Operator's manual
GB
+ INSTRUCTIONS FOR PRODUCT DELIVERY . . . Page 3
"Translation of the original Operating Manual"
EUROTOP 611 A TOPTECH PLUS
(Type SK 243 : Chassis-Nr: +..03216 / MaschNr: +..04216)
EUROTOP 691 A TOPTECH PLUS
(Type SK 293 : Chassis-Nr: +..0972 / MaschNr: +..01972)
Double Rotary Swather
Nr.
99 293.GB.80P.0
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Poettinger EUROTOP 611 A TOPTECH PLUS
Summary of Contents for Poettinger EUROTOP 611 A TOPTECH PLUS
- Page 1 + INSTRUCTIONS FOR PRODUCT DELIVERY . . . Page 3 "Translation of the original Operating Manual" 99 293.GB.80P.0 EUROTOP 611 A TOPTECH PLUS (Type SK 243 : Chassis-Nr: +..03216 / MaschNr: +..04216) EUROTOP 691 A TOPTECH PLUS (Type SK 293 : Chassis-Nr: +..0972 / MaschNr: +..01972)
- Page 2 Be advised! The operating instructions must also be passed on with any subsequent transfer of the machine and the transferee of the machine must be instructed with regard to the regulations stated. Pöttinger Newsletter www.poettinger.at/landtechnik/index_news.htm Current information, useful links and entertainment 1300_GB-SEITE 2...
- Page 3 In order to prove that the machine and the operating manual have been properly delivered, a confirmation is necessary. For this purpose please do the following: - sign the document A and send it to the company Pöttinger or via the internet to www.poettinger.at - document B stays with the specialist factory delivering the machine.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Table of contents CE sign TABLE OF CONTENTS The CE sign, which is affixed Recommendations CE sign ..............4 by the manufacturer, indicates for work safety Meaning of warning signs .......... 4 out ward ly that this machine ATTACHING TO TRACTOR con forms to the engineering All points refering to... -
Page 5: Attaching To Tractor
ATTACHING TO TRACTOR Initial attaching to tractor Hydraulic connection The tractor must be equipped with at least a double 1. Attach the drawbar on tractor tool bar. acting and a single acting hydraulic connection. Important! Safety hints: Connect hydraulic lines at tractor - The tool bar must be mobile (A-B) see Annex A1 pt. -
Page 6: Preparations For Initial Use
ATTACHING TO TRACTOR Preparations for initial use Setting the threaded spindle Important! Set distance (X1) Be advi- 1. Working positions means that the implement is lowered 1. Couple the machine to the tractor and bring it in working sed! and the rotor tines slightly touch the ground (A1). position (see above). -
Page 7: Setting The Sequential Valve
ATTACHING TO TRACTOR Hydraulic hoses and electrical cables Note: Hydraulic hoses and electrical cables are mounted overhanging on the machine. The machine can be thus attached to various tractors. • Roll hydraulic lines and electrical cables together accordingly and fasten them with cable tie (K). •... -
Page 8: Parking The Implement
PARKING THE IMPLEMENT Parking the implement Do not use the safety chain to rest the cardan shaft! The implement can be parked in either the working Important! position or transport position. - Close shut-off valve (pos. A) and then disconnect Ensure stability hydraulic lines from tractor for every plug connection. -
Page 9: Working And Transport Position
WORKING AND TRANSPORT POSITION Driving on public roads Turn manoeuvres on slopes • Observe the statutory legislation of your country/state. Take care! • Drive on public roads only as described in the chapter The tractor's driving characteristics are "Transport position". influenced by the weight (G) of the rotor •... -
Page 10: Transport Position
WORKING AND TRANSPORT POSITION Transport position Be ad- Changing to transport position. 5. Remove all tine carriers and pin to mounting vised! frame (pos. 1). Do not stand in 1. Swivel machine to central position. the implement's Actuate dual-action servo (ST) swivel range. -
Page 11: Changing From Transport To Working Position
WORKING AND TRANSPORT POSITION Changing from transport to working position Safety hints: Changing from working to transport see Supplement position and vice versa is only to be carried -A1, pt. 8a. - 8h.) out on even, firm ground. 1. Shut-off valve opened (pos. E) TD44/94/8 2. -
Page 12: Operation
OPERATION Preparations for operation Be advised! 1. Fit all tine carriers to both rotors. Do not enter rotor • Fix tine carriers onto rotor arms and secure with linch area while drive pin. motor is running. 2. Swivel all deflector hoops (6) to the protection 3. -
Page 13: Settings On Rotor Chassis
OPERATION Settings on rotor chassis Requirements: - Flat and firm ground - 1.5 bar pressure in all tyres - Implement is attached to tractor and in the working position Adjusting rake height 1. Set rake height using spindle (8) - every rotor unit individually. -
Page 14: Swath Types
OPERATION Swath types Two single swaths or a side swath 1. Setting for two single swaths. A second trap sheet (44a) can be used in this operating position (optional extra). • Swivel rear rotor to right-side operating position (R2). 159-02-16 2. -
Page 15: Important Before Starting Work
OPERATION Important before starting work General guidelines for working with the implement. Safety advice 1. Switch on p.t.o. Be advised! (see Supple- Only switch p.t.o. on when all protective fittings (covers, Do not enter the rotor area while the drive ment-A1 pts. -
Page 16: The "Multitast" System
THE "MULTITAST" SYSTEM Swather with "Multitast" system General Important! Feeler wheels are fitted to machines with the "Multitast" system The rotor units are not rigidly positioned but can be Changeover for swivelled up and down (approx. 4°) via a swivel joint. the relevant operation is Using the feeler wheel enables optimal adaptation to the ground when the surface is extremely uneven. -
Page 17: Changeover For Operation Without Feeler Wheel
THE "MULTITAST" SYSTEM Changeover for operation without feeler 7. Correctly set the distance (X1) with the front threaded spindle wheel - see chapter "Attaching to tractor" 1. Remove axle (1) 8. Remove feeler wheel (2) 2. Remove axle beam: - Remove hydraulic hose holder (2) Changeover for operation with feeler - Remove groove nut (3) wheel... -
Page 18: Safety Advice
GENERAL MAINTENANCE MAINTENANCE Safety advice Parking in the open • Switch off engine prior to any adjustment, maintenance Clean and protect the piston rods with Safety advice or repair work. grease prior to longer periods parked outside. • Switch off engine and remove igni- FETT tion key prior to... -
Page 19: Lubrication Points
MAINTENANCE Lubrication points Transmission - Change oil after the first 50 operating hours. Under normal operating conditions oil is to be changed Symbols have been affixed at annually FETT different points on the machine. - Change oil after 100 hrs. at the latest. This indicate one or several lubrication points. -
Page 20: Tine Arms
MAINTENANCE Tine arms Change tine arms Position the Nordlock washers with the rough milling - Loosen cover bolts (1). inside on top of one another. This means that both washers have the fine milling outside. - Secure cover on the new tine arm, insert between the covers and tighten screw. -
Page 21: Rotor Unit
MAINTENANCE Spring tines Changing the bearing bush of the tine arms Check the attachment bolts (S) of the spring tines after • The distance (A) in normal operation must be of about the first 10 hours in operation and re-tighten if necessary 1 mm. -
Page 22: Lubrication Chart
FETT Schmierplan Plan de graissage Lubrication chart alle X Betriebsstunden Toutes les X heures de service after every X hours operation 40 F alle 40 Fuhren 40 F Tous les 40 voyages 40 F all 40 loads 80 F alle 80 Fuhren 80 F Tous les 80 voyages 80 F... -
Page 23: Technical Data
TECHNICAL DATA Technical data Important! Please enter the se- EUROTOP 611 A EUROTOP 691 A rial number on the Number of rotors title page of the operator's manual Number of tine arms per rotor immediately upon Working width (clearing width) 3.4 - 6.2 m 4.2 - 6.9 m taking receipt... - Page 24 TECHNICAL DATA EUROTOP 611 A - 24 - 1400_GB-TECH DATEN_293...
- Page 25 TECHNICAL DATA EUROTOP 691 A - 25 - 1400_GB-TECH DATEN_293...
-
Page 26: Optional Equipment
TECHNICAL DATA Optional Equipment Tandem tyres (Weight 39 kg) System "MULTITAST" (Weight 39 kg) Feeler wheels for better ground adaptation when ground is uneven. Swath curtain for the front rotor unit (Weight 326 kg) System "MULTITAST" (Weight 22 kg) Feeler wheels for better ground adaptation when ground is uneven. -
Page 27: Supplement
SUPPLEMENT GB-Anhang Titelblatt _BA-Allgemein... - Page 28 The original cannot be copied ... Things will run better with genuine Pöttinger parts • Quality and precise fitting The decision must be made, ”original” or ”imitation”? The decision is often governed by price and a ”cheap buy” can sometimes be very expensive. - Operating safety.
- Page 29 SUPPLEMENT - A Recommendations for work safety Recommendations for work safety 5.) Spare parts All points refering to safety in this manual are a. The original com po nents and ac ces so ries have been in di ca ted by this sign. de sig ned especially for these machines and appliances.
- Page 30 SUPPLEMENT - A 9.) Transport of persons prohibited a. The transport of persons on the machine is not permitted. b. The machine may only be driven on public roads when in the position sti pu la ted for road trans port. 10.) Driving ability with auxiliary equipment a.
- Page 31 PTO SHAFT Supplement - B Matching driveshaft to tractor Instructions for working To determine the actual length required, hold the two halves The permissible pto speed may not be exceeded when Be advised! of the driveshaft side by side. using the implement. - The hitched implement may continue to run after the Only use the pto is switched off.
- Page 32 PTO SHAFT Supplement - B Information on function when using a cam shifting clutch. This overload clutch switches the torque transmitted to zero if overloaded. To revert to normal operation, stop the p.t.o. drive briefly. The clutch reengages at a speed below 200 rpm. Be advised! Re-engaging is also possible by decreasing the p.t.o.
-
Page 33: Lubricants
- 33 - 1400_EN-BETRIEBSSTOFFE... - Page 34 - 34 - 1400_EN-BETRIEBSSTOFFE...
- Page 35 - 35 - 1400_EN-BETRIEBSSTOFFE...
- Page 36 EC Conformity Declaration Original Conformity Declaration Name and address of the manufacturer: Alois Pöttinger Maschinenfabrik GmbH Industriegelände 1 AT - 4710 Grieskirchen Machine (interchangeable equipment): rotary rake EUROTOP 691 A Type Serial no. The manufacturer declares that the machines adhere to all relevant provisions in the following EU directive: machinery 2006/42/EG In addition to this, the manufacturer also declares adherence to the other following EU...
- Page 37 Im Zuge der technischen Weiterentwicklung La société PÖTTINGER Landtechnik GmbH Following the policy of the PÖTTINGER arbeitet die PÖTTINGER Landtechnik améliore constamment ses produits grâce Landtechnik GmbH to improve their products GmbH ständig an der Verbesserung ihrer au progrès technique. as technical developments continue, Produkte.
- Page 38 PÖTTINGER Landtechnik GmbH A-4710 Grieskirchen Telefon: +43 7248 600-0 Telefax: +43 7248 600-2513 e-Mail: info@poettinger.at Internet: http://www.poettinger.at PÖTTINGER Deutschland GmbH Verkaufs- und Servicecenter Recke Steinbecker Strasse 15 D-49509 Recke Telefon: +49 5453 9114-0 Telefax: +49 5453 9114-14 e-Mail: recke@poettinger.at PÖTTINGER Deutschland GmbH Servicecenter Landsberg Spöttinger-Straße 24...
