3 Package content
a
a
Barix Instreamer
e
Serial cross cable
4 Getting to know your Barix Instreamer
Rear side
A
B
C
A RJ45 for LAN 10/100 Half/Full duplex
This port is for the connection to your network.
B
S/PDIF in coaxial
C S/PDIF in optical
D Left Line input RCA
E
Right Line input RCA
F
Power in
ring: Ground, center : +12 VDC
b
Power supply
f
Network cable
D
E
F
Barix Instreamer User Manual Version 01.01
b
c
e
c
Earphone
Front side
1
2 3
1
Serial port (RS-232)
This port is for a serial connection to your computer.
2
Headphone out
3
Infrared out
4
Red and green LED for status display
5
Reset button
Press this button shortly to reset the Barix Instreamer.
If you press it until the red light flashes (about 5
seconds) the device will be reset to factory defaults.
d
f
d
RCA stereo cable
4 5
