Technica Engineering 1000BASE-T1 User Manual

Emc
Hide thumbs Also See for 1000BASE-T1:
Table of Contents

Advertisement

Quick Links

1000BASE-T1
MEDIACONVERTER
EMC
USER MANUAL
July 2020
Manual-Version: 4.0
Hardware-Version: 1.4 and 2.0

Advertisement

Table of Contents
loading

Related Manuals for Technica Engineering 1000BASE-T1

Summary of Contents for Technica Engineering 1000BASE-T1

  • Page 1 1000BASE-T1 MEDIACONVERTER USER MANUAL July 2020 Manual-Version: 4.0 Hardware-Version: 1.4 and 2.0...

  • Page 2: Table Of Contents

    CONTENT GENERAL INFORMATION ..................4 Functionality and Features of the 1000BASE-T1 MediaConverter_EMC ..4 1.1.1 Features ......................5 1.1.2 General Information ..................5 1.1.3 LINKS ......................5 1.1.4 General operating and safety strategy of Technica Engineering’s Products 1.1.5 General design rules for the power supply of Technica Engineering’s products ........................
  • Page 3 5.4.3 Examples ....................19 1000BASE-T1 Filter ....................27 GENERAL EMC TEST INFORMATION ..............28 ADDITIONAL INFORMATION .................. 29 LIST OF FIGURES ..................... 30 CHANGELOG ......................31 CONTACT ......................32 DECLARATION OF CONFORMITY ................ 33 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 4: General Information

    Figure 1-1:1000BASE-T1 MediaConverter_EMC The Technica Engineering 1000BASE-T1 MediaConverter_EMC transmits data frames directly from the physical layer 1000BASE-T1 to a chosen physical layer of the used SFP module. These SFP modules can be standard Ethernet RJ45 modules or optical Gbit Ethernet SFP modules with constant delay.

  • Page 5: Features

    International Protection: IP 2 0 Operating temperature: -40° to +80 °Celsius 1.1.3 LINKS The User can download the latest firmware and documentation for the 1000BASE-T1 MediaConverter EMC here: https://technica-engineering.de/produkt/1000base-t1-mediaconverter-emc/ 1.1.4 General operating and safety strategy of Technica Engineering’s Products Technica Engineering’s products are designed for operation in automotive systems and for supply voltages of nominal 12 V or 24 V.

  • Page 6: General Design Rules For The Power Supply Of Technica Engineering's Products

    General design rules for the power supply of Technica Engineering’s products The power supply circuit of Technica Engineering’s products are equipped with self- protection components. This automatic function protects the devices against excessive temperature and too high supply-voltage by switching the device off. This automatic switch-off function is independent of any software function.
  • Page 7 When integrating the modules in a vehicle or test set-up, the user must ensure appropriate ventilation or air convection. Technica Engineering products must not be considered as a safety element out of context when using safety-critical systems and must be included in the safety assessment when used. The development class in a safety system must be taken into account with standard QM referred to ISO26262.

  • Page 8: Rohs Certificate Of Compliance

    Please refer to for the EU Declaration of Conformity in CHAPTER accordance with Directive 2014/30/EU. 1.3 RoHS Certificate of Compliance Figure 1-2 Copy of RoHS Certificate of Compliance 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 9: Hardware Interfaces

    2 HARDWARE INTERFACES 2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the 1000BASE-T1 MediaConverter_EMC. Figure 2-1: Label of 1000BASE-T1 MediaConverter_EMC with pinning information 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 10: Matenet Connector

    Warning: If you apply a voltage higher than 18 Volts, the device will be damaged! Pinning: Function Minus Plus Figure 2-2: MATEnet Connector Table 2-2: MATEnet Connector The 3 pol. MQS connector is for power supply. Function Plus Minus Trigger 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 11: Optical Interface On The Backside

    Open a Terminal program (e.g. TeraTerm) at your PC and open the USB Device as serial connection. Speed settings: 14.400 kbaud/s and 8N1. Status information is displayed. The error counter can be reset by pressing “Space” key 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 12: Sfp-Interface

    Figure 2-4: Example for shown values in Tera Term 2.1.3 SFP-Interface There is one SFP cage for a MiniGBIC module. Following SFP-modules are tested and recommended: Copper SFP-module: o BEL SFP-1GBT-05, 10/100/1000BASE-T SFP Optical SFP-module: o Delock 86186 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 13: Microhdmi Connector

    Yellow Color. It is toggling (approx. 0,5 sec) when the processor is working fine. Upper right LED (No. 3): Green Color. It is lit when there is a linkup on the 1000BASE-T1 port. Lower right LED (No. 4): Yellow Color. It is lit, if power on. And it is toggling during communication on the 1000BASE-T1 port.

  • Page 14: Configuration Of The Device

    OFF (down) Frame Generator Disable Table 3-1: Configuration of DIP-Switches Note: In a 1000BASE-T1 Link one device must be set as Master, the other must be set as Slave. Note: In TestModes, press capital “T” in serial Terminal to select TestMode.

  • Page 15: 1000Base-T1 Mediaconverter Emc Mode A0 And A2

    On the one hand, there is the 1000BASE-T1 Media Converter HW 1.4 (TE- 1400), which works with a A0 PHY from Marvell (88Q2112) and is only compatible with PHY Z0, Z1 and A0 versions.

  • Page 16: Usb-Opto-Adapter

    HAPTER with the PHY 88Q2112A2 from Marvell. Note: All 1000BASE-T1 MediaConverter EMC with a serial number higher than 190500000 are built with an A2 PHY. Note: only describes how to set the DUT in TestMode. It is not a guide HAPTER how to execute a Physical Layer Test.

  • Page 17: Testmodes And Optical Status Information

    5.4 Testmodes and Optical Status Information 5.4.1 First steps After the Setup, following status information will be displayed: Figure 5-2: Status Information Sending a capital “T” key to the DUT will enter TestMode Menu: 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 18: Testmodes

    Figure 5-3: TestMode Menu 5.4.2 TestModes There are 6 TestModes (1 to 6) for 1000BASE-T1 and 5 TestModes (1 to 5) for 100BASE-T1. “0” for normal operation. TestModes for 100BASE-T1: 0: Normal Operation 1: Droop 2: Transmitter Jitter and Clock Frequency (Master)

  • Page 19: Examples

    5.4.3 Examples In the following figure you can see some examples of the output during different TestModes. 5.4.3.1 DUT in 100BASE-T1 Mode TestMode 0: Figure 5-4: Normal Operation for 100BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 20 TestMode 1: Figure 5-5 TestMode 1 for 100BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 21 TestMode 2: Figure 5-6: TestMode 2 for 100BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 22 TestMode 5: Figure 5-7: TestMode 5 for 100BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 23 5.4.3.2 DUT in 1000BASE-T1 Mode TestMode 0: Figure 5-8: Normal Operation for 1000BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 24 TestMode 2: Figure 5-9: TestMode 2 for 1000BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 25 TestMode 5: Figure 5-10: TestMode 5 for 1000BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...
  • Page 26 TestMode 6: Figure 5-11: TestMode 6 for 1000BASE-T1 Mode 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 27: 1000Base-T1 Filter

    6 1000BASE-T1 Filter The following 1000BASE-T1 Filter is used in the 1000BASE-T1 MediaConverter_EMC: The Pulse AE5002 is used. Figure 6-1: Used Filter in 1000BASE-T1 MediaConverter_EMC 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 28: General Emc Test Information

    GHz. The devices are not damaged in this setup. There will be no Link Drop on 100BASE-T1 or 1000BASE-T1. Warning: BCI closed loop method is not allowed for 100BASE-T1 or 1000BASE-T1 products. This test would permanently damage any device (independent of the vendor of device) if user’s generator is strong enough.

  • Page 29: Additional Information

    8 ADDITIONAL INFORMATION The 1000BASE-T1 MediaConverter_EMC is optimized for automotive use. The maximum cable length for 1000BASE-T1 segments is limited to 15 meters. HW-version until v1.3 was delivered with nano-MQS connector instead of MATEnet connectors. If you need information about the pinning for the old version, please ask for that support@technica-engineering.de.

  • Page 30: List Of Figures

    9 LIST OF FIGURES Figure 1-1:1000BASE-T1 MediaConverter_EMC ............. 4 Figure 1-2 Copy of RoHS Certificate of Compliance ............8 Figure 2-1: Label of 1000BASE-T1 MediaConverter_EMC with pinning information ..9 Figure 2-2: MATEnet Connector ..................10 Figure 2-3: USB-Opto-Adapter ..................11 Figure 2-4: Example for shown values in Tera Term .............

  • Page 31: Changelog

    July 2020 1.1.4 of Technica Engineering’s Products 1.1.5 Added information on General Design Rules for the Power Supply of Technica Engineering’s Products Warranty and Safety Information updated RoHS Certificate of Compliance added Declaration of conformity added 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 32: Contact

    If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ 1000BASE-T1 MediaConverter EMC User Manual...

  • Page 33: Declaration Of Conformity

    že produkt 1000BASE-T1 MediaConverter mediaconverter-emc/ EMC (TE-1400-1), je v souladu se směrnicí 2014/30/EU. Úplné znění EU prohlášení o Español shodě je k dispozici na této internetové adrese: Por la presente, Technica Engineering GmbH https://technica- declara producto 1000BASE-T1 engineering.de/produkt/1000base-t1- MediaConverter (TE-1400-1), mediaconverter-emc/ conforme con la Directiva 2014/30/UE.
  • Page 34 EUconformiteitsverklaring worden https://technica- geraadpleegd op het volgende internetadres: engineering.de/produkt/1000base-t1- https://technica- mediaconverter-emc/ engineering.de/produkt/1000base-t1- mediaconverter-emc/ Latviešu Polski Ar šo Technica Engineering GmbH deklarē, ka produkts 1000BASE-T1 MediaConverter EMC Technica Engineering GmbH niniejszym (TE-1400-1), atbilst Direktīvai 2014/30/ES. oświadcza, że produkt 1000BASE-T1 Pilns ES atbilstības deklarācijas teksts ir MediaConverter EMC (TE-1400-1), jest zgodny pieejams šādā...
  • Page 35 Slovensko Slovensky Technica Engineering GmbH potrjuje, da je Technica Engineering GmbH týmto vyhlasuje, izdelek 1000BASE-T1 MediaConverter EMC že produkt 1000BASE-T1 MediaConverter (TE-1400-1), skladen z irektivo 2014/30/EU. EMC (TE-1400-1), je v slade so smernicou Celotno besedilo izjave EU o skladnosti je na 2014/30/EÚ.
