Malvern - 3 Door Display Cabinet
Assembly Instructions
604/0105
- Please keep for future reference
Dimensions
Width - 123cm
Depth - 41.6cm
Height - 185.2cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6403030
BK01000 - Issue 2 - 12/06/2014
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Malvern 604/0105
Summary of Contents for Argos Malvern 604/0105
- Page 1 Malvern - 3 Door Display Cabinet Assembly Instructions 604/0105 - Please keep for future reference Dimensions Width - 123cm Depth - 41.6cm Height - 185.2cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6403030 BK01000 - Issue 2 - 12/06/2014...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • Parts of the assembly will be • We do not components and tools listed on easier with 2 people. recommend the pages 2 and 3.
- Page 3 If you have damaged or missing components, Components - Panels 0345 6403030 call the Customer Helpline: Please check you have all the panels listed below Display top Display Base (109 x 123 x 32.2cm) (76.2 x 123 x 41.6cm)
- Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. 15mm Screw x 1 15mm Washer x 2 Wall strap x 1 Connecting bracket x2...
- Page 5 Assembly Instructions Assembly Instructions Step 1 Joining the Top to the Base Position display base slightly away from the wall in the position required [please note it will be hard to move once assembled]. When in place sit the display top on top of the display base and align the...
- Page 6 Assembly Instructions Step 2 Remove and replace handle The twist bar handles are fi tted to the inside of the unit, using a Philips screwdriver unscrew the 20mm handle screws in each handle and remove both the 20mm handle screw and the twist bar handle.
- Page 7 Assembly Instructions Step 3 Connecting display lights a: The display light is fi xed to the light pelmet inside the display cabinet. Push the fi tting on the end of the cable through the hole in the back panel. connection from display light b: Connect the socket on the display light into the connection on the multi...
- Page 8 Assembly Instructions Step 4 Fixing to wall It is recommended that the unit is fi xed to a wall Fix wall strap to the back of the unit using 15mm screw 15mm washer Back Panel Warning: The Unit Top 15mm screw is for fi...
- Page 9 Customer Helpline: 0345 6403030 If you need help or have damaged or missing parts, call the...
