Nibe F1245 Installer Manual

Ground source heat pump
Hide thumbs Also See for F1245:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Installer manual
NIBE™ F1245
Ground source heat pump
IHB GB 1110-2
431040

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F1245 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Nibe F1245

Summary of Contents for Nibe F1245

  • Page 1 Installer manual NIBE™ F1245 Ground source heat pump IHB GB 1110-2 431040...
  • Page 2 A detailed explanation of the button functions can be found on page 40. How to scroll through menus and make different settings is described on page 42. The mode for setting the indoor temperature is reached, when in the start mode in the main menu, by pressing the OK button twice.

  • Page 3: Table Of Contents

    Hot water heater Manage alarm Docking alternatives Troubleshooting 5 Electrical connections 11 Accessories General Connections 12 Technical data Settings Dimensions and setting-out coordinates Optional connections Technical specifications Connecting accessories Item register 6 Commissioning and adjusting NIBE™ F1245 Table of Contents |...

  • Page 4: Important Information

    This installer manual must be left with the customer. Caution This symbol indicates important information about what you should observe when maintaining your installation. This symbol indicates tips on how to facilitate using the product. Chapter 1 | Important information NIBE™ F1245...

  • Page 5: Inspection Of The Installation

    Safety valve Shut off valves Circulation pump setting Electricity (page 18) Fuses heat pump Fuses property Outside sensor Room sensor Current sensor Safety breaker Earth circuit-breaker Setting of emergency mode thermostat Miscellaneous Guarantee submitted NIBE™ F1245 Chapter 1 | Important information...

  • Page 6: Contact Information

    Tel: +43 (0)7662 8963-0 Fax: +43 (0)7662 8963-44 E-mail: mail@knv.at www.knv.at NIBE Wärmetechnik AG, Winterthurerstrasse 710, CH-8247 Flurlingen Tel: (52) 647 00 30 Fax: (52) 647 00 31 E-mail: info@nibe.ch www.nibe.ch Druzstevni zavody Drazice s.r.o, Drazice 69, CZ - 294 71 Benatky nad Jizerou Tel: +420 326 373 801 Fax: +420 326 373 803 E-mail: nibe@nibe.cz www.nibe.cz...

  • Page 7: Delivery And Handling

    The hatches do not need to be opened during ser- leant back 45 °. Note! Can be tail heavy. vice, all service on F1245 can be carried out from the front. Leave space between the heat pump and wall behind (and any routing of supply cables and pipes) to reduce the risk reproduction of any vibration.

  • Page 8: Supplied Components

    Remove the screws from the upper and lower edges. Twist the cover slightly outward. Move the cover backwards and slightly to the side. Pull the cover to one side. Pull the cover forwards. Chapter 2 | Delivery and handling NIBE™ F1245...

  • Page 9: Removing Parts Of The Insulation

    Remove the cover of the junction box according to the description on page 19. Grip the handle and pull the insulation carefully towards you as illustrated. Grip the handle and pull straight out as illustrated. NIBE™ F1245 Chapter 2 | Delivery and handling...

  • Page 10: The Heat Pump Design

    3 The heat pump design General View from behind View from above Chapter 3 | The heat pump design NIBE™ F1245...

  • Page 11: Pipe Connections

    Serial number plate UB 1 Cable gland, incoming electricity UB 2 Cable gland UB 3 Cable gland, rear side, sensor Designations in component locations according to standard IEC 81346-1 and 81346-2. NIBE™ F1245 Chapter 3 | The heat pump design...

  • Page 12: Electrical Cabinets

    Input circuit board Designations in component locations according to standard AA 8 Sacrificial anode card* IEC 81346-1 and 81346-2. FA 1 Miniature circuit-breaker FB 1 Motor cut-out** FD 1 Temperature limiter/Emergency mode thermostat Chapter 3 | The heat pump design NIBE™ F1245...
  • Page 13 ** 1x230 V, 3x230 V 6-10 kW, 3x400V 5 kW has auxiliary switch for motor cut-out. 3x400 V 6-12 kW Designations in component locations according to standard IEC 81346-1 and 81346-2. 3x230 V 6-8 kW 3x230 V 10 kW NIBE™ F1245 Chapter 3 | The heat pump design...

  • Page 14: Cooling Section

    Compressor heater Cooling components EP 1 Evaporator EP 2 Condenser GQ 10 Compressor HS 1 Drying filter QN 1 Expansion valve Designations in component locations according to standard IEC 81346-1 and 81346-2. Chapter 3 | The heat pump design NIBE™ F1245...

  • Page 15: Pipe Connections

    Pipe installation must be carried out in accordance with module, circulation pumps and a control system. F1245 is current norms and directives. F1245 can operate with a re- connected to the brine and heating medium circuits. turn temperature of up to 58 °C and an outgoing temperat- In the heat pump evaporator, the brine (water mixed with ure from the heat pump of 70 (65 °C with only the com-...

  • Page 16: Dimensions And Pipe Connections

    Insulate all indoor brine pipes against condensation. The level vessel must be installed as the highest point in the brine system on the incoming pipe before the brine pump (Alt. 1). * Can be angled for side connection. Chapter 4 | Pipe connections NIBE™ F1245...

  • Page 17: Heating Medium Side

    Connecting the climate system A climate system is a system that regulates indoor comfort with the help of the control system in F1245 and for example radiators, underfloor heating/cooling, fan convectors etc. Install all required safety devices, shut-off valves (as close to the heat pump as possible), and supplied particle filter.

  • Page 18: Docking Alternatives

    Ventilation recovery Docking alternatives The installation can be supplemented with the exhaust air F1245 can be connected in several different ways, some of module FLM to provide ventilation recovery. which are shown below. Pipes and other cold surfaces must be insulated with dif- Further option information is available at www.nibe.eu and...

  • Page 19: Under Floor Heating Systems

    If the climate system volume is too small for the heat pump information about connecting a ground water pump. output, the underfloor heating system can be supplemented with a buffer vessel, for example NIBE UKV. Pool Charging of the pool is controlled by the pool sensor. In the...

  • Page 20: Electrical Connections

    Disconnect the heat pump before insulation testing the house wiring. F1245 is not reconnectable between 1-phase and 3-phase, neither is it reconnectable between 3x230V and 3x400V. If the building is equipped with an earth-fault breaker, F1245 should be equipped with a separate one.

  • Page 21: Accessibility, Electrical Connection

    Cable lock Use a suitable tool to release/lock cables in the heat pump terminal blocks. Insert the screwdriver (A) and pry the catch carefully downwards (B). Angle out the cover and remove it. NIBE™ F1245 Chapter 5 | Electrical connections...

  • Page 22: Connections

    "Switch for external blocking of ad- Power connection dition and/or compressor" on page 24. F1245 must be installed via an isolator switch with a minim- Connecting external operating voltage for um breaking gap of 3mm. Minimum cable area must be di- the control system mensioned according to the fuse rating used.

  • Page 23: Room Sensor

    Room sensor Install the outside temperature sensor (BT1) in the shade on F1245 is delivered with a room sensor supplied (BT50). The a wall facing north or north-west, so it is unaffected by the room temperature sensor has up to three functions: morning sun.

  • Page 24: Settings

    The load monitor is not connected. NOTE Switch (SF1) must not be moved to " " or " " until F1245 has been filled with water. Otherwise the temperature limiter, thermostat, compressor and the immersion heater can be damaged. Chapter 5 | Electrical connections NIBE™...

  • Page 25: Power In Emergency Mode

    45 °C (for example radiators). 2 kW 4 kW 6 kW 9 kW 3x230V 2 kW 4 kW 6 kW 9 kW 1x230V 1 kW 2 kW 3 kW 4 kW 5 kW 6 kW 7 kW NIBE™ F1245 Chapter 5 | Electrical connections...

  • Page 26: Optional Connections

    If an external switch function or sensor is connected at the same time as the electric addition is operating, there to F1245, the function to use input or output must is a risk of the property's main fuse tripping. The heat pump be selected in menu 5.4, see page 62.

  • Page 27: Contact For Activation Of Fan Speed

    Switch for external blocking of heating In those cases external blocking of heat is used, this can be An external contact function can be connected to F1245 for connected to terminal block X6 on the input card (AA3), activation of one of the four fan speeds. The switch must which is positioned behind the front cover.

  • Page 28: Connecting Accessories

    NOTE Mark up any junction boxes with warnings for ex- ternal voltage. F1X45 Externt Caution The relay outputs can have a max load of 2 A (230 V AC) in total. Chapter 5 | Electrical connections NIBE™ F1245...

  • Page 29: Commissioning And Adjusting

    Start the filling pump. Fill until liquid enters the return pipe. Filling and venting the climate system Vent the brine system with venting valve on F1245. Close the valves on the filler connector. Filling Open the filling valve (external, not included with the 10.

  • Page 30: Start Guide

    The start guide ensures that the start-up is carried out cor- rectly and cannot be bypassed. The start guide can be started later in menu 5.7. Operation in the start guide Chapter 6 | Commissioning and adjusting NIBE™ F1245...

  • Page 31: System Settings

    Then the pump shifts to intermittent operation. Here you set the max. electrical output of the internal elec- trical addition in F1245 and the fuse size for the installation. You can use “10 days continuous" at start-up to Here you can also check which current sensor is installed on...

  • Page 32: Room Sensor Settings

    Clean the exhaust air module's air filter regularly, how often depends on the amount of dust in the ventilation air. Chapter 6 | Commissioning and adjusting NIBE™ F1245...
  • Page 33 External addition with shunt is then for example wood/oil/gas/pellet boiler. For the shunt you can set shunt amplification and shunt waiting time. See the accessory installation instructions for function de- scription. NIBE™ F1245 Chapter 6 | Commissioning and adjusting...
  • Page 34 Setting range: 0.5 - 10.0 °C Setting range: 15.0 - 70.0 °C Default value: 1.0 Default value: 22.0 °C You can use F1245 to cool the house during hot periods of stop temperature the year. Setting range: 15.0 - 70.0 °C min.
  • Page 35 This part of the start guide is only displayed if the alternative Here you can set how long F1245 is to wait before it returns is selected in a previous menu and the accessory is installed.

  • Page 36: Setting Time And Date

    26 Setting the heat curve Set the minimum temperature on the supply temperature to the climate system. This means that F1245 never calculates a temperature lower than that set here. If there is more than one climate system the setting can be made separately for each system.

  • Page 37: Setting Operating Mode

    You cannot deselect "compressor" in manual mode. "addition" is what helps the compressor to heat the accom- modation and/or the hot water when it cannot manage the whole requirement alone. NIBE™ F1245 Chapter 6 | Commissioning and adjusting...
  • Page 38 If no alarm action is selected, it can result in higher energy consumption in the event of an alarm. 29 Filling in the checklist Do not forget to fill in the checklist on page 3 and in the user manual. Chapter 6 | Commissioning and adjusting NIBE™ F1245...

  • Page 39: Post Adjustment And Venting

    F1245 8 kW Post adjustment and venting Tillgängligt tryck, kPa / Eleffekt, W Pump capacity diagrams, collector side To set the correct flow in the brine system the correct speed P100% must be set for the brine pump. The flow must have a temperature difference between brine P80% out (BT11) and brine in (BT10) of 2 - 5 °C when the system...
  • Page 40 F1245 8 and 12 kW Pump capacity diagrams, heating medium side Tillgängligt tryck, kPa Eleffekt, W To set the correct flow in the climate system the correct speed must be set for the heating medium pump in the dif- ferent operating conditions.

  • Page 41: Readjusting, Venting, Heat Medium Side

    If the room temperature is too low, increase "temperat- ure" (heating curve offset) in menu 1.1, one step. If the room temperature is too high, reduce "temperature" (heating curve offset) in menu 1.1, one step. NIBE™ F1245 Chapter 6 | Commissioning and adjusting...

  • Page 42: Control - Introduction

    The control knob can be turned to the right or left. You can: scroll in menus and between options. increase and decrease the values. change page in multiple page instructions (for example help text and service info). Chapter 7 | Control - Introduction NIBE™ F1245...

  • Page 43: Menu System

    3.1 that you should note. These two symbols indicate whether the compressor or addition is blocked in F1245. These can, for example, be blocked depend- ing on which operating mode is selected in menu 4.2, if blocking is scheduled in menu 4.9.5 or if an alarm has occurred that...

  • Page 44: Selecting Options

    To select another option: Mark the applicable option. One of the options is pre-selected (white). Press the OK button to confirm the selected option. The selected option has a green tick. Chapter 7 | Control - Introduction NIBE™ F1245...

  • Page 45: Setting A Value

    Turn the control knob until one of the arrows in the top left corner (at the page number) has been marked. Press the OK button to skip between the steps in the start guide. NIBE™ F1245 Chapter 7 | Control - Introduction...

  • Page 46: Control - Menus

    Set the temperature (with room sensors installed and activated): Setting range: 5 - 30 °C Default value: 20 Chapter 8 | Control - Menus NIBE™ F1245...
  • Page 47 If two settings conflict with each other a red exclamation mark is displayed at the end of the line. NIBE™ F1245 Chapter 8 | Control - Menus...
  • Page 48 Setting minimum permitted flow line temperature. room sensor settings Settings regarding the room sensor. cooling settings Settings for cooling. fan return time Fan return time settings in the event of temporary ventilation speed change. Chapter 8 | Control - Menus NIBE™ F1245...

  • Page 49: Heating Curve

    35 and 45 °C. your location, if the house has radiators or under floor heating and how well insulated the house is. Check the max temperature for your floor with your installer/floor supplier. NIBE™ F1245 Chapter 8 | Control - Menus...
  • Page 50 1.9.7) is used. Set the minimum temperature on the supply temperature Press the OK button to exit the setting. to the climate system. This means that F1245 never calculates a temperature lower than that set here. To read off a heating curve:...
  • Page 51 Menu 1.9.8 - point offset Here you can set how long F1245 is to wait before it returns to heating mode when the cooling demand has ceased or outdoor temp. point vice versa.
  • Page 52 "outdoor temp. point" is set to "-2" and "change in curve" is increased until the desired room tem- perature is maintained. Caution Wait 24 hours before making a new setting, so that the room temperature has time to stabilise. Chapter 8 | Control - Menus NIBE™ F1245...

  • Page 53: Menu 2 - Hot Water

    OK button. The time to the right displays the remaining time at the selected setting. When the time has run out F1245 returns to the mode set in menu 2.2. Schedule: The schedule to be changed is selected here.
  • Page 54 "operating time" decide how long the hot water circulation pump must run per operating instance. "downtime" decide how long the hot water circulation pump must be stationary between operating instances. Chapter 8 | Control - Menus NIBE™ F1245...

  • Page 55: Menu 3 - Info

    The information is on several pages. Turn the control knob Otherwise, if an exhaust air module (NIBE FLM) is installed, to scroll between the pages. the exhaust air temperature is shown.

  • Page 56: Menu 4 - Heat Pump

    Status information for the relevant menu can be found on perature and there is no hot water or heating requirement, the display to the right of the menus. F1245 starts pool heating. plus functions Settings applying to any installed extra Untick "activated"...
  • Page 57 You can select what icon should be visible when the door the same time. If there is only one requirement the heat to F1245 is closed. You can select up to 3 icons. If you select pump only works with that requirement.
  • Page 58 Setting range: -1000 – -30 Default value: -60 start addition Setting range: -2000 – -30 Default value: -400 diff. between additional steps Setting range: 0 – 1000 Default value: 100 Chapter 8 | Control - Menus NIBE™ F1245...
  • Page 59 Caution If the stop time is before the start time it means that the period extends past midnight. Scheduling always starts on the date that the start time is set for. NIBE™ F1245 Chapter 8 | Control - Menus...

  • Page 60: Menu 5 - Service

    ) to default values. forced control Forced control of the different components in the heat pump. start guide Manual start of the start guide which is run the first time the heat pump is started. Chapter 8 | Control - Menus NIBE™ F1245...
  • Page 61 Here you set the start and stop temperature of the hot water energy consumption in the event of an alarm. for the different comfort options in menu 2.2 as well as the stop temperature for periodic increase in menu 2.9.1. NIBE™ F1245 Chapter 8 | Control - Menus...
  • Page 62 Set the operating mode of the heating medium pump here. min. brine out auto: The heating medium pump runs according to the current operating mode for F1245. Setting range: -12 – 15 °C intermittent: The heating medium pump starts 20 seconds Default value: -8 °C...
  • Page 63 Default value: 10 h Here you set the max. electrical output of the internal elec- trical addition in F1245 and the fuse size for the installation. months btwn filter alarms Here you can also check which current sensor is installed on Setting range: 1 –...
  • Page 64 For more information about the different parts of the start If you want to receive an SMS message in the event of the guide, see page 28. alarm mark the box to the right of the telephone number. Chapter 8 | Control - Menus NIBE™ F1245...
  • Page 65 NOTE During floor drying the heating medium pump in 100% runs regardless of the setting in menu 5.1.10. NIBE™ F1245 Chapter 8 | Control - Menus...

  • Page 66: Service

    NOTE Switch (SF1) must not be moved to " " or " " until F1245 has been filled with water. Otherwise the temperature limiter, thermostat, compressor and the immersion heater can be damaged. Emergency mode is used in event of operational interference and in conjunction with service.

  • Page 67: Emptying The Brine System

    This is done by unscrewing the bleed screw on Screw in the venting screw (QM5). the highest radiator in the house. Start F1245 by setting the switch (SF1) to " " and check whether the circulation pump works. When the climate system is empty the requisite service can be carried out.

  • Page 68: Temperature Sensor Data

    The cooling module can be pulled out for service and trans- port. Caution The cooling module is easier to remove if it is drained first (see page 64). Weight of the cooling module Type (kW) Weight (kg) Chapter 9 | Service NIBE™ F1245...
  • Page 69 Disconnect the connector (C) from the immersion heater circuit board (AA1) using a screwdriver. Disconnect the connector (D) from the joint circuit board (AA100). Carefully pull out the cooling module. The cooling module is installed in reverse order. NIBE™ F1245 Chapter 9 | Service...

  • Page 70: Usb Service Outlet

    The fact box at the top of the display shows information (always in English) of the most probable update that the F1245 is equipped with a USB socket in the display unit. This update software has selected form the USB memory.
  • Page 71 Set the desired interval between loggings. Tick “activated". Mark “read log settings" and press the OK button. The present values from F1245 are saved in a file in the USB memory at the set interval until “activated" is un- ticked.

  • Page 72: Disturbances In Comfort

    Vent the climate system (see page 27). If the operational interference is not shown in the display the following tips can be used: Closed valves (QM20), (QM32)to the climate system. Open the valves. Chapter 10 | Disturbances in comfort NIBE™ F1245...
  • Page 73 Not enough water in the climate system. Top up the water in the climate system (see page 27). Low or a lack of ventilation This part of the fault-tracing chapter only applies if the NIBE FLM accessory is installed. Filter (HQ10) blocked.

  • Page 74: Accessories

    Extra shunt group ECS 40/ECS 41 An accessory card is required if step controlled addition (e.g. This accessory is used when F1245 is installed in houses with external electric boiler) or if shunt controlled addition (e.g. two or more different climate systems that require different wood/oil/gas/pellet boiler) is to be connected to F1245.

  • Page 75: Technical Data

    Dimensions and setting-out coordinates * This dimension applies at 90° angle on the brine pipes (side connection). The dimension can vary approx. ±100 mm in height as the brine pipes partially consist of flexible pipes. NIBE™ F1245 Chapter 12 | Technical data...

  • Page 76: Technical Specifications

    Refrigerant circuit Type of refrigerant R407C Volume Cut-out value pressostat HP 2.9 (29 bar) Difference pressostat HP -0.7 (-7 bar) Cut-out value pressostat LP 0.15 (1.5 bar) Difference pressostat LP 0.15 (1.5 bar) Chapter 12 | Technical data NIBE™ F1245...
  • Page 77 4.50 4.40 4.24 EN14511 0/45 Rated output 5.14 6.99 8.47 11.27 Electrical output 1.49 1.92 2.34 3.33 3.45 3.63 3.62 3.39 EN14511 Additional power 2/4/6/9 Electrical data Rated voltage 230V 3NAC 50 Hz NIBE™ F1245 Chapter 12 | Technical data...
  • Page 78 EN ISO 11203 at 0/35 and a distance of 1 m Pipe connections Brine ext diam. CU pipe Heating medium ext diam. CU pipes Hot water connection external diam Cold water connection external diam Chapter 12 | Technical data NIBE™ F1245...
  • Page 79 7 – 67 7 – 67 7 – 67 7 – 67 7 – 67 IP class IP 21 Refrigerant circuit Type of refrigerant R407C Volume Cut-out value pressostat HP 2.9 (29 bar) NIBE™ F1245 Chapter 12 | Technical data...
  • Page 80 Tap volume 40 °C at Lux comfort COP at Lux comfort Idle loss Lux comfort Dimensions and weight Width Depth Height 1800 Required ceiling height 1950 Weight complete heat pump Weight only cooling module Chapter 12 | Technical data NIBE™ F1245...
  • Page 81 (up to 70 °C) is obtained using the additional the power supplier before purchasing the equipment. heat. With feet dismantled the height is approx. 1930 mm. 12 kW 3x400V, 8-12 kW 1x230V °C °C Other °C °C NIBE™ F1245 Chapter 12 | Technical data...

  • Page 82: Item Register

    Troubleshooting, 70 Docking alternatives, 16 Extra electric hot water heater, 16 Heating medium side, 15 Free cooling, 16 Connecting the climate system, 15 Ground water system, 17 Helping the circulation pump to start, 65 Chapter 13 | Item register NIBE™ F1245...
  • Page 83 Removing parts of the insulation, 7 Removing the cover, base board, 19 Removing the cover, immersion heater circuit board, 19 Removing the covers, 6 Removing the hatch, input circuit board, 19 Room sensor, 21 NIBE™ F1245 Chapter 13 | Item register...
  • Page 84 Chapter 13 | NIBE™ F1245...
  • Page 85 NIBE™ F1245 Chapter 13 |...
  • Page 86 Chapter 13 | NIBE™ F1245...
  • Page 88 NIBE AB Sweden Hannabadsvägen 5 Box 14 SE-285 21 Markaryd info@nibe.se www.nibe.eu 431040...
