Mounting instructions
Nr. 99 8548.GB.60L.0
AEROSEM F 5000
Type 8547 : + . . . 01001)
AEROSEM F 6000
Type 8548 : + . . . 01001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEROSEM F 5000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Poettinger AEROSEM F 5000

  • Page 1 Mounting instructions Nr. 99 8548.GB.60L.0 AEROSEM F 5000 Type 8547 : + . . . 01001) AEROSEM F 6000 Type 8548 : + . . . 01001...
  • Page 2: Table Of Contents

    Table of contents SAFETY NOTES Professional Qualification ......................... 3 Intended Use ............................3 Prior to Starting Assembly Work ......................3 General Safety Notes for Assembly ......................4 Prior to Starting Up ..........................4 TECHNICAL DATA Equipment variants ..........................5 The Defined Use of the Seed drill ......................5 Location of Identification Plate .........................
  • Page 3: Safety Notes

    SAFETY NOTES Professional Qualification • These assembly instructions are aimed exclusively at skilled staff trained for this work. Intended Use • Intended use is described in the machine’s Operating Instructions. The attachment or installation of additional equipment does not constitute a change to the machine’s intended use. Prior to Starting Assembly Work •...
  • Page 4: General Safety Notes For Assembly

    SAFETY NOTES General Safety Notes for Assembly DANGER Risk of severe or life-threatening injuries all over the body due to getting caught up, being pulled in, crushing and hydraulic oil escaping at high pressure! It is imperative to follow the safety notes! •...
  • Page 5: Technical Data

    TECHNICAL DATA Equipment variants Seed drill AEROSEM F Seed box Transport lines Distributor head Spur wheel Front strip packer Dosing unit Blower Seeding bar Location of Identification Plate A. P ttinger Maschinenfabrik Ges. m. b. H. A-4710 Grieskirchen Ober sterreich The serial number is struck into the Vehicle Identification Modell Plate shown opposite, and into the frame.
  • Page 6: Technical Data

    Working width No. of rows Weight Seed box capacity with / without top (cm) (kg) Aerosem F 5000 front tank 1600 / 2300 Hinged seeding bar 40 / 48 Aerosem F 6000 front tank 1600 / 2300 Hinged seeding bar 40 / 48 / 60 Seed distribution ..................pneumatic...
  • Page 7: Mounting Instructions

    MOUNTING INSTRUCTIONS 8548.GB.60L.0 Requirements These instructions describe the mounting of an AEROSEM F 6000 seed drill with front hopper onto a LION rotary harrow. Before mounting the seed drill, the rotary harrow must have been completely assembled. Normally, the seed drill is delivered disassembled in the following components: •...
  • Page 8 8548.GB.60L.0 Mount the coupling pocket as shown (outside left). Coupling pocket (outside left). Mount the coupling pocket as shown (both outside and inside left). Make sure that the distance between measuring points M1 and M2 is 1790 mm. Coupling pocket (outside left) Coupling pocket (inside left) Repeat the above steps analogously on the other side of the machine.
  • Page 9: Mounting Of The Left Seed Unit

    8548.GB.60L.0 Mounting of the left seed unit Insert the left seed unit as shown into the coupling pockets and secure the safety bolt with a linchpin as prescribed. The photo shows the left inner coupling pocket. Fastening bolt Locking pin - 9 -...
  • Page 10 8548.GB.60L.0 The photo shows the left inner coupling pocket. Repeat the above steps analogously on the right side of the machine. - 10 -...
  • Page 11: Mounting The Top Link And Top Link Support

    8548.GB.60L.0 Mounting the top link and top link support Mount the top link as shown (outside left). Top link Mount the top link support as shown (outside left) Top link support Mount the top link on the support as shown. - 11 -...
  • Page 12 8548.GB.60L.0 Mount the top link support as shown (inside left). - 12 -...
  • Page 13 8548.GB.60L.0 Mount the top link as shown (inside left). Repeat the above steps analogously on the right side of the machine. - 13 -...
  • Page 14: Mounting The Track Marker

    8548.GB.60L.0 Mounting the track marker Lower the arm and mount the extension. - 14 -...
  • Page 15 8548.GB.60L.0 Mount the track marker support as shown. Track marker support Mount the marker as shown Marker Repeat the above steps analogously on the other side of the machine. - 15 -...
  • Page 16 8548.GB.60L.0 Mount the control box and attach hoses and cables. For the assembly of the front hopper and the hoses, see "Attaching to tractor". - 16 -...
  • Page 17: Attaching To Tractor

    ATTACHING TO TRACTOR Fixing devices on the tractor Fitting the hoses - Pipe fixing hoops are included for fitting the pipe to Cutting hoses into lengths the tractor. - Machine in lowered position (front and rear) - The fixing devices (A, B, C) for fitting the pipe hoops (D) - Cut hoses to optimum lengths to the tractor are not included.
  • Page 18: Mounting Front Tank

    ATTACHING TO TRACTOR Mounting front tank Mounting the seeding rail Mounting tank to front three-point hydraulics Fitting the seeding rail - Kat II or coupling triangle - Fit seeding bar, which sits on supports (1), to a soil-tilling implement. - Secure properly! - Secure properly! - After lifting implement remove stand (A) by removing Fitting front p.t.o.
  • Page 19: Mounting Electronic Control

    ATTACHING TO TRACTOR Mounting electronic control Transport and working positions - Connect 7-pole electro cable to front tank pos. (S1) Changing to transport position - Fit operating console in tractor cabin Actuate the hydraulic control valve on the tractor - Spur markers are swung in - Secure spur markers with pin (14) Locking bracket (15) must lock into place Changing to working position...
  • Page 20: General Notes On Road Transport

    ATTACHING TO TRACTOR General notes on road transport • Lower implement far enough to have a ground clearance of 25-30 cm. Advantage: centre of gravity lies lower, therefore less danger of tipping. • Secure hydraulic control valve on tractor against unintentional use! The working unit is hydraulically locked in the transport position (fig.
  • Page 21: Check

    Check EN Final Check and Self-Check • Check all screw fittings and plug-in connections for good condition and secure fit. • Nach Fertigstellung der Maschine sind alle Schmierstellen laut Wartungsanleitung (siehe Betriebsanleitung) erstmalig abzuschmieren, sowie die Ölstände vorhandener Getriebe etc. zu kontrollieren und falls nötig zu ergänzen.
  • Page 22 Im Zuge der technischen Wei ter ent wick lung La société PÖTTINGER Ges.m.b.H améliore Following the policy of the PÖTTINGER Ges. arbeitet die PÖTTINGER Ges.m.b.H stän dig constamment ses produits grâce au progrès m.b.H to improve their products as technical an der Verbesserung ih rer Pro duk te.
  • Page 23 ALOIS PÖTTINGER Maschinenfabrik Gesellschaft m.b.H A-4710 Grieskirchen Telefon: 0043 (0) 72 48 600-0 Telefax: 0043 (0) 72 48 600-2511 e-Mail: landtechnik@poettinger.at Internet: http://www.poettinger.at GEBR. PÖTTINGER GMBH Stützpunkt Nord Steinbecker Strasse 15 D-49509 Recke Telefon: (0 54 53) 91 14 - 0 Telefax: (0 54 53) 91 14 - 14 PÖTTINGER France...

This manual is also suitable for:

Aerosem f 6000
