Model 3600
Infrared Gas Monitor
instruction manual
WARNING
THIS MANUAL MUST BE CAREFULLY READ BY ALL INDIVIDUALS WHO HAVE OR WILL
HAVE THE RESPONSIBILITY FOR INSTALLING, USING OR SERVICING THIS PRODUCT. Like
any piece of complex equipment, this product will perform as designed only if installed, used
and serviced in accordance with the manufacturer's instructions. OTHERWISE, IT COULD
FAIL TO PERFORM AS DESIGNED AND PERSONS WHO RELY ON THIS PRODUCT FOR
THEIR SAFETY COULD SUSTAIN SEVERE PERSONAL INJURY OR DEATH.
The warranties made by Mine Safety Appliances Company with respect to these products
are voided if the products are not installed, used and serviced in accordance with the
instructions in this manual. Please protect yourself and others by following them. We
encourage our customers to write or call regarding this equipment prior to use or for any
additional information relative to use or repairs.
INSTRUMENT DIVISION 1-800-MSA-INST or FAX (412) 776-3280
IN CANADA 1-800-267-0672 or FAX (416) 663-5908
MSA INTERNATIONAL (412) 967-3228 or FAX (412) 967-3373
© Mine Safety Appliances Company 1993 - All Rights Reserved
Made in Switzerland for
MINE SAFETY APPLIANCES COMPANY
PITTSBURGH, PENNSYLVANIA 15230
(L) REV 2
800031
