricity.

  • Page 71: Technical Data

    Dimensions and setting-out coordinates * This dimension applies at 90° angle on the brine pipes (side connection). The dimension can vary approx. ±100 mm vertically as the brine pipes consist in part of flexible pipes. NIBE F1245 Chapter 12 | Technical data...

  • Page 72: Electrical Data

    1/2/3/4/5/6/7 (switchable to 2/4/6/9) Output, Brine pump 35 – 185 Output, Heating medium pump 7 – 67 Enclosure class IPX1B Equipment Compliant with IEC 61000-3-12 For Connection Design Purposes, Compliant with IEC 61000-3-3 technical requirements Chapter 12 | Technical data NIBE F1245...

  • Page 73: Technical Specifications

    600 x 620 x 1,800 Ceiling height 1,950 Weight complete heat pump (Cu / Rf / E) 230 / 210 / 245 240 / 220 / 255 245 / 225 / 260 260 / 240 / 275 NIBE F1245 Chapter 12 | Technical data...
  • Page 74 Text text bla bla Temperature, °C (enhet) Incoming brine temp, °C Flow pipe Return pipe 12 kW 3x400V Vattentemperatur Temperature, °C (°C) Incoming brine temp, °C Köldbärare in Framledning Flow pipe (°C) Returledning Return pipe Chapter 12 | Technical data NIBE F1245...

  • Page 75: Energy Labelling

    Energy labelling INFORMATION SHEET Supplier NIBE AB Model F1245-6 F1245-8 F1245-10 F1245-12 Temperature application °C 35 / 55 35 / 55 35 / 55 35 / 55 Declared load profile for water heating Seasonal space heating energy efficiency class, aver-...
  • Page 76 Daily energy consumption 7.78 Daily fuel consumption elec fuel Annual energy consumption 1,709 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden Chapter 12 | Technical data NIBE F1245...
  • Page 77 Daily energy consumption 7.60 Daily fuel consumption elec fuel Annual energy consumption 1,669 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE F1245 Chapter 12 | Technical data...
  • Page 78 Daily energy consumption 7.95 Daily fuel consumption elec fuel Annual energy consumption 1,745 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden Chapter 12 | Technical data NIBE F1245...
  • Page 79 Daily energy consumption 7.95 Daily fuel consumption elec fuel Annual energy consumption 1,745 Annual fuel consumption Contact information NIBE Energy Systems – Box 14 – Hannabadsvägen 5 – 285 21 Markaryd – Sweden NIBE F1245 Chapter 12 | Technical data...

  • Page 80: Item Register

    Master/Slave, 26 Drawing out the cooling module, 7 Miniature circuit-breaker, 21 Installation area, 7 Motor cut-out, 22 Removing parts of the insulation, 9 NIBE Uplink, 28 Removing the covers, 8 Optional connections, 26 Supplied components, 8 Outdoor sensor, 24 Transport, 7...
  • Page 81 Removing the cover, immersion heater circuit Motor cut-out, 22 board, 22 Removing the hatch, input circuit board, 22 NIBE Uplink, 28 Room sensor, 24 Settings, 25 OK button, 38 Standby mode, 25 Operation, 41 Temperature limiter, 21 Optional connections, 26...
  • Page 82 Component list electrical cabinets, 12 Component location cooling section, 14 Component location electrical cabinets, 12 Component locations, 10 List of components, 10 Transport, 7 Troubleshooting, 66 USB service outlet, 63 Use the virtual keyboard, 42 Working range heat pump, 74 Item register NIBE F1245...

  • Page 83: Contact Information

    Tel: +46 (0)433-27 3000 kuzmin@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
  • Page 84 WS version: a1 (working edition) Publish date: 2020-02-18 18:59 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.

This manual is also suitable for:

F1245-6F1245-8F1245-10F1245-12F1245pc seriesF1245pc-6 ... Show all
