Summary of Contents for SLEIPNER MOTOR AS Side-Power
- Page 1 P.O. Box 519 N-1612 Fredrikstad Norway Tel: +47 69 30 00 60 w w w . s i d e - p o w e r . c o m Fax: +47 69 30 00 70 sidepower@sleipner.no © Sleipner Motor AS 2006...
-
Page 2: Table Of Contents
Warranty statement 1. The equipment manufactured by Sleipner Motor AS (The “Warrantor”) is warranted to be free from defects in workmanship and materials under normal use and service. 2. This Warranty is in effect for of two years from the date of purchase by the user. Proof of purchase must be included, to establish that it is inside the warranty period. -
Page 3: Hydraulic System Components
Hydraulic system components Tank assembly with prefitted Sternthruster components Variable Load sense pump Bowthruster A complete Sidepower hydraulic thruster system consists of one or more hydraulic pumps, one or two thrusters and an oil tank with pre-fitted load sense controlvalve, oil cooler, high-pressure and return filter, oil filling filter, level and temp indictors and internal hoses. -
Page 4: Oil Tank Assembly
Sidepower hydraulic tank and components Return filter Oil filling and breathing filter Seawater oilcooler (optional) Electrical oil temp/level indicator Visual oil temp/level indicator Prewired electrical junction box Load sense control valve Pressure gauge Feed to pumps Flexible rubber mounting feets High pressure filter 2x Internal Drain return... -
Page 5: Technical Specifications Oil Tank Assembly
Hydraulic tanks Floor mounted Tank kit 40 ltr 60 ltr 90 ltr 120 ltr Tank volume (ltr · usg) 52.8 · 13.9 93.9 · 24.8 122.3 · 32.3 160 · 42.3 Oil volume (ltr · usg) 40 · 10.6 60 · 15.9 90 ·... -
Page 6: Control Panels
Control panels Yacht Single Yacht Dual Pro Single Pro Dual Height (mm•in) 71•2.80 122•4.80 125•4.92 206•8.11 Width (mm•in) 71•2.80 71•2.80 106•4.17 106•4.17 Depth (mm•in) A/B 60•2.36/42•1.65 60•2.36/42•1.65 115•4.43/100•3.94 115•4.43/100•3.94 Item code (12 V) 895112-S 895112-D 896112-S 896112-D Depth Item code (24 V) 895124-S 895124-D 896124-S... -
Page 7: Installation Planning
• Front mounted to the engine crankshaft with use of a bracket and a flexible coupling • AC power pack Belt drive installations is not recommended due to the high stress and torque requirements. Please concact your Side-Power distributor if belt drive installation is the only option... -
Page 8: Tank Assembly Installation
Tank assembly installation • Place the tank in a position where you have access to connection and inspection points. Ensure that there is enough space to lift out and replace the filters. Keep in mind to make room for access to the oil filling point. •... -
Page 9: Cooling Water
Side-Power products. Connect drain from consumers to drain port at tank. If resetting or fine tuning of the valves is necces- sary, please contact your Side-Power distributor. Sidepower Hydraulic System 2.3 - 2006... -
Page 10: Electrical Wiring
• From the junction box to each of the control and info panels. Use 1 mm wire size (3-9 lead multi cable, depending on type of control panel). • Non-Thruster consumers are not prewired by Side-Power. Use 1 mm multi cable. More detailed information is found in the unique electrical wiring schematic. -
Page 11: System Fill Up
System fill-up Prior to filling the tank, prime the pump(s) through their upper drain port. Fill the oil tank with correct hydraulic oil through the oil filling filter. Use new and clean mineral based hydraulic oil with anti-wear additives, viscosity ISO VG 32.00 (by ISO 3448) The oil level in the tank should be approximately 3/4 full, or at the middle of the upper indicator of the sight glass. -
Page 12: Operating The Thruster System
Operating the thruster system Pro control panel, Yacht control pane On/Off control panel / info panel proportional proportional A B C D 2 3 4 A B C D ON/OFF CONTROL PANELS PROPORTIONAL CONTROL PANELS 1: Joystick A: Emergency stop button 2: On button B: Oil temperature alarm 3: Active station indicator... - Page 13 Operating the thruster system ON/OFF CONTROL PANELS/INFO PANEL 1. To activate the control station, press both on buttons (2 and 4). The active station indicator (3) will turn on to indicate that the control station is active. 2. To run the truster(s), you can now move the joystick(s) (1) in the choosen direction. The joysticks will return to center position when released.
-
Page 14: Service
Servicing the hydraulic system - Check filter indicators (A and G) periodically. A large hydraulic consumer must run at full speed for the dirt indication gauges to work. - Check oil level (E) periodically. - We recommend to replace hydraulic oil and filters (B and H) after the initial start up and test period. This is to eliminate all debris and dirt from installation and start up, to ensure a trouble free and long service life. -
Page 15: Troubleshooting
Trouble shooting No standby pressure on the system when pump(s) are running • The pumps drive direction is incorrect. Stop the pump(s) immediately to minimize potential pump damage. Contact Sidepower for further assistance / new pumps. Max pressure on the system is 20-30 bar when running a consumer •... -
Page 16: Service Centres
Tel: +385 51 704 500 Sleipner Motor AS Fax: +385 51 704 600 acy@net.hr Sleipner Motor AS • P. O. Box 519, N-1612 Fredrikstad • Norway Tel: +47 69 30 00 60 • Fax: +47 69 30 00 70 • sidepower@sleipner.no • www.side-power.com...
