2. Setup (Fig. 4, pg. 9):
Note: If the Altronix Dashboard is being used for LINQ8PD(CB) setup, refer to
the Folder and Device configuration section in the Altronix Dashboard setup/user
manual. Click on [Setup] tab. The LINQ8PD(CB) setup page will open.
This page is used to configure all operating functions of the LINQ8PD(CB).
Field Name Description
Enter a descriptive name that will identify the location (building, company or campus) where the LINQ8PD(CB) installed.
A Site ID
The Site ID will appear in both the trap message and email notifications.
B Date/Time
Clicking on [Sync Date/Time with Computer], will set the LINQ8PD(CB) to the time of the host computer.
C LINQ8PD(CB) ID
Enter a descriptive name and/or location of the LINQ8PD(CB).
D PS2 Presence
From the pull down menu select No to disable PS2 if only one power supply is connected.
E Battery Presence
From the pull down menu select No if batteries are not connected. If batteries are not connected skip this section.
PS1/PS2 Amps/Voltage Limits (Fig. 5, pg. 9):
Field Name Description
Enter both the Voltage Limit High and Voltage Limit Low for the connected power supplies. If either of these
PS1/PS2 Voltage Limit
limits are exceeded an SNMP trap message and/or email notification will be generated.
Enter both the Amp Limit High and Amp Limit Low for the connected power supplies. If either of these limits
PS1/PS2 Amp Limit
are exceeded an SNMP trap message and/or email notification will be generated.
FACP Trigger (Fig. 6, pg. 9): From the pull down menu select either Wet or Dry.
Select Description
Wet Trigger Input voltage from the fire alarm signal circuit will disconnect all outputs programmed for FACP disconnect.
Dry Trigger A short or open on the supervised FACP input will disconnect all outputs programmed for FACP disconnect.
Input Function (Fig. 6, pg. 9): From the pull down menu select either Reset or Tamper.
Select Description
When using the FACP Interface with outputs set in latching mode the reset trigger input
Reset
is designated as the FACP manual release.
When the outputs are set in non-latching mode or the FACP interface is not being used
Tamper
the reset trigger input.
Output Reset Trigger (Fig. 6, pg. 9): From the pull down menu select either N.O. or N.C.
Select Description
N.O. Normally Open reset Trigger Input.
N.C. Normally Closed Trigger input.
Max Temp: The LINQ8PD(CB) will measure the ambient temperature of the enclosure it is mounted in. Entering a high temperature limit in Celsius,
if this limit is exceeded an SNMP trap message and/or email notification will be generated.
LINQ8PD/LINQ8PDCB
Fig. 4
Setup
Site ID: Enter Location
Enter ID
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
A
Update Site ID
C D
Update No No
PS2 Presence Battery Presence
B
Monday, Sept. 21 2015 [2:30 pm] Sync with computer
Minimize Minimize Others
E
Fig. 5
PS1 Volts High Limit 27.7
PS1 Volts Low Limit 4
PS1 Amps High Limit 3
PS1 Amps Low Limit 0
Fig. 6
FACP Trigger Dry
Input Function Reset
Output Reset Trigger N.C.
Max Temp 50
