IES Keywatt 24 Wallbox User Manual page 12

General & dimensions
Cooling systems
Noise (1m, all direction)
Climatic & Environment constraints
Operating temperature (with derating)
Storage temperature
Relative humidity
Installation altitude
Norms & standards
Radio Equipment Directive (RED)
Efficient use of Radio Spectrum (RED)
Electric vehicle conductive charging system
Part 1: General requirement
Electric vehicle conductive charging system
Part 22: AC Electric vehicle charging station
Electric vehicle conductive charging system
Part 23: DC Electric vehicle charging station
Electric vehicle conductive charging system
Part 24: Digital communication between a DC charging
station and an EV for control of DC charging
Electromagnetic compatibility (EMC)
Insulation Monitor Device (IMD)
RoHS
Declaration of conformity CE
EV Ready (for G3X only)
Max output current will be adapted versus maximum carrying current of the vehicle plug.
(1)
Output current can be even reduced with the power derating versus temperature.
(2)
Potential derating above 35°C.
(3)
CE marking affixed on the product attest the conformity of the product with applicable requirements of relevent Community har-
(4)
monization legislation.
On Wallbox G3, you only have one Combo or CHAdeMO connector.
(5)
12
(4)
www.ies-synergy.com
User Manual DUM016055-EN
Heatsink with forced air flow by fans IP55
without air filter
Db(A) 65dbA (1m)
-25°C to +55°C
(3)
-25°C to +60°C
RH 10% to 95%
Alt 2 000m
2014/53/EU
ETSI EN 301 511 V12.5.1
ETSI EN 301 908-1 V11.1.1
ETSI EN 301908-2 V11.1.2
ETSI EN 301908-13 V11.1.2
ETSI EN 300 330 v2.1.1
IEC 61851-1
IEC 61851-22
IEC 61851-23
IEC 61851-24
IEC 61851-21-2 (for G3 only)
EN 61000-3-11 (for G3X only)
EN 61000-3-12 (for G3X only)
EN 61000-6-2 (for G3X only)
EN 61000-6-4/A1 (for G3X only)
EN 301489 v2.2.0 (for G3X only)
EN 301489-17 V3.2.0:2017 (for G3X only)
IEC 61557-1
IEC 61557-8
2015/863/EU (for G3 only)
2011/65/EU (for G3X only)
Yes
Compliant
Max
