WaterLogic WL2FLT Troubleshooting

Hide thumbs Also See for WL2FLT:

Download this manual

1. Red Heater & Compressor Power Switch won't light and the Red LED on the Front

won't light

2. Red Heater & Compressor Power Switch is lit but the red LED on the Front is not lit

3. Compressor Runs but does Not Chill

4. Compressor is Not Running

1. Red Heater and Compressor Power Switch won't light and the Red LED on the

Front won't light

Possible Reason

Circuit Breaker

Fuse is Blown

Defective / Loose Power Cord

Failed Socket - Power Line

Noise Filter, ElectroMagnetic

Interference filter (EMI)

Defective Red Heater &

Compressor Switch

WL2FLT Manual

POWER TROUBLESHOOTING INDEX

Check the Circuit Breaker

Replace Fuse

Check that Power Cord is properly plugged in. If it is properly

plugged in, use a different power cord to verify.

Replace Socket - Power Line Noise Filter, ElectroMagnetic

Interference filter (EMI)

Replace Red Heater & Compressor Switch

Solution

Page 41 – Revision 7-19-21

Need help?

Do you have a question about the WL2FLT and is the answer not in the manual?

Page 1 Failed Socket - Power Line Replace Socket - Power Line Noise Filter, ElectroMagnetic Noise Filter, ElectroMagnetic Interference filter (EMI) Interference filter (EMI) Defective Red Heater & Replace Red Heater & Compressor Switch Compressor Switch WL2FLT Manual Page 41 – Revision 7-19-21...
Page 2 Reduction of airflow into unit. to 4 inches). Low or lost refrigerant. Compressor is running very Counter Top should be 40 grams (1.41 ounces) hot. Tower should be 65 grams (2.29 ounces) Refrigerant recharge as necessary. WL2FLT Manual Page 42 – Revision 7-19-21...
Page 3 Disconnect the black and red terminal connectors; Compressor Starting Circuit Inspect the starter and overload relay for any defects. Replace components(s) as needed. Turn Red Heater & Compressor Switch on I = ON and retest compressor operation. WL2FLT Manual Page 43 – Revision 7-19-21...
