How to use Side-Power thrusters ..........24 Warranty statement .............. 25 Spareparts list & drawing ..........26 - 27 DECLARATION OF CONFORMITY SAMSVARSERKLÆRING Sleipner Motor AS Sleipner Motor AS P.O. Box 519, Arne Svendsensgt. 6-8 P.O. Box 519, Arne Svendsensgt. 6-8 N-1612 Fredrikstad, Norway...
Drain port Copyright All rights reserved Copyright All rights reserved Title Title Hyd. motor 16 ccm Hyd. motor 16 ccm 1 1/4" BSP 1/4" BSP SLEIPNER MOTOR AS Weight SLEIPNER MOTOR AS SLEIPNER MOTOR AS Part nr Size Scale Edition Sheet 1 1/4"...
The required time delay is 1 second. NB ! Faulty installation of the tunnel, thruster or panel will render all warranty given by Sleipner Motor AS void. Tools list for mechanical installation: - Hole Drill –...
Fig. 1 Pivot point important B = 10,0m A = 11,0m Fig. 2 Ø MG_0001 Positioning of the tunnel / thruster MC_0003 The thruster should be as far forward as possible (Fig. 1) Due to the leverage eff ect around the boats’ pivot point, it is essential for the thrusters to be placed as far forward as possible. The relative distance diff erence from the boat pivots’...
Page 8
Water flow must have space to "straighten" itself for best Ensure the top and bottom tunnel lengths are respectable performance. lengths from one another. It is important the propeller never extrudes from the tunnel ends. Cavitation STANDARD USE FLAT BOTTOM HULL HIGH-SPEED OPERATION Increase tunnel length to prevent...
Fig. 1 Pos. A Pos. B MG_0004 Tunnel installation in sailboats MC_0003 Many sailboats have a racing hull which means that it can have a very fl at bottomed and a very shallow draft in the bow section. It is thereby challenging to fi t a tunnel thruster the usual way, fi tted as far forward in the hull as the thruster should be (Fig.
Fig. 1 Fig. 2 Fig. 3 Fig. 4 High water force while underway High water force while underway from wave contact MG_0003 Water Defl ection MC_0003 A possible problem in sailboats or fast powerboats is that a non-rounded surface can generate drag from the back face of the tunnel, as it creates a “fl at”...
Fig. 1 Fig. 2 R = 0,1 x D (10%) R = 0,1 x D (10%) Fig. 3 Fig. 4 MG_0002 Tunnel ends MC_0003 Rounded tunnel ends will maximise thrust and minimise noise. We recommend rounding the tunnel connection to the hull-side as much as possible. The optimum rounding has a radius of 10% of the diameter of the tunnel.
Fig. 1 Fig. 2 Fig. 3 Fig. 4 MG_0005 Tunnel installation MC_0003 IMPORTANT We recommend that a professional does the fi breglass fi tting of the tunnel. These instructions are only general instructions and do not explain in any way the details of fi breglass work. Problems caused by faulty installation of the tunnel, are the installers full responsibility. Find the position in the boat considering the information earlier in this manual and the applicable measurements for the thruster model you are installing.
Page 13
Fig. 1a Fig. 1c Fig. 1 Fig. 1b Fig. 1d Fig. 3 Fig. 2 R = D x 0,1 R = D x 0,1 MG_0006 Tunnel installation MC_0003 With tunnel installed and cast (Fig. 1) round off the edges with a radius of 10% of the tunnel diameter (Fig. 1a) or make a slope with a length of 10-15% of the tunnel diameter (Fig.
Fitting gearhouse and motor bracket Montering av girhus og brakett Mark the centerline of the tunnel and the boats centerline. Marker båtens og tunnelens senterlinje på tunnelen. Fig.1. Use a template or gearhouse gasket to mark the centre of Bruk en mal eller girhus- pakning for å markere midten the holes and double check the measurements.
Page 16
SH1000_manual_2016 Fitting gearhouse and motor bracket Montering av girhus og brakett Snapshot SH 1000 & SH1400 Fig. 1 Fig. 3 Sealant on both sides of gearleg gasket IMPORTANT! Sealant and primer used on the gasket must be compat- ible with tunnel, gasket and gearleg material.
SH 700 Holding key Propeller Tab washer Anode & pin bolts Lock nut IMPORTANT Shaft and propeller taper must be 100% clean before assembling. Apply mounting oil before assmebling propeller to shaft. Tighten to 200Nm IMPORTANT Propeller assembly with locking washer and anode: Ensure propellers marked LH are installed - Grease up the surface (A) between the propeller and propeller nut (B).
Page 18
Fig. 1 SH 1000 & SH1400 IMPORTANT! Shaft and propeller taper must be 100% clean before assembling. Apply mounting oil before assmebling propeller to shaft. Fig. 2 Tighten to 400Nm Side marked "P" Side marked "S" facing PORT facing STARBOARD Propeller Propeller marked LH...
Page 19
Propeller assembly with locking washer and anode: - Grease up the surface (A) between the propeller and propeller nut (B). - Tigthen the propeller nut (B) to given torque without the washer (C) between - Remove the propeller nut (B) from the treads/shaft (D) - Grease up the washer (C) at both sides - Re-tighten the propeller nut (B) with the washer (C) included - Lock the washer (C) into the propeller nut (B)
10: Hydraulic motor 5. Fasten the adaptor plate firmly to the bracket with the Der Gummiring muß sich dabei ganz in den oberen Teil der SLEIPNER MOTOR AS provided screws. Tighten the screws with a torque of 33 Nm elastischen Kupplung schieben.
>0,2 x d Waterline Tunnel center line i a l i a l Fitting oil tank Montering av oljebeholder 1. Fit the oil tank (1) above the waterline by at least 20% of the 1. Plasser oljebeholderen (1) over vannlinjen, minst 20% av distance from the waterline to the centre of the tunnel.
SH1000_manual_2016 Hydraulic motor Mounting plate Motor bracket for holding motor and gear leg together on the tunnel. 1.16 Snapshot Flexible coupling secures the motor if propeller is jammed. Changeable from inside the boat. Bronze Q-propeller for ultimate performance.
Checklist (only for thruster) Sjekkliste (Kun truster) Propellen er festet til akselen på korrekt vis. Propeller is fastened correctly to the shaft. Propellen roterer fritt i tunnel. Propeller turns freely in tunnel. Girhuset er fylt med korrekt olje. Lower-unit is filled with gearoil.
Important user precautions Viktige brukerforebehold • Always turn the control device off when the thruster is not in • Skru alltid av kontrollpanelet etter bruk. use. • Bruk aldri thrusteren når noen er i vannet, thrusteren vil • Never use a thruster close to somebody in the water, as the trekke gjenstander til seg og kontakt med propellen vil volde thruster will draw objects close by into the tunnel and contact alvorlig skade.
Warranty statement 1. The equipment manufactured by Sleipner Motor AS (The “Warrantor”) is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years (Leisure Use) or one year (Commercial use) from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period.
Spareparts SH1000/513TC In order to present the most up to date documentation, we advise you to go to our website www.side-power.com and locate your product to find relevant spare parts. SH700/412 & SH1000/513TC & SH1400/610TC...
Page 27
Spareparts SH1400/610TC In order to present the most up to date documentation, we advise you to go to our website www.side-power.com and locate your product to find relevant spare parts. SH700/412 & SH1000/513TC & SH1400/610TC...
Page 28
SERVICE SH700/412 & SH1000/513TC & SH1400/610TC...
Page 32
SLEIPNER MOTOR AS P.O. Box 519 N-1612 Fredrikstad Norway The information given in the document was correct at the time it was published. However, Sleipner Motor AS can not accept liability for any inaccuracies or omissions it may contain. Continuous product improvement may change the product specifications without notice. Therefore, Sleipner Motor AS can not accept liability for any pos-...
