Mocka Addi Entertainment Unit Assembly Instructions Manual page 8

Addi Entertainment Unit
Assembly Instructions
13
A
D
A
D
3
Attach panel [1] to the unit with 6x dowels (A) and secure with 6x
locking nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
A
1
4
D
A
D
5
14
Drawers x2
14
16
P
A
12
13
Insert 10x small bolts (O) into panels [12] and [13]. Secure panels [14],
[15] and [16] to panels [12] and [13] with 2x dowel (A) and 10x small locking
nuts (P). Tighten with a screwdriver. Slide panel [17] down along the
grooves between panels [14] and [15] to form the base of the drawer.
O
O
O
12
P 13
15
P
17
14
12
13
O
O
15
8
