Page 2
Congratulations on your latest Target purchase. Now what? Don’t start sweating over this box of parts. This will be easy. We did the hard work for you. All you need to do is follow our simple instructions and you’ll be on your way to transforming your room in no time.
Page 3
table of contents introduction hardware parts list how to use the cam lock system assembly 7-19 hinge adjustment QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service. For faster service, have the style number and dpci number ready when calling.
Page 4
hardware (H1) x 27 (H2) x 22 (H3) x 22 (H4) x 2 (H5) x 2 (H6) x 4 wooden dowel cam bolt knob knob bolt door hinge (H7) x 16 (H8) x 16 (H9) x 16 (H10) x 18 (H11) x 1 (H12) x 4 flat head screw...
Page 5
exploded diagram ITEM DESCRIPTION QUANTITY top panel left side panel right side panel bottom panel upper back rail back panel lower back rail upper front rail fixed shelf door foot...
Page 6
how to use the cam lock system Screw cam bolt into panel Align cam bolt(s) with cam(s) Push cam into panel - arrow feature and insert all the way into on cam top points to panel edge cross-bored hole(s) Rotate cam(s) clockwise 180° to Panels should be tight against each lock panels together other and connection should be rigid...
Page 7
step 1: attach bottom panel to lower back rail (H1) x 2 (H2) x 3 (H3) x 3 wooden dowel cam bolt 1.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 1.2.
Page 8
step 2: attach upper front rail to top panel (H1) x 3 (H12) x 4 wooden dowel long pan head screw 2.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 2.2. Align screws with pre-drilled holes. 2.3.
Page 9
step 3: attach upper back rail (H1) x 2 (H2) x 3 (H3) x 3 wooden dowel cam bolt 3.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 3.2.
Page 10
step 4: attach left side panel (H1) x 4 (H2) x 8 (H3) x 3 wooden dowel cam bolt 4.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 4.2.
Page 11
step 5: attach fixed shelf finished edge (H1) x 2 (H3) x 2 wooden dowel 5.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 5.2. Screw-In cam bolts must be screwed down flush. 5.3. Refer to page 6 for instructions on how to use the cam lock system. 5.4.
Page 12
step 6: attach bottom panel and lower back rail (H1) x 4 (H3) x 3 wooden dowel 6.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 6.2. Screw-In cam bolts must be screwed down flush. 6.3.
Page 14
step 8: attach right side panel (H1) x 10 (H2) x 8 (H3) x 8 (H3) x 8 wooden dowel cam bolt 8.1. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. Carefully tap small wooden dowels into place. Leave 1/2” of the dowels sticking out. 8.2.
Page 15
step 9: attach hinges to door (H6) x 4 (H7) x 8 hinge flat head screw 9.1. Align screws with pre-drilled holes. 9.2. Do not over tighten screws.
Page 16
step 10: attach doors and knobs (H7) x 8 (H4) x 2 (H5) x 2 flat head screw knob knob bolt 10.1. Align screws with pre-drilled holes. 10.2. Do not over tighten screws.
Page 17
step 11: attach mounting plates to feet (H18) x 4 (H13) x 8 mounting plate confirmat screw 11.1. Align screws with pre-drilled holes. 11.2. Do not over tighten screws.
Page 18
step 12: attach feet (H8) x 16 (H9) x 16 bolt lock washer (H10) x 16 (H11) x 1 washer allen wrench 12.1. Align bolts with pre-drilled holes. 12.2. Do not over tighten bolts.
Page 19
step 13: install anti-tip kit (H16) (H14) Position against wall Mark position of strap hole on wall (H17) Drill 1/4” hole (H10) Tap in wall anchor (H10) (H15) Fasten anti-tip strap with wall screw provided (H17) x 1 (H16) x 1 (H14) x 1 (H15) x 1 (H10) x 2...
Page 20
hinge adjustment Slotted Hole Rear Adjustment Front Adjustment Slotted Hole To correct the right door as shown above: To correct the right door as shown above: To correct the right door as shown above: Tighten the front adjustment screw on the top Loosen the top rear adjustment screw and Loosen the screws from the slotted holes.
Page 21
l b s 1. This unit has been designed for the weight shown. Exceeding this recommended weight could result in excessive “sagging” of the top. Extreme overloading can cause failure of the top and possible injury. 2. Furniture Care Instructions: Dust with a clean, lint-free cloth. Use a spray furniture polish as needed. QUESTIONS? Just call 1-855-MYTGTHOME (855-698-4846) for parts and service.
