Chapter 1: Alarms

A056 - Guiding Channel Malfunction During Opening

GUIDING CHANNEL
MALFUNCTION DURING
OPENING!
POSSIBLE CAUSES:
-OPENING MECHANISM
MALFUNCTION
-SIGNAL SWITCH SQ3
DEFECTIVE OR
MIS-ADJUSTED
Description:
The Guiding Channel Malfunction During Opening alarm occurs if input (I0.5 – SQ3) does not turn on when the channel opens up.
Solution:
Press the HELP key on the remote control station. Press the F4 key (Page Down icon) twice.
Case Input Remote Pendant
1 Bit 5 = 1
2 Bit 5 = 0
For case 2, after the solution has been completed, press the STOP key on the remote control station to clear the message and reset
the alarm.
A056
MODULE 0
Alarm needs to be cleared. Press the STOP key on the remote
76543210
control station to clear the message and reset the alarm.
100000
MODULE 0
76543210
0
Solution
Check to see if a mechanical obstacle prevents the channel from
opening.
Check the channel opening/closing cylinder functionality.
Check the adjustment and functionality of the SQ3 switch.
