- Page 1 MOM5C Multi-Output Power Distribution Module for Access Control Installation Guide Altronix Corp. 140 58th St. Brooklyn, NY More than just power. Rev. 012100...
-
Page 2: Specifications
(Stand-by)] and negative to [NEG1] through [NEG5] (Fig. 7, pg. 6). 5. To trigger the MOM5C from a FACP connect signaling circuit of FACP to terminals marked [– INPUT +]. Polarity is shown in alarm condition. Connect the wires on opposite sides of the screw. -
Page 3: Terminal Identification
Under normal conditions terminals marked [NO and C] are open, POWER FAIL [NC and C] are closed. A loss of power causes terminals marked [NO and C] to close and [NC and C] to open. Contact rating 1A @ 28VDC. MOM5C - 3 -... -
Page 4: Typical Application Diagrams
INPUT FROM FACP INPUT FROM FACP OR ACCESS CONTROL DEVICE OR ACCESS CONTROL DEVICE Fig. 2 Two (2) or more MOM5C modules shown with wet and/or dry normally closed trigger inputs (Non-Latching): DC VOLTAGE INPUT FROM FACP SIGNALING OUTPUT OR ACCESS (--) CONTROL DEVICE EOL 2.2K... - Page 5 NORMALLY CLOSED (NC) OPEN (NO) RESET RESET Fig. 5 Two (2) MOM5C modules shown with wet and/or dry normally closed fire alarm trigger inputs (Latching with Manual Reset): DC VOLTAGE INPUT FROM FACP SIGNALING OUTPUT OR ACCESS (--) CONTROL DEVICE EOL 2.2K...
- Page 6 FACP MOM5 2.2K EOL TRIGGER INPUT POS (+) DC OUTPUT (ALARM) 2.2K TRIGGER INPUT TRIGGER POWER NC C NO NC C NO MAG LOCK ON LED DRY OUTPUT POWER FAIL POS (+) DC OUTPUT (STANDBY) (FAIL-SAFE) - 6 - MOM5C...
- Page 7 Notes: MOM5C - 7 -...
- Page 8 (133.35mm) (25.4mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A. MEMBER IIMOM5C E22R - 8 -...
