step 5: attach fixed shelf
(H1) x 2
(H3) x 2
wooden dowel
cam
5.1. Carefully tap small wooden dowels into place. Leave 1/2" of the dowels sticking out.
5.2. Screw-In cam bolts must be screwed down flush.
5.3. Refer to page 6 for instructions on how to use the cam lock system.
5.4. Do not over tighten bolts.
finished edge
11
