Chapter 1: Alarms

A003 - Lathe Emergency Stop Line Open

LATHE EMERGENCY
STOP LINE OPEN!
POSSIBLE CAUSES:
-EMERGENCY STOP
PUSHED IN
-WIRING PROBLEM
Description:
The Lathe Emergency Stop Line Open alarm occurs whenever the PLC does not detect input (I2.3). The problem is generated when
the lathe E-stop push button is pressed in.
Solution:
Press the HELP key on the remote control station. Press the F4 (Page Down icon) three times.
Case Input Remote Pendant
1 Bit 3 = 1
2 Bit 3 = 0
For case 2, after the solutions have been completed, press the STOP key on the remote control station to clear the message and
reset the alarm.
A003
MODULE 2
Alarm needs to be cleared. Press the STOP key on the remote
76543210
control station to clear the message and reset the alarm.
1000
MODULE 2
76543210
Reset the E-stop push button on the lathe.
0
Solution
