AXIS A8207-VE installation
Wire reader to Door Controller using Wiegand
Configuration in the
product's webpage
Reader protocol
Card types
Pin
Protocol
Wiegand
Beeper
Activate beeper
Input for beeper
3
Inputs used for LED control
1
Input for LED1
1
Color for each state
Color for state low
red
Color for state high
green
AUDIO
READER I/O 1
AUX
+MIC- +SPK-
- 12
IO
IO
IO
IO
V
3
4
5
6
- 3V
READER DATA 1
A- B+ A- B+ D0 D1
DC IN
DOOR IN 1 DOOR IN 2
- +
- IN1 - IN2
- IN3 - IN4
PoE+ Switch
READER I/O 2
- 12
IO
IO
IO
IO
IO
IO
7
8
9
10
V
1
2
READER DATA 2
A- B+ A- B+ D0 D1
LOCK
- H1 - H2
RELAY | PWR
12
24
-
*REL*
-
V
V
