Kingston - Dining Chair
Assembly Instructions
Dimensions
Width - 44cm
Depth - 52cm
Height - 99.5cm
Important – Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the
- Please keep for future reference
Customer Helpline: 08456 400800
602/9731
602/9779
602/9803
602/9834
130485
Issue 1 - 12/11/09
Advertisement
Related Manuals for Argos Kingston 602/973
Summary of Contents for Argos Kingston 602/973
- Page 1 Kingston - Dining Chair Assembly Instructions 602/9731 - Please keep for future reference 602/9779 602/9803 602/9834 130485 Dimensions Width - 44cm Depth - 52cm Height - 99.5cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 12/11/09...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly components and tools listed on the product, this could cause recommend the pages 2 and 3. damage. use of power drill/drivers for inserting screws plastic bags and separate them as this could damage the unit.
- Page 3 Components - Wooden parts Please check you have all the panels listed below Front leg ( 4 x 43cm ) Back stand Seat frame ( 42.5 x 44cm ) (41.5 x 99.5cm) Components - Fittings If you have damaged or missing components, call the Customer Helpline: 08456 400800 Note: The quantities below are the correct amount to complete the assembly.
- Page 4 Assembly Instructions Step 1 Assembling front leg a: Remove the dust cover under the seat. b: Place the chair seat on top of table. Insert the front legs into the seat. c: Secure the JCBC short bolt using spring washers and flat washers with allenkey Note: Do not fully tighten...
- Page 5 Assembly Instructions b: Secure the back stand with JCBC long bolts using spring washers flat washers and tighten with allenkey 75%. c: Secure the back stand with JCBC short bolts using spring washers flat washers and tighten with allenkey 75%. Note: Do not fully tighten bolts.
- Page 6 Assembly Instructions Step 4 Fully tighten all bolts a: Turn over the chair and place on top of a table. Fully tighten all bolts with allenkey b: Cover back the discover with the belco tape. Assembly is complete. If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800...
