SSL Status:
Certificate Status (Fig. 9b, pg. 11):
Message Descriptions
Certificate OK Valid SSL Certificate.
Bad Certificate Invalid SSL Certificate.
No Certificate A Valid SSL Certificate has not been loaded.
SSL State: The SSL of the LINQ8PD(CB) can be turned on and off by clicking [Turning SSL On/Turning SSL Off] button.
Change Username and Password:
Field Name Description
Username Enter the new Username (up to 32 characters) required to access the LINQ8PD(CB).
Password Enter the new Password (up to 32 alpha numeric characters) required to access the LINQ8PD(CB).
Confirm Password Re-enter the new Password.
Click [Save Username and Password] button, a dialog box with appear, "New settings have been applied" click "OK".
After saving, the new username and password will be active.
4. Event Log and Heartbeat Timer (Fig. 10, pg. 12):
Click [Event Log] tab.
The LINQ8PD(CB) event log will open.
This screen will display the event log along
with the heartbeat timer setup.
Event Log: The event log will display the
50 most recent events.
To update the Event Log click [Display/Refresh Log]
button, the most recent events will be displayed.
Heartbeat Timer: The heartbeat timer will send
a trap message indicating that the LINQ8PD(CB) is still connected and communicating.
5. Setting the Heart Beat Timer:
a. Click the button labeled Heartbeat Timer Setting.
b. Select the desired time between heartbeat messaging in the Days, Hours, Minutes and Seconds in corresponding fields.
c. Click the button labeled Submit to save setting.
6. Updating Firmware:
Firmware updates must be done using the Altronix Dashboard. For additional information refer to the Updating firmware / SSL certificate and Key section
in the Altronix Dashboard setup/user manual.
- 12 -
Key Status (Fig. 9b, pg. 11):
Message
Key OK
Bad Key
No Key
Fig. 10
Device Management Interface
Status Setup Network Settings Security Settings
Event Log
Site ID: LINQ8
Display/Refresh Log Heartbeat Timer Settings
Heartbeat Timer Settings:
1 Days 0 Hours 0 Minutes 0 Seconds
Available from A1 Security Cameras
www.a1securitycameras.com email: sales@a1securitycameras.com
Descriptions
Valid SSL Key.
Invalid SSL Key.
A valid SSL Key has not been loaded.
Events Log Help
Submit
v1.99.22
Monday, Sept. 21 2015 [2:30 pm]
Last updated:
LINQ8PD/LINQ8PDCB
