Chapter 3 — Starting Up

Switching On the Printer

Before switching on the printer, make the necessary connections, and
check that the printhead is engaged.
Switch on the power using the On/Off switch on the rear plate. The
"Power" control lamp on the front panel lights up when the power is on.
Wait for a few moments, while the printer loads the program and runs
some self-diagnostic tests:
Starting
After a short time, the printer is initialized. The progress of the initializa-
tion is indicated by an increasing number of colons on the lower line in
the display:
Initializing
:::
When the initialization is completed, a label is fed out. The following
message appears, indicating that the printer is ready for operation.
IPL 2.30
The message indicates the IPL version number.
16 EasyCoder PX6i User's Guide (IPL version)
