IMPORTANT NOTES AND WARNINGS

WARNING
!
• Read all instructions before installing or using this heater
• Use this controller only as described in this manual. Any other
use not recommended by the manufacturer may cause fire,
electric shock, or injury to persons.
• Improper installation, adjustment, or alteration and failure to
follow the warnings and instructions in this manual could result
in severe personal injury, death or property damage.
• The manufacturer is not responsible for any damage that could
happen from improper use. The manufacturer emphasises that
this controller should be used in a responsible manner and that
all procedures, warnings, and safety instructions contained in
this booklet be followed strictly.
• This controller is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate controller
where it may fall into a bathtub or other water container.
• Do not install the controller directly near a bathtub, shower or
swimming pool. Any switches or controls must not be within
reach of a person in the bathtub, shower or swimming pool.
• Extreme caution is necessary when any controller is used by or
near children or invalids and whenever the controller or heater
is left operating and unattended.
• This controller is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• Keep packaging materials out of reach of children
• Children and adults should be alerted to the hazards of
electrocution and should stay away to avoid serious personal
injury
• Children should be carefully supervised when they are in the
area of the controller.
• Do not attempt to alter the controller in any manner.
• Do not paint any surface of the controller.
• Do not touch the controller with wet hands at any time.
• Do not use or store flammable materials near this appliance.
• Do not spray aerosols or flammable materials in the vicinity of
the controller while it is in operation
• Never operate the controller in an explosive environment such
as areas where petrol or other flammable liquids or vapours are
stored.
INSTALLATION
• IMPORTANT - Installation must be carried out by a licensed and
authorised person.
• The installer is to ensure that the requirements of the local
authority, local electrical installation code, municipal building
codes, and any other relevant statutory regulations are carried
out.
• After unpacking, make sure the controller shows no signs
of visible damage or tampering. If the controller appears
damaged, contact the place of purchase for assistance.
• Remove transit protection before use.
• This appliance must only be used on a 120, 208 or 240 Volt AC
Single Phase electricity supply.
4
• This controller is NOT intended to be installed on recreational
vehicles and/or boats.
• Do not run cord under carpeting. Do not cover with throw rugs,
runners or the like arrange cord away from traffic area and
where it will not be tripped over
• A controller has hot and arcing or sparking parts inside. Do not
use it in areas where gasoline, paint or flammable liquids are
used or stored.
• This Installation and Operation manual should not be removed
from the site of installation. Installer should leave manual with
the customer for future reference.
• Any guard or other protective device removed for servicing
(conducted by an authorised person) must be replaced before
operating the controller.
• If the controller has not been used, or will not be used, for a
long period of time, disconnect power supply
• A means for disconnection of the controller must be
incorporated in the fixed wiring according to the local electrical
codes.
MAINTENANCE/ REPAIR
• Installation and repair must be carried out by a qualified &
licenced service person only. The controller should be inspected
before use and at least annually serviced & inspected by a
qualified & licenced service person.
• Do not perform maintenance until controller has been turned
off and power disconnected.
• Check for damage to the controller regularly. If damage to
the appliance is suspected, discontinue use immediately and
contact the supplier or qualified person to repair.
• If the supply cord is damaged, it must be replaced by an
authorised and licenced person in order to avoid a hazard.
• At the end of this product's useful life, it must not be disposed
of as domestic waste, but must be taken to a collection
centre for waste electrical and electronic equipment. It is the
user's responsibility to dispose of this appliance through the
appropriate channels at the end of its useful life. Failure to do
so may incur the penalties established by laws governing waste
disposal. Proper differential collection and the subsequent
recycling, processing and environmentally compatible
disposal of waste equipment avoids unnecessary damage to
the environment and possible related health risks, and also
promotes recycling of the materials used in the appliance. For
further information on waste collection and disposal, contact
your local waste disposal service, or the place of purchase
ELECTRICAL CONNECTIONS
• All connections must be rated for a single-phase 120/240VAC
power supply, with an earth connection.
• Arrange all the necessary safety devices and use only materials
that comply with standard electrical installations.
• The cable must have a section properly rated according to the
load connected and nominal temperature range up to 90°C.
www.bromicheating.com
PRODUCT OVERVIEW & INSTALLATION
1 DESCRIPTION
The Wireless ON/OFF control is for resistive and infrared heaters. The controller allows the power output of the
heater to be turned on/off, impulsive or timer controlled. The wireless control can be used with 120, 208 and 240VAC
supply voltages.
1.1 FEATURES
• Controls TWO 3000W heaters at 230VAC (1500W at 110VAC).
• Programmable relay functions: ON/OFF, impulsive and timer controlled up to 8hours, 59minutes and 59seconds.
1.2 KIT CONTENTS
• Wireless controller enclosed in a protective box.
• 4-channel remote
2.1 INSTALLATION
Study the WIRING DIAGRAM at the end of this document before starting installation.
WARNING: Isolate mains before installing. Use only on with a properly secured heater.
PLUG AND SUPPLY CORD: Use an appropriately rated plug and supply cord - check the power
requirements of the connected loads. Socket outlet used must be near the equipment.
OVERCURRENT DEVICE: The outputs are NOT protected against short circuits or extra-currents which
can damage the electronic board. Evaluate the characteristics of the connected loads and apply the
appropriate safety devices to the power line.
The wireless control must be mounted using the following guidelines:
• It must be fixed on surfaces which cannot be damaged by high temperature.
• It must be placed in a well-ventilated location.
• It must be fixed vertically, with cable glands downward.
• Connection cables must be protected against any accidental impacts, using proper pipes.
• Do cover the product.
• Do not use or store flammable materials close to the product.
1. Open cover to the box.
2. Wire in power and heater as per the wiring diagram.
3. Power on the wireless control.
4. Program the wireless control as per 'OPERATION' section.
5. Refit cover to the box.
2.2 OPERATION
Before programming, select the output L1 or L2, using the switch as outlined in the 'WIRING DIAGRAM'.
The following programming will be ONLY applied to the selected output.
It is possible to associate a single or double channel function to both of the outputs by repeating the procedure.
WARNING: The receiver automatically saves the setting 5 seconds after button release.
!
! IMPORTANT: The included 4-channel remote functions as a 4 x single channel remote OR a 2 x double channel remote
(paired Ch1 with Ch2 and Ch3 with Ch4). Functions are:
Single Channel Functions – On/Off with the same button
Double Channel Functions – On with Ch1 or Ch3. Off with Ch2 or Ch4
