Valencia -
Assembly Instructions -
hygena
If you are fitting a
Fridge/Freezer inside
this unit please refer to
the instructions that
were supplied with the
appliance.
We recommend that you
contact a registered
installer.
Dimensions
Width - 60cm
Depth - 59cm
Height - 213cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
600mm Larder Cabinet
Please keep for future reference
Cabinet
Black Door Pack
Cream Door Pack
Oak Door Pack
White Gloss Door Pack
White HN Door Pack
633/7777
633/2923
633/2758
198/9405
633/2844
194/7605
MADE IN
BRITAIN
Issue 4 - 09/02/15
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Valencia 633/7777
Summary of Contents for Argos Valencia 633/7777
- Page 1 Valencia - 600mm Larder Cabinet Assembly Instructions - Please keep for future reference Cabinet 633/7777 hygena Black Door Pack 633/2923 Cream Door Pack 633/2758 Oak Door Pack 198/9405 White Gloss Door Pack 633/2844 White HN Door Pack 194/7605 If you are fitting a Fridge/Freezer inside this unit please refer to the instructions that...
- Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 47kgs. space to layout the parts before recommend the Please lift with care. starting.
- Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below Left Side Right Side Back (DPF106B) (DPF107B) (DPF109A) (1980 x 560mm) (1980 x 560mm) (579 x 1976mm) Loose Shelf...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Choose which way If you would If you would you would like the like your doors like your doors doors to open to open this to open this...
- Page 6 Assembly Instructions Step 3 IMPORTANT Only carry out this step if you are building a housing for a Prepare the left side fridge/freezer. If you are building a Larder Cupboard you have already prepared this panel in Step 2. Refer to step 1 and, if required, fit 5 hinge plates onto the left...
- Page 7 Assembly Instructions Step 5 IMPORTANT Only carry out this step if you are building a housing for a Prepare the right side fridge/freezer. If you are building a Larder Cupboard you have already prepared this panel in Step 4. Refer to step 1 and, if required, fit 5 hinge plates onto the right...
- Page 8 Assembly Instructions Step 7 Fit the legs to the base Push the leg sockets into the holes in the base as shown. Secure each leg socket with 3 screws Tap in the centre plug on each leg socket Push the leg into the leg socket Step 8...
- Page 9 Assembly Instructions Step 9 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the fixed shelf Note: Wooden dowels must not stick out from the edge by more than...
- Page 10 Assembly Instructions Step 11 IMPORTANT Fit the small back Only carry out this step if you are building a housing for a fridge/freezer. If you are building a Larder Cupboard please Position the small back ignore this step. between the top and fixed shelf , as shown and secure it into...
- Page 11 Assembly Instructions Step 13 IMPORTANT Fit the back Only carry out this step if you are building a Larder Cupboard. If you are building a housing for a fridge/freezer please ignore this step. Slide the back along the grooves in the side panels Note: These 3 holes must be...
- Page 12 Assembly Instructions Step 14 Secure the unit to the Warning: Take wall care when drilling the wall Using the brackets that you do not fitted to the back edge of drill into any pipes, wires the sides etc. If in doubt, consult screw the unit to the an expert.
- Page 13 Assembly Instructions Step 16 IMPORTANT Fit the loose shelves Only carry out this step if you are building a Larder Cupboard. If you are building a housing for a fridge/freezer please ignore Insert 4 shelf studs this step. the required height for each of the shelves Lower the loose shelves down onto the shelf...
-
Page 14: Right Side
Assembly Instructions Step 18 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Important Important: Please follow If you have these instructions ONLY drill the fitted the carefully. - Page 15 Assembly Instructions Step 19 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Important If you have Important: Please follow fitted the these instructions ONLY drill the carefully.
- Page 16 Assembly Instructions Step 20 Fit doors and handles Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinges. Push the hinge onto the front part of the hinge plate The recess at the bottom of screw B goes into the slot in the hinge plate.
- Page 17 Assembly Instructions Step 21 Adjust the doors if needed Before adjusting the doors, use a spirit level to check the base (or top) of the unit is level, front-to-back and side-to-side in the 3 positions shown. Use suitable packing pieces (not supplied) to make the unit level BEFORE making any adjustment to the hinges,...
- Page 18 Assembly Instructions Step 22 Black Plinth Pack 608/2345 Fit the plinth Cream Plinth Pack 608/2369 Oak Plinth Pack 205/5668 After cutting the plinth to the required length, offer 608/2352 White Gloss Plinth Pack the plinth up to the unit and using a pencil, mark White HN Plinth Pack 198/9917 the position of the unit’s...
- Page 19 Take them to your local authority waste disposal centre. If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 20 ALR2657...
