hinge adjustment
To correct the right door as shown above:
Tighten the front adjustment screw on the top
hinge by turning it counter clockwise. Loosen
the front adjustment screw on the lower hinge
by turning it clockwise.
20
Slotted Hole
Rear Adjustment
Front Adjustment
Slotted Hole
To correct the right door as shown above:
Loosen the top rear adjustment screw and
push the top of the door toward the back of
the unit. Loosen the bottom rear adjustment
screw and slide the bottom of the door to the
front. Tighten both screws once adjusted.
To correct the right door as shown above:
Loosen the screws from the slotted holes.
Slide the door down and tighten the screws
securely.
