Crosswater GLIDE II Installation Instructions

GLIDE II BATHROOM FURNITURE RANGE
500 Two Drawer Basin Unit,
Ceramic / Cast Marble / Glass Basin / Worktop
DE0002SCW+ 11kg
GL0511SIW+ 7kg
DE0002SRW+ 17.5kg
GL5000T 11kg
GL5000D+ 25.1kg
x2 850N (86kg) Load capacity per bracket
on a solid wall. To DIN 68840 06/2004
Overflow fitting supplied with Cast Marble
and Glass Basins only
Tools & equipment needed: Drill, 8mm Suitable drill bit, Phillips screwdriver, Spirit level, Ruler/tape measure, Pencil, Solvent free silicone sealant (clear).
IMPORTANT - Advice and safety - Please read before installation
Please read these instructions carefully before starting installation
and keep in a safe place for future reference. ENSURE the room is well
heated and ventilated.
Check the contents of the pack carefully before installation. Crosswater will
not be heid responsible for any de-fit / re-fit costs where faulty product has
been fitted.
If any fault is found with materials or workmanship, it must be reported
immediately to the manufacturer. Remedial action will be taken, based on
information received, on condition that: 1. Full details are supplied to the
manufacturer. 2. The product has not been modified or tampered with; 3. The
manufacturer is informed of any damage/shortages prior to installation. 4. The
product has not been installed, or attempts have been made to install.
We do not accept responsibility for any problems that may occur through
incorrect installation.
Advice & Safety
This product should only be installed by a suitably qualified Plumber/installer.
Should the installation be completed by a non-qualified person any product
guarantee maybe considered invalid. For a claim made under our warranty
written certification of your installers qualifications can be required.
It is advised that all doors and drawers are removed prior to fitting to avoid
unnecessary damage occurring.
It is recommended that the furniture and accessories are installed after tiling,
ensuring that the product is installed flat to the tile face and allows product to
be easily removed if required in the future.
This document has been prepared for your guidance, you must exercise due
care at all times.
Please note that some units are heavy. Always take care when lifting, and
follow health and safety guidelines. It is recommended that 2 people carry out
the installation of larger basin/vanity units over 30Kgs gross weight.
Do not expose glass washbasins to wide and rapid changes in temperature.
Do not expose glass washbasins to water with a temperature over 60°C.
Glide II Furniture 02/2020
700 Two Drawer Basin Unit,
Ceramic / Cast Marble / Glass Basin / Worktop
x8
x2 850N (86kg) Load capacity per bracket
on a solid wall. To DIN 68840 06/2004
Overflow fitting supplied with Cast Marble
and Glass Basins only
DE0003SCW+ 14.2kg
GL0711SIW+ 10kg
DE0003SRW+ 21kg
GL7000T 16.2kg
GL7000D+ 28.8kg
x8
Warning! ! Please check for any hidden pipes or electrical cables before drilling
holes in the floor or walls.
When using power tools always follow the manufacturer's user instructions.
This installation guide details fitting to a solid wall. If your bathroom has studded/
plasterboard walls, please use appropriate plasterboard fixings. Please ensure
the wall can take weight of units detailed above. Before installing a wooden
bathroom unit into a new property, extension or recently plastered room we
strongly advise the building/room is completely dry, well ventilated and
adequately heated.
Important pre-installation notes
To ensure full working use of the drawers we recommend the use of basin
furniture trap BTR0410W.
Care & Cleaning
Glass and cast mineral marble products should be cleaned regularly with warm
soapy water, then rinsed with clean water and, if desired, dried and polished
with a soft cloth. Lime scale deposits can be removed using a 50:50 solution
of warm water and lime scale remover and soft clean cloth. We recommend
regular cleaning with Cream Polish SD150RW, specially formulated to clean
and help protect the surface of glass and cast mineral marble basins.
Please also take care not to damage the lacquered surface on the underside
of the glass washbasin that gives the washbasin its colour. Damage to the
underside of the washbasin may be visible through the glass. Take care how
you handle the washbasin prior to installation and place it on a soft surface to
avoid damage.
Do not use abrasive cleaners or bleach in this will permanently damage the high
gloss surface.
Use a well wrung chamois leather or micro fibre cloth to clean furniture
carcasses.
If any maintenance is required then it must be carried out by a qualified Plumber.
The manufacturer reserves the right to make technical modifications without
prior notice.
1000 Two Drawer Basin Unit,
Ceramic / Cast Marble / Glass Basin / Worktop
DE0004SCW+ 19kg
GL1011SIW 14.2kg
DE0004SRW+ 28kg
GL1000T 23kg
GL1000D+ 36.6kg
x2 850N (86kg) Load capacity per bracket
on a solid wall. To DIN 68840 06/2004
Overflow fitting supplied with Cast Marble
and Glass Basins only
x8
